Port Forwarding - Inseego 5G Home Router 1A User Manual

IMAP, SMTP), FTP, HTTP, HTTPS, and Telnet.
3. If you want to define your own service, use the Custom Services area (see steps below).
NOTE: You need to know details of the traffic used and generated by the services you want to
define.
4. Click Save Changes.
To turn off port filtering, so that any application can connect to the Internet, click OFF on the On/Off
slider.
To add a custom application:
1. Click Add Custom Service to add a new row to the custom services list. (You can add up to 10
custom services.)
NOTE: Add Custom Service is available only when the port filtering is turned on.
2. In the Service Name field, enter a name for the custom service.
3. In the Start Port field, enter the beginning of the range of port numbers used by outgoing
traffic for the custom service being added.
4. In the End Port field, enter the end of the range of port numbers used by the service.
NOTE: If the service uses a single port instead of a range, type the same value for both the
Start Port and the End Port.
5. From the Protocol drop-down list, select the protocol used by the port range. Choose from
Transmission Control Protocol (TCP), User Datagram Protocol (UDP), or both.
6. Select the On checkbox if you want your new service to be able to access the Internet.
7. Click Save Changes to save any changes made to the custom applications.
To delete a custom service, select the Delete checkbox for its row, and click Save Changes.
NOTE: Click on the Port Filtering tab again to remove deleted custom applications from view on the
screen.

Port Forwarding

Port Forwarding allows incoming traffic from the Internet to be forwarded to a particular computer or
device on your Wi-Fi network. Normally, the built-in firewall blocks incoming traffic from the Internet.
Port forwarding allows Internet users to access any server you are running on your computer, such as
a Web, FTP, or E-mail server. For some online games, port forwarding must be used in order for the
games to function correctly.
IMPORTANT: Port forwarding creates a security risk and should be turned off when not required.
5G HOME ROUTER 1A USER GUIDE 42
