Viega Eco Plus sink basin element
Instructions for Use
for sink basins
Model
8159
en_INT
Year built:
from 11/2002

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 8159 and is the answer not in the manual?

Questions and answers

Summary of Contents for Viega 8159

  • Page 1 Viega Eco Plus sink basin element Instructions for Use for sink basins Model Year built: 8159 from 11/2002 en_INT...
  • Page 2 Viega Eco Plus sink basin element 2 from 14...
  • Page 3: Table Of Contents

    Product description 2.3.1 Overview 2.3.2 Compatible components 2.3.3 Sound protection 2.3.4 Technical data Accessories Handling Assembly information 3.1.1 Mounting conditions 3.1.2 Installation dimensions 3.1.3 Required tools Assembly 3.2.1 Mounting the element Disposal Viega Eco Plus sink basin element 3 from 14...
  • Page 4: About These Instructions For Use

    This restriction does not extend to possible operating instructions. The installation of Viega products must take place in accordance with the general rules of engineering and the Viega instructions for use.
  • Page 5: About This Translated Version

    German/European directives specified in this manual: The information herein is not binding for other countries and regions; as said above, they should be understood as a recommendation. Viega Eco Plus sink basin element 5 from 14...
  • Page 6: Product Information

    Intended use 2.2.1 Areas of use The Viega Eco Plus sink basin element is suitable for mounting on masonry wall constructions and support profiles pursuant to the regula- Ä „Regulations from section: Fields of application / tions in section Mounting conditions“...
  • Page 7: Product Description

    Product information Product description 2.3.1 Overview Fig. 1: Components 1 - Viega Eco Plus element 2 - connections for wall plates 3 - mounting panel 4 - mounting bracket for drain elbow 5 - drain elbow 6 - adjustable feet 2.3.2...
  • Page 8: Technical Data

    The product has the following technical data: drain elbow DN 50 Hole diameter for fixing in wooden 11 mm frame construction Construction height 1300 mm Accessories Required accessories The fixing set model 8173 is required to secure. Viega Eco Plus sink basin element 8 from 14...
  • Page 9: Handling

    With the construction height, the marked height of the upper edge of the finished floor must be observed. 3.1.2 Installation dimensions Fig. 2: Dimensions 3.1.3 Required tools The following tools are required for mounting the sink basin element: Viega Eco Plus sink basin element 9 from 14...
  • Page 10: Assembly

    X1: 390 mm (model 8180.73) X2: 440 mm (model 8173) X3: 1280 mm Ø10 0 - 2 0 Drill holes. Mount the fixing set with the fork spanner (size 13). 560638_B2 Viega Eco Plus sink basin element 10 from 14...
  • Page 11 0 - 2 0 0 Set the installation depth of the element with the fork spanner (size 17). 0 - 2 0 0 Remove WC element and drill floor holes. Ø10 Viega Eco Plus sink basin element 11 from 14...
  • Page 12 Mounting in on-site support profile The element can be inserted into the 50 mm and 75 mm support pro- files. Determine the fixing points. Align element. Mount drain elbow. Set connections for wall plates. Viega Eco Plus sink basin element 12 from 14...
  • Page 13 Ä „Construction height“ on page 9 . 0 - 2 0 0 Set height of the crossbeam. The crossbeam aids the installation of the wall-mounted fitting. 0 - 2 0 0 Viega Eco Plus sink basin element 13 from 14...
  • Page 14: Disposal

    Double-clad element (2 x 12.5 mm). Disposal Separate the product and packaging materials (e. g. paper, metal, plastic or non-ferrous metals) and dispose of in accordance with valid national legal requirements. Viega Eco Plus sink basin element 14 from 14...
