Summary of Contents for Puretec ES2 Series
- Page 1 User Guide ES2 / ESR2 Series AS/NZS 3497 Licence No. WM 7617 Australian Certification Undersink | Drinking Water Systems Services For correct operation & installation it is essential to observe these instructions. JULY2019...
-
Page 2: Table Of Contents
Warranty ............................ 11 Puretec Customer Service Thank you for purchasing a Puretec water treatment system. Your system is a proven performer manufactured from only quality materials and components and will give years of spring-like water free of impurities, if maintained properly. -
Page 3: Introduction
Introduction Operation The Puretec water treatment systems are designed to run economically for many years, dependent on the initial installation and periodical maintenance. Flush systems for 10 minutes after any period of non-use more than 2 days. For a period of non-use of 2 weeks or more, it may be necessary to replace cartridges. -
Page 4: Installation
Select a suitable location that is close to the point of filtered water delivery (eg. sink). Remember to allow access room for changing filters and a suitable place where water spillage will not cause damage. Location should not be in direct Installation & Operation Manual Copyright © Puretec Pty Ltd 2019... -
Page 5: Installation Procedure
13. Restore the water supply and check for leaks. The filters need to be only hand tight. If they leak then undo housing and check the O-ring is sealed properly. Copyright © Puretec Pty Ltd 2019 Undersink | Drinking Water Systems... -
Page 6: Parts Description
For metal tube remove burrs and chamfer tube end to prevent O-Ring seal being damaged. DISCONNECTION PROCEDURE 3. Tube is secured in position. 4. Push collet against body and slide tube out of fitting. Installation & Operation Manual Copyright © Puretec Pty Ltd 2019... -
Page 7: Battery Installation
(usage has Gasket Cone Washer/Olive exceeded 3,000 minutes or 12 months). Cone Washer/Olive Please change the battery when 1/4" Compression changing the cartridges. 1/4" Compression 1/4" Tube 1/4" Tube Copyright © Puretec Pty Ltd 2019 Undersink | Drinking Water Systems... -
Page 8: Cartridge Installation / Replacement
Soak a piece of cloth in vinegar or citric to clean the quartz sleeve. Put the quartz sleeve back into the stainless steel chamber and make equal distance at both sides of the chamber. Installation & Operation Manual Copyright © Puretec Pty Ltd 2019... -
Page 9: Uv Installation
Insert UV lamp into chamber through the hole of the aluminium nut end. Never touch the quartz (glass) and lamp surface as spots of fingerprints may interfere with UV transmission. If lamp is dirtied, please clean lamp with alcohol based cleaner. Copyright © Puretec Pty Ltd 2019 Undersink | Drinking Water Systems... -
Page 10: Maintenance
To make a claim under the warranty, take the product and proof of purchase to place where you purchased the product, and they will lodge a Warranty Request with Puretec. Puretec will pay your reasonable, direct expenses of claiming under this warranty. -
Page 11: Warranty
Warranty Applicable to all above, is that the warranties need to be approved by Puretec to ensure product was not incorrectly used, installed or claimed. False and incorrect claims will be pursued at Puretec’s discretion, including chargeable inspection and labour costs incurred.
