Note:
The support part is needed for the following frame R1 drive types -02A7, -03A4,
-04A1, -05A7, -08A5 and -12A7.
3. Make sure that there are no signs of damage.

Installing the module

See section Installing optional modules in chapter Electrical installation.
￭

Electrical installation

WARNING!
Obey the instructions in chapter Safety instructions. If you ignore them, injury or
death, or damage to the equipment can occur. If you are not a qualified electrician,
do not do electrical work.
Make sure that the drive is disconnected from the input power during
installation. If the drive is already connected to the input power, wait for
5 minutes after disconnecting the input power.

Necessary tools and instructions

• Screwdriver and a set of suitable bits
• Cabling tools

Terminal designations

For more detailed information on the connectors, see section
Relay outputs
Marking
50 RO4C
51 RO4A
52 RO4B
53 RO5C
54 RO5A
55 RO5B
115/230 V inputs
Marking
70 HDI7
71 HDI8
1)
72
NEUTRAL
73 HDI9
74 HDI10
1)
75 NEUTRAL
76 HDI11
77 HDI12
Description
Common, C
Normally closed, NC
Normally open, NO
Common, C
Normally closed, NC
Normally open, NO
Description
115/230 V input 1
115/230 V input 2
Neutral point
115/230 V input 3
115/230 V input 4
Neutral point
115/230 V input 5
115/230 V input 6
Optional I/O extension modules 267
Technical data (page 270).
