TRENDnet User's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PoE Web Smart Switch Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TRENDnet PoE Web Smart Switch Series

Summary of Contents for TRENDnet PoE Web Smart Switch Series

  • Page 1 Cover Page TRENDnet User’s Guide...

  • Page 2: Table Of Contents

    Table of Contents TRENDnet User’s Guide Thank you for purchasing your new TRENDnet PoE Contents PoE Web Smart Switch Series Product Overview ......i Web Smart Switch! TPE-082WS Overview ...................... i Package Contents ....................i TPE-082WS Hardware Features ................i TPE-1620WS v2 &...
  • Page 3 Telnet ........................... 21 Instance ......................44 MST Port ......................45 Enable Telnet management access..............21 Trunk ..........................46 DHCP Auto Configuration .................... 22 Settings ......................46 Enable DHCP Auto Configuration............... 22 Status ......................... 47 © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 4 Egress Rate Limiting ................... 59 Set CoS priority settings ..................76 VLAN ..........................60 Port Priority ......................... 77 Tagged ....................... 60 Set Port Priority ....................77 Port ........................61 DSCP ..........................77 Forwarding ......................62 © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 5 Using the Web Smart Switch Management Utility ....... 105 DHCP Snooping ......................89 System Requirements ....................105 Settings ......................89 VLAN ........................90 Installation ......................... 105 Interfaces ......................91 Using the Utility ......................106 Binding ....................... 92 © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 6 Monitor List ..................... 107 Device Setting ....................108 Main Menu Options ..................109 Hardware Features and Specifications ......... 110 Web Smart Switch Series Software Specifications ......112 Quick Installation GuideTroubleshooting ........114 Appendix ..................115 © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 7: Poe Web Smart Switch Series Product Overview

    PoE Web Smart Switch Series TRENDnet User’s Guide TPE-082WS Hardware Features PoE Web Smart Switch Series Product Overview TPE-082WS Overview Front View Rear View TPE-082WS Package Contents In addition to your switch, the package includes:  Reset Button – Press and hold the button 1~5 seconds and release to ...
  • Page 8 1Gbps speed. Amber : When the LED is blinking amber, the port is transmitting Blinking or receiving data on the network at 10/100Mbps speed. When the LED is off, the respective port is disconnected. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 9: Tpe-1620Ws V2 & Tpe-1620Wsf Overview

    SFP slots 17F-20F and are disabled when SFP slots (17F- retailer, or reseller/distributor from which the product was purchased. 20F) are in use.  SFP Slots (17F-20F) – Supports optional 1000BASE-SX/LX mini-GBIC modules for uplink or downlink connections. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 10 : When the Green LED is on, the respective port is Green connected to a 1Gbps Ethernet network. Amber : When the Green LED lights on, the respective port is connected to a 10/100Mbps Ethernet network. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 11: Tpe-2840Ws V2 Overview

    SFP slots 25F-28F and are disabled when SFP slots (25F- 28F) are in use.  SFP Slots (25F-28F) – Supports optional 1000BASE-SX/LX mini-GBIC modules for uplink or downlink connections. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 12 Link/Activity button Mode : When the Green LED is on, the respective port is Green connected to a 1Gbps Ethernet network. Amber : When the Green LED lights on, the respective port is © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 13: Tpe-5028Ws Overview

    Gigabit Ethernet Ports (25-28) – Connect network devices. Ports 25-28 are shared with SFP slots 25F-28F and are disabled when SFP slots (25F- 28F) are in use.  SFP Slots (25F-28F) – Supports optional 1000BASE-SX/LX mini-GBIC modules for uplink or downlink connections. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 14 100Mbps link established.  Gigabit Ethernet Port LEDs (1-28) No link established.  Link/Activity button Mode Green : When the Green LED is on, the respective port is connected to a 1Gbps Ethernet network. © Copyright 2018 TRENDnet. All Rights Reserved. viii...

