Grandhall XI08ALP Operator's Manual

Xi08alp liquid propane gas (lpg) grill, xi08ang natural gas (ng) grill

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

Liquid Propane Gas (LPG) Grill

Model XI08ALP

Natural Gas (NG) Grill

Model XI08ANG

FREE HELP

FROM THE GRILL EXPERTS

At Grand Hall we're the experts on this

product and trained to help you with:

Assembly Questions

Grill Operation

Replacement of Damaged or Missing parts

visit www.grandhall.com or call:

1-877-934-7455

Monday - Friday 8:00am-4:30pm CST

IMPORTANT:

NOTE TO ASSEMBLER / INSTALLER:

Leave this manual with the consumer.

NOTE TO CONSUMER:

Keep this manual for future reference.

RECORD YOUR SERIAL # __________________

(see silver CSA label on main body of grill)

XI08ALP

Operator's Manual

WARNING

Failure to comply with these instructions could

result in a fire or explosion that could cause

serious bodily injury, death or property dam-

age.

Whether this grill was assembled by you or

someone else, you must read this entire manual

before using your grill to ensure the grill is

properly assembled, installed and maintained.

Use your grill at least 3 feet away from any

wall or surface. Use your grill at least 3 feet

away from combustible objects that can melt or

catch fire such as vinyl or wood siding, fences

and overhangs or sources of ignition including

pilot lights on water heaters and live electrical

appliances.

THIS GAS APPLIANCE IS DESIGNED FOR

OUTDOOR USE ONLY.

Never use your gas grill in a garage, porch,

shed, breezeway or any other enclosed area.

Never obstruct the flow of ventilation air

around your gas grill housing.

Never disconnect the gas regulator or any gas

fitting while your grill is lit. A lit grill can ignite

leaking gas and cause a fire or explosion which

could result in property damage, personal in-

jury or death.

Manual # P80134004A - Date:2009/02/27

XI08ANG

Table of Contents

Need help?

Do you have a question about the XI08ALP and is the answer not in the manual?

