TRENDnet Web Smart Switch Series User Manual

Table of Contents

Quick Links

Cover Page

TRENDnet User's Guide

Table of Contents

Need help?

Do you have a question about the Web Smart Switch Series and is the answer not in the manual?

Questions and answers

Summary of Contents for TRENDnet Web Smart Switch Series

Page 1 Cover Page TRENDnet User’s Guide...
Page 2: Table Of Contents
Table of Contents TRENDnet User’s Guide Thank you for purchasing your new TRENDnet Web Contents Web Smart Switch Series Product Overview ........2 Smart Switch! TEG-082WS Overview ....................2 Package Contents ....................2 TEG-082WS Hardware Features ................2 TEG-204WS Overview ....................4 Please note: The scope of this user's guide encompasses multiple Package Contents ....................
Page 3 Telnet ........................... 25 Instance ......................50 MST Port ......................50 Enable Telnet management access..............25 Trunk ..........................51 DHCP Auto Configuration .................... 26 Settings ......................51 Enable DHCP Auto Configuration............... 26 Status ......................... 52 © Copyright 2023 TRENDnet. All Rights Reserved.
Page 4 Egress Rate Limiting ................... 64 Set CoS priority settings ..................81 VLAN ..........................65 Port Priority ......................... 82 Tagged ....................... 65 Set Port Priority ....................82 Port ........................66 DSCP ..........................82 Forwarding ......................67 © Copyright 2023 TRENDnet. All Rights Reserved.
Page 5 Network Connectivity Test (Ping Tool) ............109 Denial of Service (DoS) ..................91 Using the Web Smart Switch Management Utility ....... 110 DHCP Snooping ......................92 System Requirements ....................110 Settings ......................92 VLAN ........................94 Installation ......................... 110 © Copyright 2023 TRENDnet. All Rights Reserved.
Page 6 Device Setting ....................113 Main Menu Options ..................114 Hardware Features and Specifications ......... 115 Web Smart Switch Series Software & Technical Specifications ..117 Quick Installation GuideTroubleshooting ........119 Appendix ..................120 © Copyright 2023 TRENDnet. All Rights Reserved.
Page 7: Web Smart Switch Series Product Overview
Web Smart Switch Series TRENDnet User’s Guide TEG-082WS Hardware Features Web Smart Switch Series Product Overview TEG-082WS Overview Front View Rear View Package Contents In addition to your switch, the package includes: • Quick Installation Guide • CD-ROM (Utility & User’s Guide) •...
Page 8 : When the LED is blinking amber, the port is transmitting Blinking or receiving data on the network at 10/100Mbps speed. When the LED is off, the respective port is disconnected. • SFP Slots (9-10) © Copyright 2023 TRENDnet. All Rights Reserved.
Page 9: Teg-204Ws Overview
SFP slots 17F-20F and are disabled when SFP slots (17F- retailer, or reseller/distributor from which the product was purchased. 20F) are in use. • SFP Slots (17F-20F) – Supports optional 1000BASE-SX/LX mini-GBIC modules for uplink or downlink connections. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 10 1Gbps speed. Amber : When the LED is blinking amber, the port is transmitting Blinking or receiving data on the network at 10/100Mbps speed. When the LED is off, the respective port is disconnected. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 11: Teg-284Ws Overview
If any package contents are missing or damaged, please contact the retail store, online • SFP Slots (25F-27F) – Supports optional 1000BASE-SX/LX mini-GBIC retailer, or reseller/distributor from which the product was purchased. modules for uplink or downlink connections. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 12 1Gbps speed. Amber : When the LED is blinking amber, the port is transmitting Blinking or receiving data on the network at 10/100Mbps speed. When the LED is off, the respective port is disconnected. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 13: Teg-524Ws Overview
If any package contents are missing or damaged, please contact the retail store, online 52F) are in use. retailer, or reseller/distributor from which the product was purchased. • SFP Slots (49F-52F) – Supports optional 1000BASE-SX/LX mini-GBIC modules for uplink or downlink connections. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 14 When the SFP LED is on, the link established using the SFP module is operating at 100Mbps speed. Amber blinking When the SFP LED is blinking, the port is transmitting or receiving data on through the 100Mbps link established. No link established. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 15 • Power cord (1.8 m / 6 ft.) • Rack mount kit If any package contents are missing or damaged, please contact the retail store, online retailer, or reseller/distributor from which the product was purchased. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 16 : When the LED is blinking amber, the port is transmitting Blinking or receiving data on the network at 10/100Mbps speed. When the LED is off, the respective port is disconnected. • SFP Slots (25 – 28) • Link/Activity © Copyright 2023 TRENDnet. All Rights Reserved.
Page 17: Switch Installation
• When installing the Switch on a level surface, attach the rubber feet to the bottom of each device. The rubber feet cushion the hub and protect the hub case from scratching. Then, use screws provided with the equipment rack to mount each switch in the rack. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 18: Basic Ip Configuration
192.168.10.x (e.g. 192.168.10.25) and a subnet mask of 255.255.255.0. 4. Open your web browser, and type the IP address of the switch in the address bar, and then press Enter. The default IP address is 192.168.10.200. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 19 9. When the confirmation message appears click OK. Be sure to re-log back into the switch using the new IP address and save the configuration to your flash. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 21: Connect Additional Devices To Your Switch
