Solarcheck family
30
PHOENIX CONTACT
4.4

Technical data

Voltage measurement
Supply
Supply voltage
Typical internal power consumption
Maximum internal power consumption
Measuring inputs
Voltage measuring range
Maximum transmission error from measuring range final
value
Temperature coefficient from T > 25°C
Number of measuring channels
Connection method
Minimum terminal block distance
Surge voltage
Analog output
Output voltage range
Cable length (for 0.15 mm²)
Cable type
General data
Degree of protection
Ambient temperature range (operation)
Ambient temperature range (storage)
Dimensions W / H / D
Screw connection solid / stranded / AWG
Tightening torque
Humidity at 25°C, no condensation
Altitude
Installation on DIN rail
Pollution degree
Conformance/approvals
Conformance
Referenced standard
SCK-M-U-1500V (Order No. 2903591)
24 V DC (-10% ... +25%) or via SCK-M-I-8S-20A
8 mA
65 mA
0 ... 1500 V DC
1% after additional adjustment
(valid for 100 ... 1500 V DC)
0.01% / K
1
Screw connection
32 mm
6 kV
2 ... 10 V
0.5 m, maximum
Twisted, shielded
IP20
-20°C ... 70°C
-40°C ... 85°C
22.5 / 102 / 128.5 mm
0.2 ... 2.5 mm² / 0.2 ... 2.5 mm² / 24- 12
0.5 - 0.6 Nm
≤ 95%
≤ 2000 m
35 mm (DIN EN 50022)
2
CE-compliant
Conformance with EMC Directive 2004/108/EC and Low
Voltage Directive 2006/95/EC
EN 61010-01:2011-7
105608_en_00
