ESR2 Tripla™ Series
Undersink UV Filter System with Tripla LED Mixer Tap
For correct operation & installation, it is essential to observe these instructions.
DO NOT OVERTIGHTEN.
DO NOT USE
LIQUID SEALANTS.
SURGE PROTECTION
REQUIRED /
NO EXTENSION CORDS.
User Guide
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Puretec ESR2 Tripla Series
Summary of Contents for Puretec ESR2 Tripla Series
- Page 1 DO NOT OVERTIGHTEN. DO NOT USE LIQUID SEALANTS. SURGE PROTECTION REQUIRED / NO EXTENSION CORDS. SURGE PROTECTION REQUIRED / NO EXTENSION CORDS. User Guide ESR2 Tripla™ Series AS/NZS 3497 Licence No. WM 74617 Australian Certification Services Undersink UV Filter System with Tripla LED Mixer Tap For correct operation &...
-
Page 2: Table Of Contents
The system is designed for mains and rainwater supply but can be used in other situations. For other types of water supply please contact your local Puretec stockist or call our Puretec Customer Service Helpline at 1300 140 140 (Australia) or 0800 130 140 (New Zealand). -
Page 3: Operation
The system is designed for rain tank or metropolitan supply water but can be used in other situations. For other types of water supply please contact your local Puretec stockist or call our Puretec Customer Service Helpline prior to installing the tap on 1300 140 140 (Australia) 0800 130 140 (New Zealand). -
Page 4: Part 1 Mixer Tap Assembly & Installation
Note: It is important to flush out the supply pipes to the mixer before connecting the flexible hoses, with the initial installation, so no foreign matter can enter into the cartridges. A Puretec Water Filter is highly recommended for product longevity. Installation & Operation Manual Copyright © Puretec Pty Ltd 2021... - Page 5 Mixer Tap Installation Fig. 2 - Tap Assembly Step 1. Connect the hoses to the faucet and tighten them. Refer to page 7 for connection patterns. Only use hand to screw the flexible hose. Do not over tighten. Don't use Brass Base any tools.
-
Page 6: Mixer Tap Connections
Mixer Tap Connections Fig. 3 - Water Connection Patterns For ESR2-T1 & ESR2-T2 Water Filter Connection Retainer Screw HOT Water COLD Water Connection Connection Installation & Operation Manual Copyright © Puretec Pty Ltd 2021... - Page 7 Mixer Tap Connections Fig. 4 - Water Connection Patterns For ESR2-T3 to ESR2-T6 Water Filter Connection Retainer Retainer Screw Screw HOT Water COLD Water Connection Connection Undersink UV Filter System with Tripla™ LED Mixer Tap...
-
Page 8: Battery Installation
This product contains a button battery. Accidental ingestion may occur and can be fatal. Please keep out of reach from infants. If you suspect an accidental ingestion please contact emergency services. Installation & Operation Manual Copyright © Puretec Pty Ltd 2021... -
Page 9: Mixer Tap Servicing
Mixer Tap Servicing Mixer Tap Servicing Periodically clean the aerator for any lodged sediment that may restrict flow. A Puretec water filter is highly recommended on all incoming lines for product longevity. Should it be necessary to have your mixer serviced while under warranty, please carry out the... -
Page 10: Part 2 Filter System Installation
Location should not be in direct sunlight. • An isolation valve may be installed prior to the system to isolate the unit for changing the cartridges, lamps and sleeve. 10 Installation & Operation Manual Copyright © Puretec Pty Ltd 2021... -
Page 11: Replacement Guide
To maintain the high quality of the purified water the cartridges need changing every 6 - 12 months (this is dependant on water quality and usage). You can obtain replacement cartridges and/or lamp from your local Puretec dealer and to maintain performance and warranty use genuine Puretec replacements. - Page 12 2-3 minutes to release air and impurities from the system. 20. Turn the power on and ensure that the lamp is operating. Make sure that the GREEN LED is illuminated. 12 Installation & Operation Manual Copyright © Puretec Pty Ltd 2021...
-
Page 13: Quick Connect Fittings
Installation Diagram Fig. 5 - Installation Diagram No. DESCRIPTION Tripla™ Mixer Tap Lock Nut & Washer Filtered Water Flexible Hose - Plain Cold Water Flexible Hose - Blue Streak Hot Water Flexible Hose - Red Streak Ballast Lamp Connector & Cap Filter System Outlet WATER Aluminium Nut... - Page 14 5. Turn the quick connect nut on the SmartTee™ 6. Push the collet against the quick connect nut and slide tube anticlockwise to release the collet. out of fitting. 14 Installation & Operation Manual Copyright © Puretec Pty Ltd 2021...
-
Page 15: Uv Lamp Installation/Replacement
UV Lamp Installation/Replacement UV Lamp Installation / Replacement Prior to performing any work on the UV steriliser system, always disconnect the power supply and allow unit to cool. The treated water will seem warm for a short period at first flow. -
Page 16: Cartridge Install/Changeout
Clean the quartz sleeve with Puretec Quartz Sleeve Cleaner SC1000. If the glass will not come up clear/clean you will need to install a new replacement quartz sleeve. Slide one of the two O-rings back over one end of the quartz sleeve. -
Page 17: Tripla T1 Parts Description
Tripla T1 Parts Fig 9. - Tripla T1 Parts Discription 1. Handle 2. Screw 5. Handle 3. Screw 6. Cap 4. Cap 7. Plunger 11-4 Connector 8. Stem / Cartridge 11-3 Inner Tube 9. Cover Stem 11-2 Tube 11-1 Body 10. -
Page 18: Tripla T2 Parts Description
42. Alternate Flexible Rubber Hose (Plain) ½" Hose (Red) Washer ½" (alternate hose with larger filter connection 17. Stainless Washer supplied but not required for ESR2 filter installation) 18. Brass Nut 18 Installation & Operation Manual Copyright © Puretec Pty Ltd 2021... -
Page 19: Tripla T3 Parts Description
Tripla T3 Parts Fig. 11 - Tripla T3 Parts Description 23-4 Connector 23. Spout 23-3 Inner Tube 23-2 Tube 23-1 Body 1. W asher 4. Washer 24. Cap 9. Display 7. Handle 2. Aerator 25. Washer Insert 8. Screw 26. O-Ring 11. -
Page 20: Tripla T4 Parts Description
Washer (Plain) ½" 45. Flexible Hose (Red) ½" (alternate hose with larger filter connection supplied but not Washer required for ESR2 filter installation) Brass 46. Flexible Hose (Blue) ½" 20 Installation & Operation Manual Copyright © Puretec Pty Ltd 2021... -
Page 21: Tripla T5 Parts Description
Tripla T5 Parts Fig. 13 - Tripla T5 Parts Description 1. Spout 1-3. Inner Tube 16. Screw 1-2. Tube 1-4. Connector 2. Washer 1-1. Body 13. Display 10. Cap 3. Aerator Insert 5. Gasket 4. Aerator Cap 6. Washer 11. O-Ring 14. -
Page 22: Tripla T6 Parts Description
½" 48. Alternate Flexible Washer Hose (Plain) ½" 51. Flexible Hose (Red) ½" (alternate hose with larger filter connection supplied but not required for ESR2 filter Washer installation) Brass 22 Installation & Operation Manual Copyright © Puretec Pty Ltd 2021... -
Page 23: Warranty
Applicable to all above, is that the warranties need to be approved by Puretec to ensure product was not incorrectly used, installed or claimed. False and incorrect claims will be pursued at Puretec’s discretion, including chargeable inspection and labour costs incurred.