Questions and answers

Summary of Contents for Grandhall XI08ALP

Page 1: Primary Safety Warnings
FROM THE GRILL EXPERTS Ÿ Failure to comply with these instructions could At Grand Hall we're the experts on this result in a fire or explosion that could cause product and trained to help you with: serious bodily injury, death or property dam- Ÿ...
Page 2: Table Of Contents
Patents held by Grand Hall include the following: product contain chemicals known to the State of California to cause cancer, birth defects, or other The Crossray Burner System by Grand Hall is covered reproductive harm. by Australian Patent No. 2006100635, Chinese Patent No.
Page 3: Pre-Assembly Instructions
To begin your “restaurant quality” grilling, become familiar Do not assemble or operate the grill if it appears dam- with all of the cooking elements of your Grand Hall Grill aged. If there are damaged or missing parts when you lighting and operating instructions.
Page 4: Part Diagrams And Lists
Hardware Pack Parts List for Models XI08ALP & XI08ANG PART # PART DESCRIPTION QTY PURPOSE OF PART P06030003A Hardware Pack For use in assem bly of Model XI08ALP P06030007A Hardware Pack For use in assem bly of Model XI08ANG Install Island Side Panel Bracket Assembly S125G04092 Phillips Head Screw, PT 1/4"x1-5/16"...
Page 5 Parts Diagram for Models XI08ALP & XI08ANG 8b(optional) 8b(optional) 8a(optional)
Page 6 Parts List for Models XI08ALP & XI08ANG DESCRIPTION PART# Lid Assem bly Outer P0014513A5 Protective Pad P05518018I Tem perature Gauge P00601371A Lid Handle P00215034F Lid Assem bly Inner P0014514E5 Lid Hinge P05547004D Lid Bracket P033031165 Motor Transmission P05378002B Motor/DC P07102002A...
Page 7 4. Quantity of parts needed Important: Use only Grand Hall replacement parts. The use of any part that is not a Grand Hall replacement part can be dangerous and will also void your product warranty. Keep this Operator's Manual for convenient referral and for part replacement.
Page 8: Assembly Instructions
Assembly Instructions CAUTION : To assemble this grill, you should obtain assistance from 2 people when handling the larger, heavier pieces. Install Island Side Panel Bracket Assembly Lay a piece of cardboard on the ground (refer to Pre-Assembly Instructions). With the help of your assistant, remove the Grill Head from the box and put it on the cardboard.
Page 9 Install Island Side Panel Sets Insert 2 Socket Head Cap Screws 1/4"x3/4" into the Bowl Frame Trim Panel/Left. Tighten and secure using the Wrench/M3 as shown. With your assistants, lift the Side Panel, Left/Island and slide it towards the Left Island Side Bracket Assembly.
Page 10 Flange Nut 1/4" Qty. 8 Part # S313G04062 Install Partition Panel Bracket (For XI08ALP Model) and Island Decorative Panel Install the Left Partition Panel Bracket onto the Left Island Decorative Panel using 2 Pan Head Screws 1/4"x3/8" and tighten securely.
Page 11 Socket of LCD Plug of Battery Install Partition Panel (For XI08ALP Model) Line up the fittings in the Partition Panel with the slots in the Partition Panel Brackets. From the underside of the Partition Panel, insert 4 Hex Head Screws 3/16"x3/8" and tighten securely (see diagram).
Page 12 Install the Grease Tray Heat Shield and Spark Electrode Tip Grease Tray Spark Receiver Place the 4 pins on the Grease Tray Heat Shield into the 4 Holes in the Grill Bowl as Spark Gap 1/8" shown. Pull out the Grease Tray Bracket. Place the Grease Tray into the Grease Tray Bracket as shown.
Page 13: Gas Safety And Leak Tests
Replacement regulators and hose assemblies must be those specified by Grand Hall. WARNING Have your LP Gas dealer check the relief valve after every filling to ensure it remains free of defects.
Page 14: Use & Care Instructions
USE AND CARE INSTRUCTIONS NOTE about LP Gas Tank Exchange Programs Secure a 20lb LP Gas Tank to Gas Grill Many retailers that sell grills offer you the option of replac- ing your empty LP Gas tank through an exchange service. Turn your LP Gas Tank Valve clockwise to the closed Use only those reputable exchange companies that in- or OFF positon.
Page 15 USE AND CARE INSTRUCTIONS LP Gas Model only: Check all connections for LP Gas Leaks Connect Regulator with Hose to your LP Gas Tank Never test for leaks with an open flame. Prior to first use, at the beginning of each season, or every time Turn all Burner Valves to the OFF position.
Page 16: Natural Gas Connection
Natural Gas Connection Natural Gas Model only: Fig.1 Connecting Natural Gas To Your Grill Vertical Connect the Swivel nut of the 12' Natural Gas fitting Hose to the horizontal fitting of NG Regulator as Swivel shown in Fig.1. Connect the other hose end (male plug) to the gas supply line from your home.
Page 17: Use & Care Instructions - Lcd
USE AND CARE INSTRUCTIONS - LCD LCD Functions: 1. Cooking Timer (shows cooking time remaining) 2. Grill Temperature Display (indicates temperature of grill) 3. Flame Level Detector (indicates flame level) 4. Battery Power Display (indicates how much battery power is remaining) 5.
