Grandhall CSTS13ALP Operator's Manual

Liquid propane gas (lpg) grill
Hide thumbs

Advertisement

Quick Links

Download this manual
Liquid Propane Gas (LPG) Grill
Model CSTS13ALP
FREE HELP
Grill Information Center:
FROM THE GRILL EXPERTS
Do not return to the store. At Grand Hall
we're the expert on this product and trained
to help you with:
Ÿ
Assembly Questions
Ÿ
Grill Operation
Ÿ
Replacement of Damaged or Missing parts
visit www.grandhall.com or call:
1-800-761-5456
Monday - Friday 8:00am-4:30pm CST
IMPORTANT:
Ÿ
NOTE TO ASSEMBLER / INSTALLER:
Leave this manual with the consumer.
Ÿ
NOTE TO CONSUMER:
Keep this manual for future reference.
Ÿ
RECORD YOUR SERIAL #
__________________
(see CSA label on main body of grill)
Operator's Manual
WARNING
!
Ÿ
Failure to comply with these instructions could
result in a fire or explosion that could cause
serious bodily injury, death or property damage.
Ÿ
Whether this grill was assembled by you or
someone else, you must read this entire manual
before using your grill to ensure the grill is
properly assembled, installed and maintained.
Ÿ
Use your grill at least 3 feet away from any
wall or surface. Use your grill at least 3 feet
away from combustible objects that can melt or
catch fire such as vinyl or wood siding, fences
and overhangs or sources of ignition including
pilot lights on water heaters and live electrical
appliances.
Ÿ
THIS GAS APPLIANCE IS DESIGNED FOR OUT-
DOOR USE ONLY.
Ÿ
Never use your gas grill in a garage, porch,
shed, breezeway or any other enclosed area.
Ÿ
Never obstruct the flow of ventilation air
around your gas grill housing.
Ÿ
Never disconnect the gas regulator or any gas
fitting while your grill is lit. A lit grill can ignite
leaking gas and cause a fire or explosion which
could result in property damage, personal injury
or death.
Manual #
!
P80170024D - Date:2014/12/15

Advertisement

loading
Need help?

Need help?

Do you have a question about the CSTS13ALP and is the answer not in the manual?

Questions and answers

Related Manuals for Grandhall CSTS13ALP

Summary of Contents for Grandhall CSTS13ALP

  • Page 1 Replacement of Damaged or Missing parts properly assembled, installed and maintained. Ÿ Use your grill at least 3 feet away from any visit www.grandhall.com or call: wall or surface. Use your grill at least 3 feet away from combustible objects that can melt or 1-800-761-5456...

  • Page 2: Table Of Contents

    Table of Contents WARNING Primary Safety Warnings......1-3 Pre-Assembly Instructions........3 Do not store or use gasoline or other Part Diagrams and Lists......4-8 flammable liquids or vapors in the Assembly Instructions.........9-11 vicinity of this or any other appli- Use & Care Instructions: ances.

  • Page 3: Pre-Assembly Instructions

    Pre-Assembly Instructions For Your Safety PRE-ASSEMBLY CAUTION Read and perform the following pre-assembly instruc- tions: Failure to comply with these instructions may result Tools Required for Assembly in a hazardous situation which, if not avoided, may • protective work gloves result in injury.
  • Page 4 Hardware Pack Parts List for Models CSTS13ALP PART # PART DESCRIPTION PURPOSE OF PART P06024015A Hardware Pack For use in assem bly of Model CSTS13ALP S112G04081 Phillips Head Screw 1/4"x1/2" Attach side shelf and side burner to Grill bowl S313G04081 Flange Nut 1/4"...
  • Page 5 Parts Diagram for Models CSTS13ALP 14_2 14_1 16_2 16_1 32_1 32_2 32_3 60 62...
  • Page 6 Parts List for Model CSTS13ALP DESCRIPTION PART# Lid Assembly P00147496A Temperature Gauge P00601071A Name Plate P00407006S Lid Handle Bracket, Left P03303124A Lid Handle Bracket, Right P03303125A Lid Handle Heat Insulating Spacer P06802007A Lid Handle P00218002R Protective Pad P05518002I Lid Hinge...
  • Page 7 Natural gas conversion kit Natural gas 12’ hose Part #Y0440050 Part #P3718A The CSTS13ALP can be converted to If you are converting your Grill natural gas with this natural gas kit to natural gas, in most cases and a qualified gas technician only. In...
  • Page 8 Rotisserie Assembly Parts Diagram Rotisserie Assembly Parts List PART# DESCRIPTION P05508177F Rot. Collar S196G04084 Rot. Thumbscrew 1/4"x1/2" P05508203F Rot. Spit P05508023F Rot. Holding Fork P05508174F Rot. Motor Bracket P07101039B Rot. Motor/AC S112G10124 Rot. Screw#10-24x3/4"UNC S411G03084 Rot. Washer 3/16" S362G10124 Rot. Nut #10-24 Hardware for Rotisserie Rot.

  • Page 9: Assembly Instructions

    Assembly Instructions for CSTS13ALP CAUTION : To assemble this grill, you should obtain assistance from another person when handling the large, heavy pieces. Install Temperature Gauge onto the Grill Lid Open the Lid. Remove the Wing Nut and Toothed Washer from the Temperature Gauge.
  • Page 10 Connect the Side Burner Connection Hose Push back Sleeve of the Socket. See Figure A. Insert Plug then release Sleeve. See Figure B. Push Plug until sleeve snaps forward locking the Plug into the Socket. See Figure C. Push the Side Burner Hose into hose holders. Figure A PLUG SOCKET...
  • Page 11 Main Burner Electrode check Install Cooking Components With the assistance of another person, Place the Flame Tamer Rack inside the Grill Bowl. perform this Electrode Check before Position it onto the lower ledge of the Bowl above proceeding. the burners. Next, place the Flame Tamers on the This test will ensure that the Spark Electrode Tips Flame Tamer Rack.

