Grandhall TG11ALP Operator's Manual

Liquid propane gas (lpg)/natural gas (ng ) grill

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

Liquid Propane Gas (LPG) Grill

Model TG11ALP&TG11BLP

Natural Gas (NG ) Grill

Model TG11ANG&TG11BNG

FREE HELP

FROM THE GRILL EXPERTS

At Grand Hall we're the experts on this

product and trained to help you with:

Assembly questions

Grill operation

Replacement of damaged or missing parts

visit www.grandhall.com or call:

1-877-934-7455

Monday - Friday 8:00am-4:30pm CST

IMPORTANT:

NOTE TO ASSEMBLER / INSTALLER:

Leave this manual with the consumer.

NOTE TO CONSUMER:

Keep this manual for future reference.

RECORD YOUR SERIAL # __________________

(see silver CSA label on main body of grill)

Operator's Manual

WARNING

Failure to comply with these instructions could

result in a fire or explosion that could cause

serious bodily injury, death or property damage.

Whether this grill was assembled by you or

someone else, you must read this entire manual

before using your grill to ensure the grill is

properly assembled, installed and maintained.

Use your grill at least 3 feet away from any

wall or surface. Use your grill at least 3 feet

away from combustible objects that can melt or

catch fire such as vinyl or wood siding, fences and

overhangs or sources of ignition including pilot

lights on water heaters and live electrical appli-

ances.

THIS GAS APPLIANCE IS DESIGNED FOR OUT-

DOOR USE ONLY.

Never use your gas grill in a garage, porch,

shed, breezeway or any other enclosed area.

Never obstruct the flow of ventilation air

around your gas grill housing.

Never disconnect the gas regulator or any gas

fitting while your grill is lit. A lit grill can ignite

leaking gas and cause a fire or explosion which

could result in property damage, personal injury

or death.

Manual # P80151125A - Date:2011/01/04

Table of Contents

Need help?

Do you have a question about the TG11ALP and is the answer not in the manual?

