Intel® RAID Modules RMSP3AD160F, RMSP3CD080F and RMSP3HD080E Hardware User Guide
7.4
AXXRMFBU7 Mean time Between failres (MTBF)
The AXXRMFBU7 unit is very temperature sensitive. Although the heat produced by itself is negligible, the
heat from other components located near this unit can affect it significantly. Below is the MTBF information
calculated at different temperatures.
7.5
Monitoring the Intel® RAID Maintenance Free Backup Unit
Three different utilities can be used to monitor the RMFBU: StorCli, RAID Web Console 3 and HII. This section
only describes how to use HII for this purpose. For details on how to monitor using the other utilities,
consult the Intel® RAID Utilities User Guide.
7.5.1
Monitoring the RMFBU with the Human Interface Infrastructure.
The Human Interface Infrastructure (HII) can be used to configure disk arrays and logical drives. It is
independent of the operating system and can be accessed at server start-up through the Setup BIOS. The HII
can only be accessed when the system is configured for UEFI boot mode. The HII can also be used to monitor
the MFBU.
Note: Refer to the Intel® RAID Software User Guide for full featured and entry level RAID controllers for for
more information on the Human Interface Infrastructure.
To view the RMFBU information, do the following:
1.
At boot, press the <F2> key when prompted and enter the Setup BIOS.
2.
Navigate to Main, Advanced, PCI Configuration, and then UEFI Option ROM Control.
3.
Look for the RAID card under the Storage Module list.
4.
Press Enter to get into the Main Menu for the HII Configuration Utility.
43
Temperature (Celsius)
MTBF (hours)
AXXRMFBU7
55°
40°
10,152.28 19,493,177 28,169,014
30°
