Access to the parameter menu enabling
modification of the system operation.
The settings menu for the parameters of
rotation speed.
Settings of the motor rotation speed:
When the diesel motor is running, and with
the aid of a tachometer, (not provided), the
actual speed must be entered in order to
set parameters for the controller.
Once the preceding action has finished,
validate the procedure by selecting "start"
from the menu, which will automatically
return to "finished".
Minimum rotation speed from which the
controller deems that the "motor is in
operation".
The parameter menu for all timer
parameters influencing the operation.
English
100 ... 3000 ... 4000
Finished
Start
200 ... 800 ... 3000
