ST EP 5
Attaching QuickStand to the Base
IMPORTANT: Your QuickStand unit is heavy. If needed, please
have assistance when lifting.
• Carefully lift your QuickStand unit from its horizontal position
to its vertical position (fig. G)
• Once your QuickStand is sitting upright on the base slide it
back so the stopper hooks into base (fig H)
ST EP 6
Attach Leg to Base
Tools: 4 mm Hex Key
• Secure the legs to base using (8)
M6 x 9.5 mm Flat Head Machine Screws (fig. I)
• Attach the plastic leg-covers by pressing firmly
down until they each click into place (fig J)
• Position the unit so the front edge of the
work surface aligns with the front edge of
the desk when in the low position (fig K)
Proceed to the Monitor Installation steps in the main QuickStand Assembly Instructions
Customer Service: N America +1 800 400 0625 / International +353 (0)1 858 0910
G
H
J
I
K
