WARNING, SAFETY, & MAINTENANCE THERE IS A RISK ASSUMED BY INDIVIDUALS WHO USE THIS TYPE OF EQUIPMENT. TO MINIMIZE RISK, YOU MUST FOLLOW THESE RULES: >(9505.! WARNING! :HML[` HUK 4HPU[LUHUJL VM *HISLZ IMPORTANT: Cable inspection should be performed daily. Replace and damaged or worn cable immediately.
IMPORTANT SAFETY INSTRUCTIONS When using exercise equipment, you should always take basic precautions, including the following: Obtaining Service Personal Safety During Assembly Retain this Owner’s Manual for future reference. If you need to order replacement parts please be prepared to provide the following information when contacting us so that we can assist you better.
PART LIST/ILLUSTRATION PART G PART A FRAME A, 1 PCS LIFT OFF, 2 PCS PART B PART H FRAME B, 1 PCS SAFETY CATCH, 2 PCS PART C PART #5 FRAME C, 2 PCS FOOT CAP, 4 PCS PART D PART #6 FRAME D, 4 PCS CLIP-ON SPACER, 2 PCS...
S T E P Be careful to assemble all components in the sequence they are presented. NOTE: Finger tighten all hardware in this step. DO NOT wrench tighten until the last step. Some components may be pre-assembled. Nylon lock nuts will not fully screw onto bolts, they must be wrench tighten to fully go on.
Page 11
S T E P Above shows STEP 1 assembled and completed.
Page 12
S T E P Be careful to assemble all components in the sequence they are presented. NOTE: Finger tighten all hardware in this step. DO NOT wrench tighten until the last step. Some components may be pre-assembled. Nylon lock nuts will not fully screw onto bolts, they must be wrench tighten to fully go on.
Page 13
S T E P Above shows STEP 2 assembled and completed.
Page 14
S T E P Be careful to assemble all components in the sequence they are presented. NOTE: Finger tighten all hardware first in this step. Wrench tighten ALL hardware at the end of STEP 3C. Some components may be pre-assembled. Nylon lock nuts will not fully screw onto bolts, they must be wrench tighten to fully go on.
Page 15
S T E P Above shows STEP 3 assembled and completed.
Page 16
S T E P Be careful to assemble all components in the sequence they are presented. Insert Safety Catches (H) and Lift Offs (G) into desired positions. 4B. Insert the Safety Pins (#8) at the ends of the Safety Catches (H) and Lift Offs (G).
Page 17
S T E P Above shows STEP 4 assembled and completed.
