6.4.2 Suction heights for media with maximum permissible
viscosity
Applies to:
•
Newtonian liquids
•
non-degassing and non-abrasive media
•
temperature of 20 °C.
Maximum
Pump type
viscosity
[mPa s]
DMX 4-10
400
DMX 7-10
400
DMX 9-10
200
DMX 12-10
200
DMX 17-4
200
DMX 25-3
200
DMX 7.2-16
400
DMX 8-10
400
DMX 14-10
400
DMX 18-10
200
DMX 26-10
200
DMX 39-4
100
DMX 60-3
100
DMX 13.7-16
200
DMX 16-10
200
DMX 27-10
200
DMX 35-10
100
DMX 50-10
100
DMX 75-4
100
DMX 115-3
100
6.5 Ambient and operating conditions
•
Permissible ambient temperature: 0 °C to +40 °C.
•
Permissible storage temperature: –20 °C to +50 °C.
•
Permissible air humidity: max. relative humidity:
70 % at 40 °C, 90 % at 35 °C.
The installation site must be under cover!
Ensure that the enclosure class of motor and
pump are not affected by the atmospheric
Caution
conditions.
Pumps with electronics are only suitable for
indoor use! Do not install outdoors!
Warning
Risk of hot surfaces!
Pumps with AC motors may become hot.
Allow a minimum space of 100 mm above the fan
cover!
•
Sound pressure level: ± 55 dB(A), testing according to DIN
45635-01-KL3.
•
Minimum counter-pressure: 1 bar at the pump discharge
valve.
Pay attention to the pressure losses along the way to the
injection point inclusively.
Pumps with AR control unit only
Maximum permissible mains impedance: 0.084 + j 0.084 Ω
(testing according to EN 61000-3-11).
6.6 Dosing medium
In the event of questions regarding the material
resistance and suitability of the DMX 221 for
Caution
specific dosing media, please contact Grundfos
Alldos.
10
Intake height
[mWC]
1
1
1
1
1 mWC flooded suction
1 mWC flooded suction
1
1
1
1
1 mWC flooded suction
1
1
1
1
1
1
1
1 mWC flooded suction
1 mWC flooded suction
The dosing medium must have the following basic characteristics:
•
liquid
•
non-abrasive
•
non-inflammable.
6.6.1 Permissible media temperature
Dosing head
material
p < 10 bar
PVC
0 °C to 40 °C
Stainless steel,
–10 °C to 70 °C
DIN 1.4571*
Stainless steel,
–10 °C to 70 °C
DIN 2.4610*
PP
0 °C to 40 °C
–10 °C to 60 °C*
PVDF
* For SIP/CIP applications: A temperature of 145 °C at a
counter-pressure of max. 2 bar is permitted for a short period
(15 minutes).
Observe the freezing and boiling points of the
Caution
dosing medium!
6.7 Electrical data
6.7.1 Enclosure class
The enclosure class depends on the motor variant selected, see
motor nameplate.
The specified enclosure class can only be ensured if the power
supply cable is connected with the same degree of protection.
Pumps with electronics: The enclosure class is only met if the
sockets are protected! The data regarding the enclosure class
applies to pumps with correctly inserted plugs or screwed-on
caps.
6.7.2 Motor
Version: see motor and pump nameplates.
6.8 AR control unit
Functions of pumps with electronics:
•
"Continuous operation" button for function test and dosing
head deaeration
•
memory function (stores a maximum of 65,000 pulses)
•
two-stage tank-empty signal (e.g. via Grundfos Alldos tank
empty sensor)
•
stroke signal/pre-empty signal (adjustable), e.g. as a feedback
to the control room
•
dosing controller function (only with sensor – optional)
•
diaphragm leakage detection (only with sensor – optional)
•
access-code-protected settings
•
remote on/off
•
Hall sensor
•
operating hours counter
•
motor monitoring.
Operating modes:
•
manual
Stroke frequency: manually adjustable between zero and
maximum
•
contact signal control
Multiplier (1:n) and divisor (n:1)
•
current signal control 0-20 mA / 4-20 mA
Adjustment of stroke frequency proportional to the current
signal.
Weighting of current input.
Temperature range
p < 16 bar
0 °C to 20 °C
–10 °C to 70 °C
–10 °C to 70 °C
–
–10 °C to 20 °C
*70 °C at 9 bar