  • Page 15: Tpe-5240Ws Overview

    Gigabit Ethernet Ports (49-52) – Connect network devices. Ports 49-52 are shared with SFP slots 49F-52F and are disabled when SFP slots (49F- 52F) are in use.  SFP Slots (49F-52F) – Supports optional 1000BASE-SX/LX mini-GBIC modules for uplink or downlink connections. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 16 : When the Green LED is on, the respective port is connected to a 1Gbps Ethernet network. Amber : When the Green LED lights on, the respective port is connected to a 10/100Mbps Ethernet network. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 17: Tpe-5048Ws Overview

    SFP slots 49F-52F and are disabled when SFP slots (49F- 52F) are in use.  SFP Slots (49F-52F) – Supports optional 1000BASE-SX/LX mini-GBIC modules for uplink or downlink connections. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 18 : When the Green LED is on, the respective port is connected to a 1Gbps Ethernet network. Amber : When the Green LED lights on, the respective port is connected to a 10/100Mbps Ethernet network. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 19: Switch Installation

     When installing the Switch on a level surface, attach the rubber feet to the bottom of each device. The rubber feet cushion the hub and protect the hub case from scratching. Then, use screws provided with the equipment rack to mount each switch in the rack. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 20: Basic Ip Configuration

    192.168.10.x (e.g. 192.168.10.25) and a subnet mask of 255.255.255.0. 4. Open your web browser, and type the IP address of the switch in the address bar, and then press Enter. The default IP address is 192.168.10.200. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 21 2. Select the Config you would like to save the settings to, click Save Settings to Flash, then click OK. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 22: Connect Additional Devices To Your Switch

    Note: If you encounter issues connecting to your network, there may be a problem with your computer or device network settings. Please ensure that your computer or device network settings (also called TCP/IP settings) are configured properly within the network subnet your switch is connected. Note: Your switch model may be different than the one shown in the example illustrations. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 23: Accessing Switch Management Interfaces

    User Name: admin Password: admin Note: User Name and Password are case sensitive. Hardware Information  DRAM Size: Displays your switch RAM memory size.  Flash Size: Displays your switch Flash memory size. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 24  Subnet Mask – Displays the current IPv4 subnet mask assigned to your switch. DHCP client.  Default Gateway – Displays the current gateway address assigned to your switch.  IPv6 DHCP Client Mode: Displays if your switch IPv6 address setting is set to DHCP client. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 25: System

     System Contact - Specifies the name of the network administrator responsible for managing the switch. This contact name is optional and may contain up to 30 characters. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 26: L3 Feature

    7. Select the Config you would like to save the settings to, click Save Settings to Flash, then click OK. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 27: Ipv4 Arp Aging Time

    5. Select the Config you would like to save the settings to, click Save Settings to Flash, then click OK. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 28: Ipv4 Static/Default Route

     Next Hop IP Address: Enter the next hop for the routing entry. (e.g 192.168.20.200)  Backup Status: Specify if this routing entry is to be the Primary or Backup entry. Note: If this assigning the default gateway IP address, select Primary. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 29: Set Your Ipv6 Settings

    IPv6 Address: Enter the full IPv6 address you would like to specify for this Interface VLAN field and then click Find. connection. 4. To change the IPv6 IP address associated with a specific VLAN, click on Detail within the lower table. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 30: Add Ipv6 Neighbors

    Delete or delete the address. If the entries span multiple pages, you can navigate page number in the Page field and click Go or you can click First, Previous, Next, and Last Page to navigate the pages. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 31: Configure Ipv6 Routing Table

    5. Select the Config you would like to save the settings to, click Save Settings to Flash, then click OK. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 32: Dns

    5. Select the Config you would like to save the settings to, click Save Settings to Flash, then click OK. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 33: Ip Access List

