S T E P
Be careful to assemble all components
1
in the sequence they are presented.
NOTE:
Finger tighten all hardware in this step. DO NOT wrench tighten until the last step.
Some components may be pre-assembled. Nylon lock nuts will not fully screw onto
bolts, they must be wrench tighten to fully go on.
Install four Foot Caps (#5) in Frame A (A) and Frame B (B).
1A.
1B. Install two Clip-On Spacers (#6) on Frame A (A) and Frame B (B).
1C. Attach Frame A (A) and Frame B (B) to Frame C (C) using:
4 - (#1) M10X70mm Hex Head Bolt
8 - (#3) ø11Xø30X2.5mm Flat Washer
4 - (#4) M10 Nylon Lock Nut
1 0