  • Page 12: Use & Care Instructions

    USE AND CARE INSTRUCTIONS Use of alcohol, prescription or non-prescription drugs CORRECT LP GAS TANK USE can impair your ability to properly assemble and LP Gas grill models are designed for use with a standard safely operate your grill. 20 lb. Liquid Propane Gas (LP Gas) tank (sold sepa- rately).
  • Page 13 USE AND CARE INSTRUCTIONS NOTE about LP Gas Tank Exchange Programs LP Gas Model only: Secure a 20lb LP Gas Tank to Gas Grill Many retailers who sell grills offer you the option of replacing your empty LP Gas tank through an exchange Turn your LP Gas Tank Valve clockwise to the closed service.
  • Page 14 USE AND CARE INSTRUCTIONS LP Gas Model only: Check all connections for LP Gas Leaks Connect Regulator with Hose to your LP Gas Tank Never test for leaks with an open flame. Prior to first use, at the beginning of each season, or every time Turn all Burner Valves to the OFF position.
  • Page 15 USE AND CARE INSTRUCTIONS Grill Lighting Instructions Before each use, check all hoses for cracks, nicks, cuts, burns or abrasions. If a hose is damaged in any way, do not use your grill before replacing the hose with an authorized part from the Parts List. Also make sure all Infrared Main Burner Rotisserie...

  • Page 16: Lighting Instructions

    USE AND CARE INSTRUCTIONS TROUBLESHOOTING Manually Lighting Your Grill By Paper Match If the grill fails to light : To light your gas grill by match, insert a match into the Lighting Stick and follow steps 1 through 5 of the Grill Turn gas off at source and turn Control Knobs to OFF.
  • Page 17 USE AND CARE INSTRUCTIONS CORRECT ROTISSERIE USE ELECTRICAL EQUIPMENT USE Read all instructions before initial use. To protect against electric shock, do not immerse cord or IMPORTANT: When using electrical appliances, basic safety plugs in water or other liquid. precautions should always be used. The Rotisserie Motor is set for 120V, 60Hz AC current.

  • Page 18: Rotisserie Instruction

    Rotisserie Instructions 1. Remove all components from the carton. Attach the Motor Bracket on the outside of the right grill bowl panel. Align the two holes of the Bracket with the holes on the grill bowl. Tighten securely using two Screws #10-24x3/4" UNC, Plain Washers and Nuts provided.
  • Page 19 Install the AC (alternating current) Rotisserie Motor onto the Motor Bracket as shown below. Be sure the Motor attaches to the Bracket with the electrical cord down. This installation insures that once the Spit is inserted into the Motor it will also rest securely into the slot of your grill bowl. Rotisserie Motor Rotisserie Spit must rest securely into the slot of your grill bowl.

  • Page 20: Cleaning And Maintenance

    Cleaning Exterior Stainless Steel Surfaces: CLEANING AND MAINTENANCE Routine care and maintenance is required to preserve Proper care and maintenance will keep your grill in top operating the appearance and corrosion resistance of stainless condition and prolong its life. Follow these cleaning procedures steel.
  • Page 21 2. 2. CLEANING THE BURNER TUBES AND BURNER PORTS To reduce the chance of FLASHBACK FIRE you must clean Regardless of which Burner cleaning procedure you use, we recommend that you also complete the follow- the Burner Tubes as follows at least once a month in ing cleaning regimens to help prolong Burner life.
  • Page 22 Cooking Instructions Burn-Off Indirect Cooking using Main Burners Before cooking on your gas grill for the first time, you The indirect cooking method can also be used with the should "burn off" the grill to eliminate any odor or foreign supplied Cooking Grids.
  • Page 23 Guide to Grilling using the Main Burners and Direct Cooking Method Approximate Cooking Times Grilling Steak and Ribs Cut of Meat Rare: 4-8 minutes Turn the grill Burners on IGN/HIGH, close the Lid and preheat T-bone steak Medium: 10-14 minutes your grill 10 to 15 minutes.
  • Page 24 Guide to Searing using the Infrared Cooking Zone • Important notes about using the Infrared Burner Once lit, leave the Infrared Burner on High and sear both sides of meat using the guidelines below. Whether you are a seasoned chef or a newcomer to gas •...
  • Page 25 Guide to Roasting and Baking Using the Main Burners Food preparation An Important Note About Heat Settings Trim meat of excess fat. Truss meat and poultry with cooking The suggested heat settings shown are approximate. There string to retain shape if desired. Bacon strips can be used to are many factors such as outside temperature, wind condi- cover the outside surface of lean meat and poultry to help tions and grill location that affect your grill performance.
  • Page 26 Guide to Rotisserie Cooking Guide to Smoking Preparing to Smoke Slow Cooking with a Rotisserie Smoking gives food a distinctive, delicious flavor. You will find Rotisserie cooking produces foods that are moist, flavor- a variety of wood chips available for use in smoking grilled ful and attractive.
  • Page 27 Question: Question: Can I convert my grill from one fuel type to another Sometimes I hear a humming sound coming from my in other words from LPG to NG? regulator. What causes this? And - My grill has a low flame and sometimes will not light.
  • Page 28 To help main- tain the finish of stainless steel follow these cleaning pro- cedures for the best results: You may also review FAQ , Troubleshooting and Care & Maintenance Tips online at www.grandhall.com.
  • Page 29 All remaining parts - 2 Year Limited Warranty Grand Hall will require reasonable proof of your date of purchase. Therefore, you should send in the owner registration card or register online at www.grandhall.com. Save your receipt in case it is required as proof of purchase.
