Grandhall OD3208SLP Operator's Manual

Liquid propane/natural gas grill
Hide thumbs
Table of Contents

Advertisement

Quick Links

Liquid Propane Gas (LPG) Grill
Model OD3208SLP
Natural Gas (NG ) Grill
Model OD3208SNG
FREE HELP
FROM THE GRILL EXPERTS
Grand Hall is the expert on this product and
trained to help you with:
Ÿ
Assembly Questions
Ÿ
Grill Operation
Ÿ
Replacement of Damaged or Missing parts
visit www.grandhall.com or call:
1-877-934-7455
Monday - Friday 8:00am-4:30pm CST
IMPORTANT:
Ÿ
NOTE TO ASSEMBLER / INSTALLER:
Leave this manual with the consumer.
Ÿ
NOTE TO CONSUMER:
Keep this manual for future reference.
Ÿ
RECORD YOUR SERIAL # __________________
(see silver CSA label on main body of grill)
Model OD3208SLP/NG
WARNING
!
Ÿ
Failure to comply with these instructions could
result in a fire or explosion that could cause
serious bodily injury, death or property damage.
Ÿ
Whether this grill was assembled by you or
someone else, you must read this entire manual
before using your grill to ensure the grill is
properly assembled, installed and maintained.
Ÿ
Use your grill at least 3 feet away from any
wall or surface. Use your grill at least 3 feet
away from combustible objects that can melt or
catch fire such as vinyl or wood siding, fences and
overhangs or sources of ignition including pilot
lights on water heaters and live electrical appli-
ances.
Ÿ
THIS GAS APPLIANCE IS DESIGNED FOR OUT-
DOOR USE ONLY.
Ÿ
Never use your gas grill in a garage, porch,
shed, breezeway or any other enclosed area.
Ÿ
Never obstruct the flow of ventilation air
around your gas grill housing.
Ÿ
Never disconnect the gas regulator or any gas
fitting while your grill is lit. A lit grill can ignite
leaking gas and cause a fire or explosion which
could result in property damage, personal injury
or death.
Manual # P80151095A - Date:2009/04/02
Operator's Manual
!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OD3208SLP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Grandhall OD3208SLP

Summary of Contents for Grandhall OD3208SLP

  • Page 1: Primary Safety Warnings

    FROM THE GRILL EXPERTS Ÿ Failure to comply with these instructions could Grand Hall is the expert on this product and result in a fire or explosion that could cause trained to help you with: serious bodily injury, death or property damage.

  • Page 2: Table Of Contents

    Patents held by Grand Hall include the following: serious bodily injury, death or property damage. The Crossray Burner System by Grand Hall is covered • The Grease/W ater Tray must be visually inspected by Australian Patent No.

  • Page 3: Pre-Assembly Instructions

    To begin your “restaurant quality” grilling, become familiar with all of the cooking elements of your Grand Hall Grill light- Do not assemble or operate the grill if it appears dam- ing and operating instructions.

  • Page 4: Part Diagrams And Lists

    Hardware Pack Parts List for Models OD3208SLP & OD3208SNG PART # PART DESCRIPTION PURPOSE OF PART P06030008A Hardware Pack For use in assembly of Models OD3208SLP P06030009A Hardware Pack For use in assembly of Models OD3208SNG S182G03061 Pan Head Screw 3/16"x3/8"...
  • Page 5 Parts Diagram for Models OD3208SLP & OD3208SNG...
  • Page 6 Parts List for Models OD3208SLP & OD3208SNG DESCRIPTION PART# Lid Assem bly P0014734AA Tem perature Gauge P00601381A Lid Handle Bracket, Left P00307028E Lid Handle Bracket, Right P00308028E Lid Handle P00215036H Bowl Panel, Rear/Lower P0075803BC Lid Assem bly Bracket, Left P03320007C...
  • Page 7 4. Quantity of parts needed Important: Use only Grand Hall replacement parts. The use of any part that is not a Grand Hall replace- ment part can be dangerous and will also void your product warranty. Keep this Operator's Manual for...

  • Page 8: Assembly Instructions

    Assembly Instructions CAUTION : While it is possible for one person to assemble this grill, obtain assistance from another person when handling some of the larger, heavier pieces. CAUTION: Build your grill island before installing the LP Gas Tank and Partition Panel (Not included in this unit).
  • Page 9 Manifold Swivel Nut Install LP Gas Tank (For OD3208SLP Model) Install the Bracket with Regulator onto the Island Side Panel using 2 Pan Head Screws 3/16"x3/8". Install the Stainless Steel Tube (not included in this unit) onto the manifold. Next, insert the other end of the Stainless Steel Tube through the hole on the Island Side Panel.
  • Page 10 Install Partition Panel (For OD3208SLP Model) Install the Partition Panel (not included in this unit) onto the left island. Make sure there is 22-24" of clearance between the Partition Panel and the Tank Tray Set. 1/8" Partition Panel (Above the Gas Tank) 5"...