    Delete All to delete all entries in the table. When you have completed entering the IPv4 and IPv6 address entries, click the IP Restriction Status drop-down list at the top and select Enabled, then click Apply. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 34: Administration

    In the Password field, enter the new password and enter the new password again the switch is rebooted or power cycled, the configuration changes will still be applied. Confirm Password field to verify. Then, click Apply. Note: The password consists of up to 20 alphanumeric characters. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 35: Timeout

    Local Time – Allows you to manually set the time settings. If selecting this option, under Local Time Settings, manually enter your date and time settings.  Date Settings – Enter your date settings (YYYY/MM/DD).  Time Settings – Enter your time settings (HH:MM:SS) © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 36 Additional Time Parameters – Allows you to configure additional Daylight Saving Time parameters.  Daylight Savings Time Status: Click the drop-down list to enable or disable Daylight Savings.  From: Set the daylight savings start date and time. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 37: Ssl

    Disabled – Disabled HTTPS/SSL management access and enabled HTTP unsecured mode. (Default setting). If enabling SSL management access, you will need to access the switch management page using HTTPS instead of HTTP. (e.g. https://192.168.10.200) © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 38: Ssh

    Enabled – Enables SSH management access. Disabled – Disabled SSH management access.  Port: Set the port number to use for SSH management access 4. At the bottom of the left hand panel, click Save. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 39: Telnet

    Enabled – Enables Telnet management access. Disabled – Disabled Telnet management access.  Port: Set the port number to use for Telnet management access 4. At the bottom of the left hand panel, click Save. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 40: Dhcp Auto Configuration

    2. Click on System, and click on DHCP Auto Configuration. 3. Click the Auto Configuration State drop-down list and select Enabled. Click Apply to save changes. 4. At the bottom of the left hand panel, click Save. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 41: System Log

     1 Alert - Action must be taken immediately.  2 Critical - Critical conditions are displayed.  3 Warning - Warning conditions are displayed.  4 Info - Informational messages are displayed. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 42: Snmp

    Enabled - When you enable this parameter, the SNMP agent is active. You can manage the switch with SNMP network management software and the switch’s private MIB. Disabled - When you enable this parameter, the SNMP agent is inactive. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 43: View

    Excluded: This selection blocks the view of the specified MIB object. then click OK. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 44: Group

    AuthPriv: When the Auth-Protocol or Priv-Protocol have been 5. Select the Config you would like to save the settings to, click Save Settings to Flash, enabled, choose this selection. then click OK.  Click the Add button. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 45: User

    5. Select the Config you would like to save the settings to, click Save Settings to Flash, then click OK. none - Specifies no encryption is applied to SNMP data. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 46: Community

    Click Add. The values of the new Community Name and User Name are then click OK. displayed. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 47: Trap

    5. Select the Config you would like to save the settings to, click Save Settings to Flash, then click OK. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 48: Rmon

    5). 2. Click on System, click on RMON and click on Settings. 3. Click the RMON Status drop-down list and select Enabled to enable RMON. Click Apply to save settings. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 49: Statistics

    Click Add to add the entry to the table. then click OK. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 50: History

    Note: This step saves all configuration changes to the NV-RAM to ensure that if the primarily intended for switches that are managed by more than one person, switch is rebooted or power cycled, the configuration changes will still be applied. and is an optional field. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 51: Alarms

     Owner: This parameter is used to identify the person who created an entry. It is primarily intended for switches that are managed by more than one person, and is an optional field. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 52: Events

    5. At the bottom of the left hand panel, click Save. 6. Select the Config you would like to save the settings to, click Save Settings to Flash, then click OK. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 53 Page field and click Go or you can click First, Previous, Next, and Last Page to navigate the pages. 4. At the bottom of the left hand panel, click Save. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 54: Statistics

    OutDiscards: Outbound Discards (Pkts), number of outbound discarded packets.  Apply: Click the Apply button to clear port specific Traffic information.  Refresh: Click the Refresh button to update table with newest traffic information. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 55: Error