Page 18 USE AND CARE INSTRUCTIONS - LCD Using the Temperature Probe Insert the plug of the Temperature Probe into the Temperature Control Outlet of the LCD Panel. When appears, select whether you want the temperature displayed in Celsius or Fahrenheit. Note: Do not measure the temperature of the burners by using this probe. Do not expose this probe to open flame.
Page 19: Lighting Instructions
USE AND CARE INSTRUCTIONS Grill Lighting Instructions If ignition does not occur in 5 seconds, turn gas off at Before each use, check all hoses for cracks, nicks, cuts, source and turn Control Knobs OFF. Wait at least 5 burns, or abrasions. If a hose is damaged in any way, minutes for gas to clear, then retry.
Page 20: Troubleshooting
USE AND CARE INSTRUCTIONS Troubleshooting To purge air from your gas line and/or reset the regulator excess gas flow device: If the grill fails to light : Turn Control Knobs to the OFF position. Turn gas off at source and turn Control Knobs to OFF. Wait at least 5 minutes for gas to clear, then retry.
Page 21 The use of third part accessory attachments is not damaged in any manner or cannot be safely oper- recommended by the manufacturer and may cause ated. Contact Grand Hall for replacement parts. injuries. Do not use this Rotisserie other than for its intended use.
Page 22: Rotisserie Instruction
Rotisserie Instructions Remove all components from the carton. Slide a Holding Fork onto each end of the Rotisserie Spit. Adjust spacing between Holding Forks to accommodate your food, then turn clockwise until the screw stops. Holding Forks Clockwise to Tighten Spit Note: In order to avoid damaging the holding fork, do not tighten unless it is assembled on the spit rod.
Page 23 Insert the left side of the assembled Rotisserie Spit into the Motor Transmission. Next insert the right side of the Spit into the hole on the Right Bowl Frame Panel. (See diagram below.) 5. Make sure that you have completed installation step 6 on page 11 before testing the rotisserie or turning it on. Holding Forks Spit Motor...
Page 24: Cleaning And Maintenance
CLEANING AND MAINTENANCE Cleaning Exterior Stainless Steel Surfaces: Routine care and maintenance is required to preserve Proper care and maintenance will keep your grill in top the appearance and corrosion resistance of stainless operating condition and prolong its life. Follow these clean- steel.
Page 25 Infrared Grill Cooking Instructions Burn-Off Indirect Cooking Before cooking on your gas grill for the first time, you should To cook indirectly, the food should be placed on the left "burn off" the grill to eliminate any odor or foreign matter. or right side of your grill (or Secondary Rack) with the Ignite the burners, lower the Lid, and operate grill on Burners lit on the opposite side.
Page 26 Guide to Infrared Grilling using the Direct Cooking Method Cut of Meat Approx. Total Cooking Times Grilling Steak and Ribs Fill Grease/Water Tray half-full. Turn the grill Burners on T-bone steak Rare: 4-6 minutes , close the Lid and preheat your grill 3 to 5 minutes. Sirloin steak Medium: 6-8 minutes Open Lid and place food on the mid section of a Cooking...
Page 27 Guide to Roasting & Baking using the Indirect Cooking Method An Important Note About Infrared Heat Settings Food preparation The suggested heat settings and cooking times shown are Trim meat of excess fat. Truss meat and poultry with cooking approximate. Unlike the controlled environment inside your string to retain shape if desired.
Page 28 Slow Cooking with a Rotisserie burners and smoker box. When cooking with a smoker box the Lid must be down. Your Crossray Infrared Cooking System® by Grand Hall is the ideal set-up for Rotisserie cooking because of the Tips for Smoking unique position and angle of the infrared burners.
Page 29: Retardant Bbq Mitt
Guide to Stir-Frying and Deep-Frying STIR-FRYING TECHNIQUES DEEP-FRYING TECHNIQUES This method of cooking is popular around the world and can A wide variety of foods can be deep-fried outdoors on your be easily accomplished outdoors on your gas grill. It's a quick grill, from potatoes, to seafood and chicken.
Page 30: Warning
Question: Question: Sometimes I hear a humming sound coming from my Can I convert my grill from one fuel type to another in regulator. What causes this? And - My grill has a low other words from LPG to NG or vice versa? flame and sometimes will not light.
Page 31 Question: After every use (after your grill has cooled down), wipe The Regulator and Hose supplied with my gas grill stainless surfaces with a soft, soapy cloth or sponge does not fit the older LP Gas tank I’ve used for years. then rinse with water.
Page 32 Grand Hall Limited Warranty Grand Hall will warrant to the ORIGINAL PURCHASER of this product that it will be free of defects in material and workmanship for set periods below from the date of purchase when used under normal outdoor use and...