  • Page 11: Lp Gas Tank Installation

    Grand Hall. Refer to this table when designing the island unit for the OD3208SLP/NG. Side* and Rear* show the mini- Have your LP Gas dealer check the release valve after mum amount of distance the unit must be from every filling to ensure it remains free of defects.
  • Page 12 Do not use household cleaning agents. Damage to gas Every ventilation opening must be a minimum of 1/ assembly components can result. 8". (See Fig. 4 on page 9). Please ask a Grand Hall associate for full details. Ÿ Use a clean paintbrush and a 50/50 mild soap and Fig.
  • Page 13 USE AND CARE INSTRUCTIONS LP Gas Model only: Check all connections for LP Gas Leaks Connect Regulator with Hose to your LP Gas Tank Never test for leaks with an open flame. Prior to first use, at the beginning of each season, or every time Turn all Burner Valves to the OFF position.

  • Page 14: Natural Gas Connection

    Natural Gas Connection Natural Gas Model only: Gas Line Piping: Connecting Natural Gas To Your Grill If the length of line required does not exceed 50 feet, Connect the Swivel nut of the 12' Natural Gas use a 5/8" O.D. tube. One size larger should be used Hose to the horizontal fitting of NG Regulator as for lengths greater than 50 feet.

  • Page 15: Use & Care Instructions

    USE AND CARE INSTRUCTIONS Grill Lighting Instructions Before each use, check all hoses for cracks, nicks, cuts, burns, or abrasions. If a hose is damaged in any way, do not use your grill before replacing the hose with an authorized part from the Parts List. Also make sure all gas supply connections are securely tightened.

  • Page 16: Troubleshooting

    USE AND CARE INSTRUCTIONS Troubleshooting To purge air from your gas line and/or reset the regulator excess gas flow device: If the grill fails to light : Turn Control Knobs to the OFF position. Turn gas off at source and turn Control Knobs to OFF.

  • Page 17: Cleaning And Maintenance

    CLEANING AND MAINTENANCE Cleaning Exterior Stainless Steel Surfaces: Routine care and maintenance is required to preserve Proper care and maintenance will keep your grill in top operat- the appearance and corrosion resistance of stainless ing condition and prolong its life. Follow these cleaning proce- steel.

  • Page 18: Retardant Bbq Mitt

    Infrared Grill Cooking Instructions Indirect Cooking Burn-Off Before cooking on your gas grill for the first time, you To cook indirectly, the food should be placed on the should "burn off" the grill to eliminate any odor or foreign left or right side of your grill (or Secondary Rack) with the matter.
  • Page 19 Guide to Infrared Grilling using the Direct Cooking Method Cut of Meat Approx. Total Cooking Times Grilling Steak and Ribs Fill Grease/Water Tray half-full. Turn the grill Burners on T-bone steak Rare: 4-6 minutes close the Lid and preheat your grill 3 to 5 minutes. Open Lid Sirloin steak Medium: 6-8 minutes and place food on the mid section of a Cooking Grid.

  • Page 20: Retardant Bbq Mitt

    Guide to Roasting & Baking using the Indirect Cooking Method Food preparation An Important Note About Infrared Heat Settings Trim meat of excess fat. Truss meat and poultry with cooking The suggested heat settings and cooking times shown are approximate. Unlike the controlled environment inside your string to retain shape if desired.

  • Page 21: Retardant Bbq Mitt

    Guide to Stir-Frying and Deep-Frying DEEP-FRYING TECHNIQUES STIR-FRYING TECHNIQUES A wide variety of foods can be deep-fried outdoors on your This method of cooking is popular around the world and can grill, from potatoes, to seafood and chicken. Deep-frying be easily accomplished outdoors on your gas grill. It's a quick uses a large portion of oil, preferably saturated.

  • Page 22: Warning

    Question: Question: Sometimes I hear a humming sound coming from my Can I convert my grill from one fuel type to another in regulator. What causes this? And - My grill has a low other words from LPG to NG or vice versa? flame and sometimes will not light.
  • Page 23 Question: After every use (after your grill has cooled down), wipe The Regulator and Hose supplied with my gas grill stainless surfaces with a soft, soapy cloth or sponge does not fit the older LP Gas tank I’ve used for years. then rinse with water.
  • Page 24 Grand Hall Limited Warranty Grand Hall will warrant to the ORIGINAL PURCHASER of this product that it will be free of defects in material and workmanship for set periods below from the date of purchase when used under normal outdoor use...