    Jabber Frames is raised to the maximum size of Jumbo Frames.  Apply: Click the Apply button to clear port specific Traffic information.  Refresh: Click the Refresh button to update table with newest traffic information. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 56: Ieee 802.3Az Eee

    3. Click the IEEE 802.3az EEE Status drop-down list and select Enabled to enable the power saving feature and click Apply to save the settings. 4. At the bottom of the left hand panel, click Save. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 57: Network

    Link Status - This parameter indicates the status of the link between the port 10/Full -This parameter indicates the port is configured for 10Mbps and the end node connected to the port. The possible values are: operation in full-duplex mode. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 58 Enabled - This parameter indicates that the port is permitted to use Note: This step saves all configuration changes to the NV-RAM to ensure that if the flow control. switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 59: Spanning Tree

    Maximum Age: The Maximum Age defines the amount of time a port will wait for STP/RSTP information. MSTP uses this parameter when interacting with STP/RSTP domains on the boundary ports. Its range is 6 - 40 seconds © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 60: Port

    '0' assigns the automatically calculated default Path Cost value to the status automatically. The default setting for this parameter is Auto. port. If the default Path Cost is being used, this object returns '0' when read. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 61: Mst

    OK. value between 0-61440. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 62: Instance

    5. Select the Config you would like to save the settings to, click Save Settings to Flash, then click OK. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 63: Mst Port

    5. Select the Config you would like to save the settings to, click Save Settings to Flash, then click OK. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 64: Trunk

    Note: This step saves all configuration changes to the NV-RAM to ensure that if the For each Trunk ID/Group, check the port numbers to add for each trunk group. switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 65: Status

    5. Select the Config you would like to save the settings to, click Save Settings to Flash, then click OK. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 66: Mirroring

    Port section or you could click All to copy data received on all ports. To copy data transmitted on specific port, check the port number under the Egress Port section or you could click All to copy data transmitted on all ports. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 67: Loopback Detection

    5. Select the Config you would like to save the settings to, click Save Settings to Flash, then click OK. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 68: Static Unicast

    MAC Address – Enter the MAC address of the device to add.  Port Member – Select the port where the MAC address will reside. Click Apply to add the Static Unicast entry to the list. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 69: Static Multicast

    Group Member – Check the port(s) where the MAC address will reside. Note: You can click All to select all ports. Click Apply to add the Static Multicast Group entry to the list. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 70: Igmp Snooping

    Note: This step saves all configuration changes to the NV-RAM to ensure that if the Router Timeout - Enter the maximum time duration without router messages switch is rebooted or power cycled, the configuration changes will still be applied. before the router timeout. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 71: Router Ports

    Check the static router ports to add and click Apply to save the settings. Note: You can click on All to add all ports. Clicking Restore will restore the static router port settings to default. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 72: Mld Snooping

     Last Member Query Interval – Enter the interval between the last member queries.  Router Timeout – Enter the amount of time before the router times out. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 73: Router Port

     802.1Q VLAN ID – Shows the VLAN ID.  Static Router Port – Check the box below the port number to set the statically set ports © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 74: Multicast Vlan

    5. Select the Config you would like to save the settings to, click Save Settings to Flash, then click OK. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 75: Multicast Vlan Access Settings

    5. Select the Config you would like to save the settings to, click Save Settings to Flash, then click OK. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 76: Multicast Filtering

    5. Select the Config you would like to save the settings to, click Save Settings to Flash, then click OK. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 77: Ingress Rate Limiting

    Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 78: Vlan

    In the sections Static Tagged, Static Untagged, and Not Member, you can add the type of VLAN ports to add to the new VLAN (Tagged or Untagged) and assign ports that are not members (Forbidden) of the new VLAN. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 79: Port

    4. At the bottom of the left hand panel, click Save. 5. Select the Config you would like to save the settings to, click Save Settings to Flash, then click OK. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 80: Dynamic

