Intel® RAID Modules RMSP3AD160F, RMSP3CD080F and RMSP3HD080E Hardware User Guide
6.
The Hardware Component Screen shows the Battery Status. Select the Battery Management option.
7.
The Battery Management screen contains the following information:
Battery Type
Battery Status
Temperature
Capacitance
8.
Select the Advanced field at the bottom of the the Battery Management Screen.
45
Figure 25. HII Hardware Components screen
Figure 26. HII Battery Management screen
A string that identifies the RMFBU type.
The current status of the RMFBU, normally it should be optimal.
The current temperature of the battery pack or supercap
With time, the capacitance decreases, this field shows the current capacitance of
the battery pack or supercap.
