- Page 1 V. BFLA100-070517 BFLA100 O w n e r ’ s M A n u A L...
- Page 2 Do not allow children or minors to play on or around this equipment. If unsure of proper use of equipment, call your local Best Fitness distributor or the Best It is recommended that you workout with a training partner.
-
Page 3: Table Of Contents
tABLe OF cOntents • sAFety instructiOns ......PAge 4 • PrePArAtiOn ........... PAge 5 • HArDwAre List ........PAge 6 • HArDwAre iLLustrAtiOn ......PAge 7 • PArt List/iLLustrAtiOn ......PAge 9 • AsseMBLy instructiOns ......PAge 10 • eXPLODeD View .. -
Page 4: Safety Instructions
Antes de comenzar cualquier programma de ejercicios, deberias tener un examen fisico con su doctor. When using exercise equipment, you The BFLA100 is designed for your enjoyment. By should always take basic precautions, following these precautions and using common... -
Page 5: Preparation
PrePArAtiOn Thank you for purchasing the BFLA100. This machine is part of the Best Fitness line of quality strength training machines, which lets you target specific muscle groups to achieve better muscle tone and overall body conditioning. To maximize your use of the equipment please study this Owner’s Manual thoroughly. -
Page 6: Hardware List
HArDwAre List PArt# siZe DescriPtiOn QuAntity M12X80mm HeX HeAD BOLt 2 Pcs. M12X70mm HeX HeAD BOLt 2 Pcs. M10X80mm HeX HeAD BOLt 4 Pcs. M10X65mm HeX HeAD BOLt 2 Pcs. M10X50mm HeX HeAD BOLt 5 Pcs. M10X25mm HeX HeAD BOLt 1 Pcs. -
Page 7: Hardware Illustration
HArDwAre iLLustrAtiOn Part #1 HeX HeAD BOLt M12X80mm Qty. 2 Part #2 HeX HeAD BOLt M12X70mm Qty. 2 Part #3 HeX HeAD BOLt M10X80mm Qty. 4 Part #4 HeX HeAD BOLt M10X65mm Qty. 2 ... - Page 8 HArDwAre iLLustrAtiOn Part #6 HeX HeAD BOLt M10X25mm Qty. 1 Part #7 FLAt wAsHer M12 Qty. 8 Part #8 FLAt wAsHer M10 Qty. 23 UNLESS OTHERWISE SPECIFIED: NAME DATE DRAWN DIMENSIONS ARE IN INCHES TOLERANCES: TITLE: CHECKED FRACTIONAL ANGULAR: MACH BEND ENG APPR.
-
Page 9: Part List/Illustration
PArt List PArt# DescriPtiOn QuAntity BAse FrAMe 1 Pcs. cHrOMe uPrigHt 1 Pcs. sLiDing FrAMe 1 Pcs. tOP FrAMe 1 Pcs. PuLLey BrAcKet 2 Pcs. LOw rOw BAr 1 Pcs. LAt BAr 1 Pcs. FOOt cAP 1 Pcs. HAnD griP 4 Pcs. -
Page 10: Assembly Instructions
s t e P Be careful to assemble all components in the sequence they are presented. nOte: Finger tighten all hardware in this step. DO nOt wrench tighten until the last step. some components may be pre-assembled. nylon lock nuts will not fully screw onto bolts, they must be wrench tighten to fully go on. - Page 11 s t e P Above shows steP 1 assembled and completed.
- Page 12 s t e P Be careful to assemble all components in the sequence they are presented. nOte: Finger tighten all hardware first in this step. wrench tighten ALL hardware at the end of steP 2B. some components may be pre-assembled. nylon lock nuts will not fully screw onto bolts, they must be wrench tighten to fully go on.
- Page 13 s t e P Above shows steP 2 assembled and completed.
- Page 14 s t e P Be careful to assemble all components in the sequence they are presented. nOte: some components may be pre-assembled. nylon lock nuts will not fully screw onto bolts, they must be wrench tighten to fully go on. Attach Lat Bar (g) to top cable (#20).
- Page 15 s t e P Above shows steP 3 assembled and completed.
-
Page 16: Exploded View
eXPLODeD View DiAgrAM... -
Page 18: Contact Page
BFLA100 PLeAse write yOur seriAL nuMBer in tHe BOXes BeLOw 012912-��-��-����-���� s/n # 1900 S. Des Plaines Ave. Forest Park, Il 60130 1 (800) 556-3113 Hours: M-F 8:30 - 5:00 CST www.BestFitness.com Copyright 2003. Body-Solid. All rights reserved. Body-Solid reserves the right to change design and specifications when we feel it will improve the product.
