105608_en_00
5.2.3

Register addresses

5.2.3.1 Structure of the register areas
Table 5-2 Structure of the register areas
Modbus address Contents
HEX [DEC]
0000..005D Data register Rev. 02
[0..93]
0080..00B0 Status register, PD0...PD47
[128..176]
00B1..00E0 MI0...MI47
[177..244]
0100..0130 Status register, PD0...PD47
[256..304]
0131..0160 MI0...MI47
[305..523]
0180..01B0 Status register, PD0...PD47
[384..432]
01B1..01E0 MI0...MI47
[433..480]
0200..0230 Status register, PD0...PD47
[512..560]
0231..0260 MI0...MI47
[561..608]
0280..02B0 Status register, PD0...PD47
[640..688]
02B1..02E0 MI0...MI47
[689..736]
0300..0330 Status register, PD0...PD47
[768..816]
0331..0360 MI0...MI47
[817..864]
0380..03B0 Status register, PD0...PD47
[896..944]
03B1..03E0 MI0...MI47
[945..992]
0400..0430 Status register, PD0...PD47
[1024..1072]
SCK-C-MODBUS Solarcheck communication module
Designation
Copy of the data register for de-
vice revision 02 to ensure com-
patibility
Process data SCK channel 1
(device at T1)
Module information data SCK
channel 1 (device at T1)
Process data SCK channel 2
(device at T2)
Module information data SCK
channel 2 (device at T2)
Process data SCK channel 3
(device at T3)
Module information data SCK
channel 3 (device at T3)
Process data SCK channel 4
(device at T4)
Module information data SCK
channel 4 (device at T4)
Process data SCK channel 5
(device at T5)
Module information data SCK
channel 5 (device at T5)
Process data SCK channel 6
(device at T6)
Module information data SCK
channel 6 (device at T6)
Process data SCK channel 7
(device at T7)
Module information data SCK
channel 7 (device at T7)
Process data SCK channel 8
(device at T8)
35
