Grandhall CCH07A090 Operator's Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Charcoal Grill
MODEL CCH07A090
FREE HELP
Customer Support Helpline:
FROM THE GRILL EXPERTS
At Grand Hall we're the experts on this
product and trained to help you with:
Ÿ
Assembly Questions
Ÿ
Grill Operation
Ÿ
Replacement of Damaged or Missing parts
visit www.grandhall.com or call:
1-877-934-7455
Monday - Friday 8:00am-4:30pm CST
IMPORTANT:
Ÿ
NOTE TO ASSEMBLER / INSTALLER:
Leave this manual with the consumer.
Ÿ
NOTE TO CONSUMER:
Keep this manual for future reference.
Ÿ
RECORD YOUR SERIAL # __________________
(see silver CSA label on main body of grill)
OPERATOR'S MANUAL
WARNING
!
Ÿ
Whether this grill was assembled by you or
someone else, you must read this entire manual
before using your grill to ensure the grill is
properly assembled and installed.
Ÿ
Obtain assistance from another person when
handling the large or heavy pieces.
Ÿ
Some parts may contain sharp edges, wear
protective work gloves if necessary.
Ÿ
Combustion byproducts produced when using
this product contain chemicals known to the
State of California to cause cancer, birth de-
fects, or other reproductive harm.
Ÿ
THIS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY
Ÿ
CARBON MONOXIDE HAZARD - Burning
charcoal inside gives off carbon monoxide
without odor that can kill you. NEVER burn
charcoal inside homes, vehicles or tents.
Ÿ
This product contains chemicals known to
the State of California to cause birth defects
or other reproductive harm.
Manual # P80170005A - Date:2009/08/25
!

Advertisement

loading
Need help?

Need help?

Do you have a question about the CCH07A090 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Grandhall CCH07A090

Summary of Contents for Grandhall CCH07A090

  • Page 1 Grill Operation Ÿ Obtain assistance from another person when Ÿ Replacement of Damaged or Missing parts handling the large or heavy pieces. visit www.grandhall.com or call: Ÿ Some parts may contain sharp edges, wear protective work gloves if necessary. 1-877-934-7455 Ÿ...
  • Page 2 Table of Contents DANGER Primary Safety Warnings ......1-2 Part Diagrams and Lists ......3-6 Ÿ Never allow children to operate your grill. Do not Assembly Instructions.......7-12 allow children or pets to play near your grill. Use & Care Instructions: Cleaning and Maintenance ......
  • Page 3 Hardware Pack Parts List for CCH07A090 PART # PART DESCRIPTION QTY PURPOSE OF PART P06002012A Hardware Pack For use in assembly S112G04061 Phillips Head Screw 1/4"x3/8" 16 Installs Cart Legs P05515015L Wrench Tightens Casters S411M10221 Plain Washer M10.5 Installs into Wheel Axle Installs Grease/Ash Tray Bracket S112G04061 Phillips Head Screw 1/4"x3/8"...
  • Page 4 Parts Diagram for Model CCH07A090...
  • Page 5 Parts List for Model CCH07A090 DESCRIPTION PART# Lid Assembly Y0110035 Lid Handle P00205005B Lid Handle Heat-Insulating Spacer P06801002A Lid Handle Bracket, Left P00301016E Lid Handle Bracket, Right P00302016E Temperature Gauge P00601171A Protective Pad P05518002I Name Plate P00407010D Bowl Frame Panel, Front...

  • Page 6: Key Part Description

    Parts List for Model CCH07A090 PART DESCRIPTION PART# Charcoal Tray Adjusting Arm P04102002D Charcoal Tray Adjusting Arm Handle P05508076E Grease/Ash Tray Body P02717671A Grease/Ash Tray Handle P00210002H Grease/Ash Tray Trim Plate P02720063C Grease/Ash Tray Track, Left/Right P05330010E Grease/Ash Tray Bracket...
  • Page 7 Assembly Instructions Install Cart Legs onto Cart Bottom Shelf Have an assistant help you with positioning the Cart Legs (Left Back, Left Front, Right Front, Right Back) onto the Cart Bottom Shelf. Use 4 Phillips Head Screws 1/4"x3/8" to secure each Cart Leg.
  • Page 8 Install Grease/Ash Tray Bracket Install Grease/Ash Tray Bracket onto Cart Legs as shown using 4 Phillips Head Screws 1/4"x3/8". Phillips Head Screw 1/4"x3/8" Qty. 4 Part # S112G04061 Install Grease/Ash Tray Tracks Install 1 Grease/Ash Tray Track onto the Left Cart Legs using 4 Phillips Head Screws 1/4'x3/8".
  • Page 9 Install Grill Bowl Remove Cooking Grids and Secondary Cooking Rack from Grill Bowl. With an assistant, lift and position the Grill Bowl onto the Cart as shown. Secure the Grill Bowl by using 13 Pan Head with Cross Recess Screws 1/4"x1/2"...
  • Page 10 Install Side Shelves Align the 4 holes on the Left Side Shelf with the threaded holes on the Cart. Insert 4 Phillips Head Screws 1/4"x1/2 from the inside of the Side Shelf and tighten securely. Repeat for Right Side Shelf. Phillips Head Screw 1/4"x1/2"...
  • Page 11 Assemble Grease/Ash Tray Handle onto the Grease/Ash Tray Install Grease/Ash Tray Handle onto Grease/Ash Tray. Secure the Handle using 6 Phillips Head Screws 3/16"x3/8". Phillips Head Screw 3/16"x3/8" Qty. 6 Part # S112G03061 Install Grease/Ash Tray Slide the assembled Grease/Ash Tray over the Grease/Ash Tray Tracks.
  • Page 12 Install Cooking Components Place Cooking Grids on bowl ledge. Place the Secondary Cooking Rack into the slots on Grill Bowl Side Panels. Congratulations. Your Charcoal Grill is now ready to use. Final Grill Assembly Step When you have finished assembling your Secondary Cooking Rack grill be sure that all screws are tightened for safe operation of your grill.

  • Page 13: Using Your Charcoal Grill

    USE AND CARE INSTRUCTIONS CLEANING AND MAINTENANCE USING YOUR CHARCOAL GRILL Using Charcoal Proper care and maintenance will keep your grill in top operating condition and prolong its life. Follow these Open Access Door. Slide the Charcoal Tray out from cleaning procedures on a timely basis and your grill will stay Charcoal Tray Support.
  • Page 14 All Other Grill Parts-2 Years Grand Hall will require reasonable proof of your date of purchase. Therefore, you should send in the owner registration card or register online at www.grandhall.com. Save your receipt in case it is required as proof of purchase.