Questions and answers

Summary of Contents for Grandhall TG11ALP

Page 1: Primary Safety Warnings
FROM THE GRILL EXPERTS Ÿ Failure to comply with these instructions could At Grand Hall we're the experts on this result in a fire or explosion that could cause product and trained to help you with: serious bodily injury, death or property damage.
Page 2: Table Of Contents
Grand Hall include the following: type to another is extremely hazardous and will void the warranty. Grand Hall and design®, T Grill and design®, Crossray™ Lateral Infrared Burner Technology, Command Flame®, • Keep gas regulator hose away from hot grill Smooth Start®...
Page 3: Pre-Assembly Instructions
To begin your “restaurant quality” grilling, become familiar Do not assemble or operate the grill if it appears dam- with all of the cooking elements of your Grand Hall Grill aged. If there are damaged or missing parts when lighting and operating instructions.
Page 4: Part Diagrams And Lists
PART # PART DESCRIPTION QTY PURPOSE OF PART P06029001A Hardware Pack For use in assembly of Model TG11ALP/NG & TG11BLP/NG S182G03062 Pan Head Screw 3/16" x 3/8" Attaches Side Shelves to Bowl Panel S182G03061 Pan Head Screw 3/16" x 3/8"...
Page 5 Parts Diagram for Models TG11ALP/NG & TG11BLP/NG 36 35...
Page 6 Parts List for Models TG11ALP/NG & TG11BLP/NG DESCRIPTION TG11ALP/NG PART # TG11BLP/NG PART # P0015311E4 P0015311E4 Lid Assembly Outer P0011440IK P0011440IK Lid Assembly Inner P06916001B P06916001B Lid Handle Heat Shield P06917001S P06917001S Lid Handle Heat Insulating Spacer P00213023N P00213023N Lid Handle...
Page 7 4. Quantity of parts needed Important: Use only Grand Hall replacement parts. The use of any part that is not a Grand Hall replacement part can be dangerous and will also void your product warranty. Keep this Operator's Manual for convenient referral...
Page 8: Assembly Instructions
Assembly Instructions CAUTION : To assemble this grill, you should obtain assistance from another person when handling the larger, heavier pieces. Install Casters onto Caster Seats Open Lid of shipping carton and remove some packing materials. See Fig.1. With the help of your assistant, laying down the Grill slowly.
Page 9 Assembly Instructions Install Side Shelves Raise lid and remove all packing materials. Insert the Left Side Shelf Brackets into the holes on the Left Bowl Panel. Align the 3 holes on the Left Side Shelf with the 3 holes on the Left Bowl Panel, insert 3 Pan Head Screws 3/16"x3/8"...
Page 10 Install Igniter and LED Light Controller Spark Electrode Tip Batteries Spark Gap 1/8" Remove Caps from the Electric Ignitor Bracket. Place 1 AA and 4 AAA batteries into the slots of the Electric Ignitor and LED Light Controller as shown below. (Note: The positive pole of the AA battery must face towards the cap.
Page 11: Gas Safety And Leak Tests
Replacement regulators and hose assemblies must be those specified by Grand Hall. WARNING Have your LP Gas dealer check the relief valve after every filling to ensure it remains free of defects.
Page 12: Use & Care Instructions
USE AND CARE INSTRUCTIONS NOTE about LP Gas Tank Exchange Programs LP Gas Model only: Many retailers that sell grills offer you the option of replac- Secure a 20lb LP Gas Tanks to Gas Grill ing your empty LP Gas tank through an exchange service. Use only those reputable exchange companies that in- Turn your LP Gas Tank Valve clockwise to the spect, precision fill, test, and certify their tanks.
Page 13 USE AND CARE INSTRUCTIONS Check all connections for LP Gas Leaks LP Gas Model only: Connect Regulator with Hose to your LP Gas Tank Never test for leaks with an open flame. Prior to first use, at the beginning of each season, or every time Turn all Burner Valves to the OFF position.
Page 14: Natural Gas Connection
Natural Gas Connection Natural Gas Model only: Connecting Natural Gas To Your Grill Fig.1 Connect the Swivel nut of the 12' Natural Gas Hose to the horizontal fitting of NG Regulator as shown in Fig.1. Connect the other hose end (male Hose, 12 ft./ NG plug) to the gas supply line from your home.
Page 15: Lighting Instructions
USE AND CARE INSTRUCTIONS Grill Lighting Instructions Before each use, check all hoses for cracks, nicks, cuts, 7. If ignition does not occur in 5 seconds, turn gas off at burns, or abrasions. If a hose is damaged in any way, source and turn Control Knobs OFF.
Page 16: Troubleshooting
USE AND CARE INSTRUCTIONS Troubleshooting To purge air from your gas line and/or reset the regulator excess gas flow device: If the grill fails to light : Turn Control Knobs to the OFF position. Turn gas off at source and turn Control Knobs to OFF. Wait at least 5 minutes for gas to clear, then retry.
Page 17: Cleaning And Maintenance
CLEANING AND MAINTENANCE Cleaning Exterior Stainless Steel Surfaces: Routine care and maintenance is required to preserve Proper care and maintenance will keep your grill in top the appearance and corrosion resistance of stainless operating condition and prolong its life. Follow these clean- steel.
Page 18 Infrared Grill Cooking Instructions Burn-Off Indirect Cooking Before cooking on your gas grill for the first time, you To cook indirectly, the food should be placed on the left should "burn off" the grill to eliminate any odor or foreign or right side of your grill (or Secondary Rack) with the matter.
Page 19 Guide to Infrared Grilling using the Direct Cooking Method Cut of Meat Approx. Total Cooking Times Grilling Steak and Ribs Turn the grill Burners on , close the Lid and preheat your T-bone steak Rare: 4-6 minutes grill 3 to 5 minutes. Open Lid and place food on the mid Sirloin steak Medium: 6-8 minutes section of a Cooking Grid.
Page 20 Guide to Roasting & Baking using the Indirect Cooking Method An Important Note About Infrared Heat Settings Food preparation The suggested heat settings and cooking times shown are Trim meat of excess fat. Truss meat and poultry with cooking approximate. Unlike the controlled environment inside your string to retain shape if desired.
Page 21 Guide to Stir-Frying and Deep-Frying STIR-FRYING TECHNIQUES DEEP-FRYING TECHNIQUES This method of cooking is popular around the world and can A wide variety of foods can be deep-fried outdoors on your be easily accomplished outdoors on your gas grill. It's a quick grill, from potatoes, to seafood and chicken.
Page 22 Question: Question: Sometimes I hear a humming sound coming from my Can I convert my grill from one fuel type to another in regulator. What causes this? And - My grill has a low other words from LPG to NG or vice versa? flame and sometimes will not light.
Page 23 Question: After every use (after your grill has cooled down), wipe The Regulator and Hose supplied with my gas grill stainless surfaces with a soft, soapy cloth or sponge does not fit the older LP Gas tank I’ve used for years. then rinse with water.
Page 24 Grand Hall Limited Warranty Grand Hall will warrant to the ORIGINAL PURCHASER of this product that it will be free of defects in material and workmanship for set periods below from the date of purchase when used under normal outdoor use...
