Changing the default settings
The default baud rate setting is 9600 bps. The baud rate can be changed to the following
values using DIP switches S1 ... S4.
Table 6-9 Setting the baud rate
Baud rate [bps]
9600
14400
19200
38400
Please note that fast baud rates are generally more susceptible to interference.
The default parity and stop bit settings can be changed using DIP switches S5 and S6 and
DIP switch S7.
Table 6-10 Setting the parity
Parity S5
Even 1
Odd 1
None 0
Table 6-11 Setting the stop bits
Stop bits S7
1 0
2 1
S1 S2
0 0
1 0
0 1
1 1
S6
0
1
x
Installation
S3 S4
0 0
0 0
0 0
0 0
