Key Lock - ProLights SmartBat Plus User Manual

SMARTBATPLUS
12

3.13 KEY LOCK

Enter the Key Lock mode to select whether the access password is on or off.
• Press the button MODE so many times until show Key Lock and press the button ENTER to confirm.
• Use UP/DOWN button to select: ON or OFF.
• Press ENTER button to confirm the selection.
When the fixture is set as pass ON, after 30 seconds or turn on the fixture next time, the fixture will need
an access password to enter the display menu control.
NOTE - The factory access password is UP + DOWN + UP + DOWN (press ENTER to confirm the access)
DMX Busy DMX
Start address Next possible start address Next possible start address Next possible start address
Channels address
(example) for unit n°1 for unit n°2 for unit n°3
number
4 33 33-36 37 41 45
DMX512 Controller
wireless
solution
4 channels DMX configuration example
Fig.7
