Portable Gas Barbecue
Operating and Assembly Instructions
FOR YOUR SAFETY.
IF YOU SMELL GAS:
1. Shut off gas to the
appliance, if possible.
2. Extinguish any open flame.
3. Open hood.
4. If odour continues,
immediately call your gas
supplier or fire department.
FOR YOUR SAFETY.
1. Do not store or use
petrol or other flammable
vapours and liquids in the
vicinity of this or any other
appliance.
2. A gas cylinder not
connected for use must not
be stored in the vicinity of
this or any other appliance.
These instructions are a
guide to assembling and
using the 5009XBHN
barbecue.
Please read carefully, and
retain for future reference.
Only to be used outdoors.
Illustration may vary from barbecue
contained in carton.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Grandhall 5009XBHN
Summary of Contents for Grandhall 5009XBHN
- Page 1 Operating and Assembly Instructions These instructions are a FOR YOUR SAFETY. FOR YOUR SAFETY. guide to assembling and using the 5009XBHN IF YOU SMELL GAS: 1. Do not store or use barbecue. petrol or other flammable 1. Shut off gas to the vapours and liquids in the appliance, if possible.
-
Page 2: Table Of Contents
GAS INSTALLATION CODES FAILURE TO COMPLY WITH THESE INSTRUCTIONS COULD RESULT IN A Barbecues must be used in accordance with the installation FIRE OR EXPLOSION WHICH COULD requirements of your local gas supply authority, and the appropriate CAUSE SERIOUS BODILY INJURY, installation standard AS5601/AG601. -
Page 3: Safety
CHECKING FOR GAS LEAKS READ CAREFULLY BEFORE ASSEMBLING AND OPERATING NEVER TEST FOR LEAKS WITH AN OPEN FLAME. YOUR BARBECUE. Prior to first use, and at the beginning of each new season (or, if using bottled gas, whenever gas cylinder is changed), you must LOCATION OF YOUR BARBECUE check for gas leaks. -
Page 4: Outdoor Areas
THIS APPLIANCE SHALL ONLY BE USED IN AN ABOVE GROUND OPEN AIR SITUATION WITH NATURAL VENTILATION, WITHOUT STAGNANT AREAS, WHERE GAS LEAKAGE AND PRODUCTS OF COMBUSTION ARE RAPIDLY DISPERSED BY WIND AND NATURAL CONVECTION. ANY ENCLOSURE IN WHICH THE APPLIANCE IS USED SHALL COMPLY WITH ONE OF THE FOLLOWING: •... -
Page 5: Pre-Assembly
GENERAL CARTON CONTENTS While it is possible for one person to assemble the barbecue, Description we recommend asking for the assistance of another person when Trolley side panel – right manoeuvring some of the larger or heavier pieces. Trolley side panel – left Bottom shelf ASSEMBLY TIPS Castor seat... -
Page 6: Assembly
Attach castor seats to side panels. NOTE: Castor seats are labelled for correct location Phillips-head screw " x " Qty: 8 Countersunk flat-head screw " x " LF / RR Qty: 8 Door magnets Attach side panels to bottom shelf. to front Phillips-head screw "... - Page 7 Trolley bracket front Attach the trolley bracket front Rear panel and rear panel. Phillips-head screw " x " Qty: 8 Flange nut " Qty: 8 Attach body support brackets and gas cylinder housing. Position wing bolt to rear. Gas cylinder housing Phillips-head screw Flange nut...
- Page 8 Attach barbecue body to trolley. NOTE: Cut cable tie from underneath the barbecue head to release the gas regulator before assembling onto trolley. Phillips-head screw " x 1 " Qty: 4 Washer " Qty: 4 Slide tool hook onto the tool holder and attach to the side shelf.
- Page 9 Install side shelf brackets. From the rear of the barbecue, and below the gas hoses, slide the grease tray side tabs over the side rails under- neath the barbecue body. Side shelf Install the grease receptacle under the grease tray from Grease bracket –...
- Page 10 Install left side shelf and side burner frame. Place the side shelf over the left side shelf brackets and side burner frame over the right side shelf brackets using four (4) " x " Phillips-head screws and four (4) " flange nuts.
- Page 11 Attach cylinder connection ENSURING BURNER CONTROLS ARE OFF device of regulator and hose assembly to cylinder IMPORTANT: Before connecting and disconnecting valve outlet. barbecue to gas source, ensure burner controls are Tighten firmly. in ‘OFF’ position. Open the gas NOTE: The ‘OFF’ position on the control panel is cylinder valve identified by either a small black dot / a short vertical Direction for...
