Silicon Laboratories Si5316 Series Reference Manual page 118

Si53xx-RM
A A—N
PPENDIX ARROWBAND
Resonator/External Clock Selection
Table 63 shows the approved 114.285 MHz 3rd overtone crystals.
Manufacturer
TXC
Connor Winfield
Connor Winfield
NDK
NDK
Siward
Saronix/eCera
Mtron
RATE[1:0] NB/WB
HH WB
HM NB
HL NB
MH NB
MM NB
ML NB
LH NB
LM NB
LL NB
In some applications, crystal with frequencies other than 114.285 MHz may be used. Contact Silicon Labs for
details and a current list of crystal vendors and approved part numbers.
External reference (and crystal) frequency values should be avoided that result in an output frequency that is an
integer or near integer multiple of the reference frequency. See Appendix B for details.
Because the crystal is used as a jitter reference, rapid changes of the crystal temperature can temporarily disturb
the output phase and frequency. For example, it is recommended that the crystal not be placed close to a fan that
is being turned off and on. If a situation such as this is unavoidable, the crystal should be thermally isolated with an
insulating cover.
118
R
EFERENCES
Table 63. Approved Crystals
Part Number
7MA1400014 http://www.txc.com.tw
CS-018 http://www.conwin.com
CS-023 http://www.conwin.com
EXS00A-CS00871 http://www.ndk.com/en/
EXS00A-CS00997 http://www.ndk.com/en/
XTL573200NLG- http://www.siward.com
114.285 MHz-OR
FLB420001 http://www.pericom.com/saronix
http://www.ecera.tw
M1253S071 http://www.mtronpti.com
Table 64. XA/XB Reference Sources and Frequencies
Type
No crystal or external clock
External clock
Reserved
External clock
3rd overtone crystal
External clock
Reserved
External clock
Reserved
Web Site
Recommended
—
171.4275 MHz
—
114.285 MHz
114.285 MHz
57.1425 MHz
—
38.88 MHz
—
Rev. 0.41
Stability Initial
Accuracy
100 ppm 100 ppm
100 ppm 100 ppm
20 ppm 20 ppm
100 ppm 100 ppm
20 ppm 20 ppm
20 ppm 20 ppm
100 ppm 100 ppm
100 ppm 100 ppm
Lower limit Upper limit
— —
163 MHz 180 MHz
— —
109 MHz 125.5 MHz
— —
55 MHz 61 MHz
— —
37 MHz 41 MHz
— —
