Table of Contents
Precaution
On safety
• Operate the unit only with a power source as
specified in "Specifications" section.
• The nameplate indicating operating voltage, power
consumption, etc., is located at the rear.
• Should any solid object or liquid fall into the cabinet,
unplug the unit and have it checked by qualified
personnel before operating it any further.
• Do not drop or place heavy objects on the power
cord. If the power cord is damaged, turn off the
power immediately. It is dangerous to use the unit
with a damaged power cord.
• Unplug the unit from the wall outlet if it is not to be
used for several days or more.
• Disconnect the power cord from the AC outlet by
grasping the plug, not by pulling the cord.
• The socket-outlet shall be installed near the
equipment and shall be easily accessible.
On installation
• Allow adequate air circulation to prevent internal
heat build-up.
Do not place the unit on surfaces (rugs, blankets,
etc.) or near materials (curtains, draperies) that may
block the ventilation holes.
• Do not install the unit in a location near heat sources
such as radiators or air ducts, or in a place subject to
direct sunlight, excessive dust, mechanical vibration
or shock.
On cleaning
To keep the unit looking brand-new, periodically clean
it with a mild detergent solution. Never use strong
solvents such as thinner or benzine, or abrasive
cleansers since they will damage the cabinet. As a
safety precaution, unplug the unit before cleaning it.
On repacking
Do not throw away the carton and packing materials.
They make an ideal container which to transport the
unit. When shipping the unit to another location,
repack it as illustrated on the carton.
If you have any questions about this unit, contact your
authorized Sony dealer.

Table of Contents

Features ..................................................................... 4
Front ................................................................. 6
Rear Panel ........................................................ 8
Using On-Screen Menus ......................................... 10
On-Screen Menu Configuration ..................... 10
Functions of On-Screen Menus ...................... 12
Connections ............................................................. 15
BNC Connector ......................................... 15
Specifications ........................................................... 16
About this manual
Before operating the unit, please read this manual
thoroughly and retain it for future reference.
The explanation given in this manual can be applied to
the following models unless noted otherwise.
When explanation differs among models, this is clearly
indicated in this manual.
• PVM-14M4U/14M4E/14M4A (14-inch monitor)
• PVM-14M2U/14M2E/14M2A (14-inch monitor)
• PVM-20M4U/20M4E/20M4A (20-inch monitor)
• PVM-20M2U/20M2E (20-inch monitor)
Illustrations of the video monitor are of the PVM-
20M4U/20M4E/20M4A.
