5 Product information

5.1 Type key
Example:
W
CTRL
SC
F
1x
(2)
M
FM
ND
D
FR
Table 1 - Type key
5.2 Technical data (standard execution)
Technical data
Mains connection voltage [V]:
Frequency [Hz]:
Control voltage [V]:
Absorbed current max [A]:
Protection class:
Fuse protection max on mains side [A]:
Room temperature [°C]:
Electrical safety:
Alarm/signal contact:
Table 2 - Technical data
5.3 Scope of delivery
• Switchgear
• Circuit diagram
• Installation and operating Instructions
• Check log in accordance with EN 60204-1
5.4 Accessories
WILO SE 11/2016
W-CTRL-SC-F-1x(2)KW-M-FM-ND-D-FR
W = WILO
Operation
Smart Control = Control unit
F = Fire fighting application
Number of pumps
Rated power range of the diesel motor [kW]:
4.25 – 47.7 kW
66 – 145 kW
197 – 246 kW
Power supply: 1 x 230 V/50 Hz
Frame mounted
New design of the electrical/control cabinet
Diesel cabinet
France – box conforms to A2P
1~230 V (L, N, PE)
50/60 Hz
12/24 V DC
See the rating plate
IP44
See circuit diagram
0 °C to +50 °C
Pollution degree II
250 V AC, 1 A
English
