6.4 Suction heights
6.4.1 Media with a viscosity similar to water
Applies to:
•
counter-pressure of 1.5 to 3 bar
•
non-degassing and non-abrasive media
•
temperature of 20 °C
•
stroke length 100 %.
Pump type
Suction height*
[mWC]
DMX 4-10
DMX 7-10
DMX 9-10
DMX 12-10
DMX 17-4
DMX 25-3
DMX 7.2-16
DMX 8-10
DMX 14-10
DMX 18-10
DMX 26-10
DMX 39-4
DMX 60-3
DMX 13.7-16
DMX 16-10
DMX 27-10
DMX 35-10
DMX 50-10
DMX 75-4
DMX 115-3
* Suction line and dosing head filled (continuous operation)
** Suction line and dosing head not filled, but dosing head and valves moistened (start-up)