    5. Select the Config you would like to save the settings to, click Save Settings to Flash, 5. Select the Config you would like to save the settings to, click Save Settings to Flash, then click OK. then click OK. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 81: Private

    Set the Source Port to one of the following choices from the pull-down menu: Note: This step saves all configuration changes to the NV-RAM to ensure that if the All, 01 – 10 switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 82: Current

    Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 83: Port Settings

    Restricted VLAN Registration field. In other words, each port is set individually. Enable - The Restricted VLAN Registration is active for the port row selected. Disable - The Restricted VLAN Registration is de-active for the port row selected. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 84: Time Settings

    Note: To ensure compatibility between network devices, you need to configure the same values for the GARP Join Timer, GARP Leave Timer, and GARP Leave All Timer on all participating GVRP devices in your network. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 85: Voice Vlan

    If the IP phone(s) that you are installing cannot be configured with a VLAN ID, then the same, then no other IP phone MAC addresses need to be entered into the configuration. switch ports should be configured as Static tagged ports within the voice VLAN. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 86: Settings

    VLAN IDs that have been defined. Aging Time - This parameter indicates the amount of time, in hours, after the last IP phone's OUI was received on a port, after which this © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 87: Oui

    To delete a specific OUI that had already been entered in the table at the bottom of the page, click on Delete in the Action column of the table. The specific OUI will be deleted from the table. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 88: Lldp

     Enable: The LLDP feature is active.  Disable: The LLDP feature is inactive. LLDR-MED Parameter Settings: Fast Start Repeat Count: Enter the number of tries to start. Configure the LLDP Parameter Settings © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 89 System Name: This parameter lists the System Name of the switch. You can assign the system name.  System Description: This parameter lists the product name of the switch. You cannot change this parameter © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 90: Basic Tlvs Settings

    3. Configure the basic TLVs settings. Click Apply to save. 4. At the bottom of the left hand panel, click Save. 5. Select the Config you would like to save the settings to, click Save Settings to Flash, then click OK. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 91: Med Port Settings

    “Access your switch management page” on page 5). 2. Click on Network, click on LLDP, and click on LLDP Local Port Information. 3. View the LLDP Local Port Information. Click Show Details to for additional info. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 92: Mac Vlan

    Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 93: Protocol Vlan Profile Interface

    5. Select the Config you would like to save the settings to, click Save Settings to Flash, then click OK. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 94: Qos (Quality Of Service)

    For each Priority who’s Queue ID you want to change, click on the CoS Table (1-7, Ignore) radio button that applies to your configuration. 4. Review the settings. Click Apply to save the settings. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 95: Port Priority

    Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. 4. At the bottom of the left hand panel, click Save. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 96: Scheduling Algorithm

    5. Select the Config you would like to save the settings to, click Save Settings to Flash, then click OK. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 97: Ipv6 Traffic Class

    You can also click Delete All to delete all of the entries in the table. If the entries span multiple pages, you can navigate page number in the Page field and click Go or you can click First, Previous, Next, and Last Page to navigate the pages. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 98: Poe (Power Over Ethernet)

    Critical and High 15.4W 0.44W to 12.95W levels are already receiving power. This 4.0W 0.44W to 3.84W level is the default setting. 7.0W 3.84W to 6.49W 15.4W 6.49W to 12.95W 34.2W 12.85W to 25.5W © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 99: Configure Poe Settings

    Note: The User Defined power limit ranges between 1.0 and 30.0 watts.  TimeRange – Select a defined PoE TimeRange. N/A will be displayed if no time ranges have been created. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 100: Time Range

    To: Time (HH:MM) – Set the end time of the PoE time range.  End Weekday – Check this box to set the time range to stop at the end of the defined From: Weekday. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 101: Security

    1. Log into your switch management page (see “Access your switch management page” 5. Select the Config you would like to save the settings to, click Save Settings to Flash, on page 5). then click OK. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 102: Dial-In User

    Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. Click Add to add the entry to the table. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 103: Radius

    Note: This step saves all configuration changes to the NV-RAM to ensure that if the Click Add to add the entry to the table. switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 104: Tacacs

    Possible field values are 1-255. The default value is 5.  Shared Secret – Enter the default authentication and encryption key for TACACS+ communication between the device and the TACACS+ server. Click Add to add the entry to the table. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 105: Destination Mac Filter

    3. Enter the MAC Address to add to the destination filter table. Click Add. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 106: Denial Of Service

    5. Select the Config you would like to save the settings to, click Save Settings to Flash, then click OK. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 107: Dhcp Snooping

    Enable - Allows an Option 82 packet to be passed through the switch without being altered. Disable - Blocks an Option 82 packet from passing through the switch.  Verify MAC Address - Select one of the following choices from the pull-down menu: © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 108: Vlan

    You can also click Delete All to delete all of the entries in the table. If the entries span multiple pages, you can navigate page number in the Page field and click Go or you can click First, Previous, Next, and Last Page to navigate the pages. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 109: Interfaces

    5. Select the Config you would like to save the settings to, click Save Settings to Flash, then click OK. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 110: Binding

    5. Select the Config you would like to save the settings to, click Save Settings to Flash, then click OK. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 111: Dynamic Arp Inspection

    4. At the bottom of the left hand panel, click Save. 5. Select the Config you would like to save the settings to, click Save Settings to Flash, then click OK. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 112: Arp Inspection Port Settings

    5. Select the Config you would like to save the settings to, click Save Settings to Flash, then click OK. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 113: Arp Inspection Statistics

    5. Select the Config you would like to save the settings to, click Save Settings to Flash, then click OK. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 114: Acl

    Destination- Defines the access packet destination. Any- Indicates ACL action will be taken on packets to any destination. MAC Address – Indicates ACL action will be taken on packets to the specified MAC address. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 115: Access Profile List

    Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 116: Acl Finder

    Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. 4.View the active poicies by clicking on the Access ID number. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 117: Tools

    2. Click on Tools, click on Firmware Upgrade. TRENDnet may periodically release firmware upgrades that may add features or fix problems associated with your TRENDnet switch model and version. To check if there is 3. Select the Image you would like to upgrade.

  • Page 118: Firmware Upgrade Via Tftp Settings

    To restore your switch configuration: 1. Log into your switch management page (see “Access your switch management page” on page 5). 2. Click on Tools, click on Configuration and click on Backup/Restore, under via HTTP. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 119: Backup/Restore Via Tftp Settings

    4. Review the settings. Click Backup to save the configuration file (config.bin) to your config.bin) local hard drive on your TFTP server root directory.  TFTP Server IP: Enter the IP address of your TFTP server. 5. Wait for the switch to restore settings. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 120: Diagnostics

    2. Click on Tools and click on Cable Diagnostic. 3. Click on the Port drop-down list to select which port to run the cable diagnostic and click Test Now to run the test. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 121: Reboot

    3. Click the Reboot Type drop-down list and select Normal and click Apply to initiate a reboot. Wait for the switch complete the rebooting process. The switch factory default settings are below. Administrator User Name admin Administrator Password admin Switch IP Address 192.168.10.200 Switch Subnet Mask 255.255.255.0 © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 122: Ping

    Timeout Value - Specifies the length of time, in seconds, the switch waits for a response before assuming that a ping has failed.  Number of Ping Requests - Specifies the number of ping requests you want the switch to perform. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 123: Using The Web Smart Switch Management Utility

    Using the Web Smart Switch Management Utility The Web Smart Management Utility allows you to do the following:  You can easily discover all TRENDnet web smart switches on your network using the discover feature.  You can modify the IP address settings, change the admin password, and upgrade firmware for multiple switches.

