- Page 1 DanVex DEH-1200Р DEHUMIDIFIER INSTALLATION AND OPERATING INSTRUCTIONS...
- Page 2 RoHS Please read this instruction manual before using the dehumidifier. www.danvex.fi...
-
Page 3: Table Of Contents
Panel Control ....................Remote Controller ..................10-11 Operation Guide ..................... AUTO Operation Mode ................. Air Direction Adjustment ................Timer Operations .................... Defrost system ....................Water drainage system ................... Error codes ..................... Wiring diagram ....................Maintenance ....................7-18 Trouble Shooting ......................www.danvex.fi... -
Page 4: Safety Instruction
PROHIBITION PROHIBITION WARNING Use an exclusive power source with a circuit When abnormality such as burnt-small found, breaker. immediately stop the operation button and contact sales shop. STRICT ENFORCEMENT www.danvex.fi... -
Page 5: Attention During Usage
If the abnormal condition persists, it may cause a electric shock or a fire due to overheating. Please consult the dealer of service centre as soon as possible to arrange for a repair. www.danvex.fi... - Page 6 If internal combustion of the heater Due to danger of electric shocks. instruments, food, plants and is not complete, it may give out artistic items. This may affect the poisonous carbon monoxide. quality of the food. PROHIBITION PROHIBITION PROHIBITION www.danvex.fi...
-
Page 7: Principle Of Dehumidifier
The dehumidifier use the refrigeration circuit to change the damp air warm dry air. When the damp air passes the condenser, the air water will be condensed and the air will become dry. The Specification Of Dehumidifier (R410a) Model DEH-1200P Capacity(L/hr) Heating capacity(W) 2300... -
Page 8: Exploded Views
Upper fixing board Indoor temperature sensor Draining connector Plastic cover Drain pipe Power Cord Right panel Electrical box cover PG connector Cross flow fan Terminal Defrost temperature sensor Cover Compressor Capacitor Capillary Fan motor Public Terminal Filter Heat exchanger bracket www.danvex.fi... -
Page 9: Descriptions Of Parts
Function of the needle valve When the heat pump need to measure the pressure of the current system or to filling refrigerant, the operator can use this service valve and make the appropriate maintenance work! www.danvex.fi... -
Page 10: Panel Control
Display Displays when turns to CLOCK status Auto operation mode Fan operation mode Displays when turns to TEMPERATURE status Displays when turns to status Heating operation mode Dehumidifying operation mode CLOCK or TEMPERATURE or display www.danvex.fi... -
Page 11: Remote Controller
Air flow setting. Timer On Button : Set Timer-on hour. Timer Cancel Button Cancel Timer-On and Timer-Off settings. Timer Confirm Button Send Timer-on or Timer-off data to the dehumidifier. Air Direction Button : Set air louver swinging or stationary. www.danvex.fi... - Page 12 When AUTO FAN Automatic the display disappears, the up- down louver stops swinging. High NOTE: All Displays on the diagram are listed out for demonstration. During operation, only the relevant display will appear on the remote controller. www.danvex.fi...
-
Page 13: Operation Guide
When heating mode is selected, the internal fan will delay operation for a while when the machine is switched on to prevent cool air circulation at the beginning. After switching on, air flow amount and temperature may be separately adjusted as desired. www.danvex.fi... -
Page 14: Auto Operation Mode
18~31 adjustable Factory setting is 25 Heating Factory setting is 60% 1%~99% adjustable Dehumidify Adjustment in Automatic Mode Feeling Operation Button Press once to change the air flow progressively until the Unsuitable fan speed suitable air flow is selected. www.danvex.fi... -
Page 15: Air Direction Adjustment
To get the best effect, the up-down air flow is usually set in the following manner : Dehumidifying - Horizontal air direction or upward air direction. Heating -Downward air direction Changing Left-Right Air Direction NOTE: Don’t move the Left-Right van directly. www.danvex.fi... -
Page 16: Timer Operations
If the "On-Off" button is pressed while the unit is under timer-off setting, then the unit will shut down immediately, the timer setting is cancelled and the timer light will be off. Timer Cancellation Press "Timer-Cancel" button to cancel the timer-on or timer-off settings. www.danvex.fi... -
Page 17: Defrost System
In this instance, you should cut the power off, and then restart the dehumidifier ,and the operation will continue . Error Codes E1 : Room temperature sensor error; E2 : Defrost temperature sensor error; E3 : Humidity sensor error; E4 : Drain error; P1 : Electrical heater error; www.danvex.fi... -
Page 18: Wiring Diagram
Do not block the air inlet or outlet. Use the timer effectively. Setting of proper room temperature. If the unit is not to be used for Use the louvers effectively. Close doors and windows during a long time, turn off the power operation. supply main switch. www.danvex.fi... - Page 19 On a fine day, unit shall be started and operate in FAN mode for about half a day until the inside of the unit becomes thoroughly dry. 3. Cleaning the body. 4. Take out the batteries from the wireless remote controller. www.danvex.fi...
-
Page 20: Trouble Shooting
Is fuse blown out? Is the air filter dirty? Normally it should be cleaned every 15 days. Are there any obstacles before inlet and outlet? Inefficient Is temperature set correctly? Are there some doors or windows left open? www.danvex.fi...
