General notes on PV systems

105608_en_00
2.1 Typical structure of large PV systems and PV
power stations

PV generator with central inverter

Figure 2-1 PV generator with central inverter

Generator with string inverters

Figure 2-2 Generator with string inverters
Inverters with and without an internal transformer are used in PV systems. This results in
various electrical characteristics which must be considered with regard to the design of the
system, cabling, the use of other devices, and the grounding concept.
Inverters with transformers, for example, can be arranged without grounding as well as with
grounding on the negative or positive side.
General notes on PV systems
+
=
~
–
N
–
=
~
+
–
=
~
+
–
=
~
+
L
L
~
N