  • Page 124: Using The Utility

    6. In the Completion window, click Finish. You can also launch the utility from the Start Menu programs. Start > Programs (or All Programs) > TRENDnet Management Utility > TRENDnet Management Utility.exe © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 125: Discovery List

    Add Item: To add a device to the Monitor List manually, enter the IP Address of  Group Interval: the device that you want to monitor.  Delete Item: To delete the device in the Monitor List. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 126: Device Setting

    “Set” to process the data change immediately. The default password of TRENDnet Web Smart Switches is “admin”. Access Web: Double click the device in the Monitor List or select a device in the Monitor List and press this “Web Access”...

  • Page 127: Main Menu Options

    Choose 15 secs, 30 secs, 1 min, 2 min and 5 min to select the time of monitoring.  Group Interval: 120~1225 In the “Help TAB”, there is About function, it will show out the version of the Web Management Utility. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 128: Hardware Features And Specifications

    75 Watts Fan Quantity Fanless Noise Level N/A (fanless) 52 dBA (max.) 52.4 dBA (max.) 55 dBA (max.) MTBF 862,966 hours 465,862 hours 192,382 hours 443,825 hours 277,604 hours 239,897 hours 338,601 hours © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 129 External Power Adapter (UL) Warranty Lifetime In addition to the switch, the package contents include the following: Quick Installation Guide Package Contents Rack mount kit Power adapter (54V Power cord (1.8m/6 ft.) DC, 1.67A) © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 130: Web Smart Switch Series Software Specifications

    Up to 256 VLAN groups, ID Range 1- Multiple management VLAN assignment  MAC-based VLAN 4094  Asymmetric VLAN   Private VLAN (Protected Ports)  Protocol-based VLAN VLAN 802.1Q Tagged VLAN  Voice VLAN (10 user defined OUIs) © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 131 IPv4 / IPv6 static routing Layer 3 Features IPv6)  IP interfaces: Up to 6  ARP table (up to 128 entries) Compatibility Optional Software Utility: Windows® 10, 8.1, 8, 7, Vista, XP, Windows® 2003/2008 Server © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 132: Quick Installation Guidetroubleshooting

    Then click Use the following IP address, and make sure to assign your network adapter an IP address in the subnet of 192.168.10.x. Click OK Note: If you are experiencing difficulties, please contact your computer or operating system manufacturer for assistance. © Copyright 2018 TRENDnet. All Rights Reserved.

  • Page 133: Appendix

    From the Location drop-down list, select Automatic. 2. In the Network Preference window, next to "Show:", select Network Status. You'll see d. Select and view your Ethernet connection. your network status and your IP address settings displayed. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 134 2. Select Ethernet from the list on the left. Example: ping –c 4 192.168.10.100 3. Click the Advanced button. 3. On the Ethernet tab, the Ethernet ID is your MAC Address. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 135 Country Code selection feature to be disabled for products marketed to the US/CANADA CE Mark Warning This is a Class A product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. © Copyright 2018 TRENDnet. All Rights Reserved.
  • Page 136 An RMA number is required in order to initiate warranty service support the event that the RMA unit needs to be replaced, TRENDnet may replace it with a for all TRENDnet products. Products that are sent to TRENDnet for RMA service must refurbished product of the same or comparable model.
  • Page 137 OF SUCH DAMAGES, AND LIMITS ITS LIABILITY TO REPAIR, REPLACEMENT, OR REFUND evidence of the original purchaser's date of purchase. Replacement products may be OF THE PURCHASE PRICE PAID, AT TRENDNET'S OPTION. THIS DISCLAIMER OF LIABILITY refurbished or contain refurbished materials. If TRENDnet, by its sole determination, is...

This manual is also suitable for:

Tpe-082wsTpe-1620ws v2Tpe-1620wsfTpe-1620wsTpe-2840ws v2Tpe-2840ws ... Show all

Table of Contents

Save PDF