-
Page 12: Inspection
IGNITION BATTERY BURNER OPERATION AND IGNITION SYSTEM CHECK Piezo igniter Gas collector / electrode battery Igniter Gas valve assembly Orifice Burner tube Contact Spring With burner controls in ‘OFF’ position, open the gas cylinder valve or connect to gas supply. Upon first assembly the gas lines and burners will be full of air. -
Page 13: Accessory Assembly
A S S E M B L Y – G E N E R A L WITH THE ASSISTANCE OF ANOTHER SIDE BURNER ELECTRODE CHECK PERSON, PERFORM THIS ELECTRODE CHECK BEFORE PROCEEDING. • Open side burner lid. Remove plastic shipping band from burner and pot support. - Page 14 Open barbecue hood before attempting to light TEMPERATURE GAUGE back burner. Set burner control knobs to ‘OFF’ and open the The temperature gauge is used as a guide to cooking temperatures gas cylinder valve. when cooking with the hood closed. Push and turn back burner control knob to ‘ON’.
- Page 15 OPERATING PROCEDURE • THE SIDE BURNER IS DESIGNED FOR USE WITH A WOK UP TO 360 mm DIAMETER AND COOKING POTS UP TO BURN-OFF 200 mm DIAMETER Before cooking on your barbecue for the first time, burn-off any • USE OF VERY LARGE POTS MAY residual oils or foreign matter from the cooking plates.
- Page 16 • The easiest foods to balance are those of uniform shape ROTISSERIE and texture. To test if the food is balanced correctly when secured, place the ends of the rotisserie skewer loosely Rotisserie is available as an optional extra from your place of purchase.
-
Page 17: Fault Finding
IF THE BARBECUE FAILS TO LIGHT • SHOULD A FLASHBACK FIRE OCCUR IN OR AROUND THE BURNER TUBES, FOLLOW THE INSTRUCTIONS BELOW. Turn gas off at source and turn burner control knobs to FAILURE TO COMPLY WITH THESE ‘OFF’. Wait at least five (5) minutes for gas to clear, then INSTRUCTIONS COULD RESULT IN A retry. -
Page 18: Maintenance
CLEANING THE FLAME TAMERS DO NOT USE OVEN CLEANER TO CLEAN THE BARBECUE. Periodically you should wash the flame tamer in a soap and warm water solution. Use a vegetable brush to remove stubborn burnt-on cooking residue. Dry the flame tamers thoroughly before you re-install them into the barbecue. - Page 19 • BEWARE OF SPIDERS. STORAGE BURNER TUBES SHOULD BE INSPECTED AND CLEANED We recommend that you minimise the barbecue’s exposure to PERIODICALLY. the elements. High moisture content in the air (rain, mist, salt spray etc.) can affect metal components and lead to material •...
- Page 20 METHOD 3: Use an air hose to force air through each burner tube. CLEANING THE BURNER TUBES The forced air should pass debris or obstructions through the AND BURNER PORTS burner and out the ports. To reduce the chance of FLASHBACK FIRE you must clean the Regardless of which burner cleaning procedure you use, we burner tubes as follows at least once a month in summer and fall recommend you also complete the following steps to help prolong...
- Page 21 THIS PAGE HAS BEEN LEFT INTENTIONALLY BLANK...
-
Page 22: Parts Diagram / List
This diagram is provided to assist you identify parts if replacement is necessary. Contact your place of purchase or the manufacturer to enquire about parts, availability and or service. Items included in your barbecue specification may differ from the parts list, depending on region or specific dealer specification. - Page 23 Description Part No. Hood P001450464 Hood hinge P05501018A Protective pad – front / rear P05518002I Temperature gauge P00601331B Hood handle P00206004M Hood handle bracket – left P00301106A Hood handle bracket – right P00302106A Name plate P00407006S Grill plate P01615028H Hot plate P01702008K Burner –...
- Page 24 Privacy Act 1988 (Cth). Importantly, individual consumers generally have a right to access information held about them. Manufactured by Grand Hall Enterprise Co Ltd Focus Lifestyle Products Pty Ltd ABN 93 160 136 977 223 - 225 Governor Road, Braeside, Victoria, Australia 3195 P.O.