Note: If you encounter issues connecting to your network, there may be a problem with your computer or device network settings. Please ensure that your computer or device network settings (also called TCP/IP settings) are configured properly within the network subnet your switch is connected. Note: Your switch model may be different than the one shown in the example illustrations. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 22: Accessing Switch Management Interfaces
User Name: admin Password: admin Note: User Name and Password are case sensitive. Hardware Information • DRAM Size: Displays your switch RAM memory size. • Flash Size: Displays your switch Flash memory size. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 23 • IPv6 DHCP Client Mode: Displays if your switch IPv6 address setting is set to • Subnet Mask – Displays the current IPv4 subnet mask assigned to your switch. DHCP client. • Default Gateway – Displays the current gateway address assigned to your switch. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 24: Switch View
Distance: Displays the estimated length of the cable measured in meters MC(Tx): The number of Multicast packets transmitted • BC(Tx): The number of Broadcast packets transmitted Real-time Statistics View your switch status information Dashboard > Real-time Statistics © Copyright 2023 TRENDnet. All Rights Reserved.
Page 25: System
30 characters. • System Contact - Specifies the name of the network administrator responsible for managing the switch. This contact name is optional and may contain up to 30 characters. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 26: Cloud Settings
This section allows you to change your switch IPv4 address settings and additionally With TRENDnet Hive, you will be able to manage and monitor your device through the create and assign the aforementioned address to VLANs. Typically, the IP address TRENDnet Cloud portal remotely.
Page 27: Ipv4 Arp Aging Time
OK. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 28: Ipv4 Static Arp
5. Select the Config you would like to save the settings to, then click Save Settings to Flash. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 29: Set Your Ipv6 Settings
OK. the lower table. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 31: Add Ipv6 Neighbors
Page field and click Go or you can click First, Previous, Next, and Last Page to navigate the pages. 4. At the bottom of the left hand panel, click Save. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 32: Configure Ipv6 Routing Table
• Next Hop IPv6 Address: Enter the next hop for the routing entry. • Backup Status: Specify if this routing entry is to be the Primary or Backup entry. 4. At the bottom of the left hand panel, click Save. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 33: Dns
5. Select the Config you would like to save the settings to, click Save Settings to Flash, then click OK. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 34: Ip Access List
Delete All to delete all entries in the table. When you have completed entering the IPv4 and IPv6 address entries, click the IP Restriction Status drop-down list at the top and select Enabled, then click Apply. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 35: Administration
In the Password field, enter the new password and enter the new password again the switch is rebooted or power cycled, the configuration changes will still be applied. Confirm Password field to verify. Then, click Apply. Note: The password consists of up to 20 alphanumeric characters. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 36: Timeout
5. Select the Config you would like to save the settings to, click Save Settings to Flash, then click OK. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 37: System Time
Date Settings – Enter your date settings (YYYY/MM/DD). From: Set the daylight savings start date and time. ▪ To: Set the daylight savings end date and time. ▪ Time Settings – Enter your time settings (HH:MM:SS) © Copyright 2023 TRENDnet. All Rights Reserved.
Page 38: Ssl
If enabling SSL management access, you will need to access the switch management page using HTTPS instead of HTTP. (e.g. https://192.168.10.200) © Copyright 2023 TRENDnet. All Rights Reserved.
Page 39: Ssh
Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. 4. At the bottom of the left hand panel, click Save. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 41: Dhcp Auto Configuration
3. Click the Auto Configuration State drop-down list and select Enabled. Click Apply to switch is rebooted or power cycled, the configuration changes will still be applied. save changes. 4. At the bottom of the left hand panel, click Save. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 42: System Log
▪ 1 Alert - Action must be taken immediately. ▪ 2 Critical - Critical conditions are displayed. ▪ 3 Warning - Warning conditions are displayed. ▪ 4 Info - Informational messages are displayed. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 43 5. Select the Config you would like to save the settings to, click Save Settings to Flash, then click OK. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 44: Snmp
Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. Disabled - When you enable this parameter, the SNMP agent is inactive. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 45: View
5. Select the Config you would like to save the settings to, click Save Settings to Flash, then click OK. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 46: Group
Auth-Protocol has a password assigned and the Priv- then click OK. Protocol has been selected as none on the SNMP User/Group page. AuthPriv: When the Auth-Protocol or Priv-Protocol have been enabled, choose this selection. • Click the Add button. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 47: User
Select one of the following choices for the Priv-Protocol field: DES - Specifies DES encryption scrambles the SNMP data so that outside observers are prevented from seeing the data content. none - Specifies no encryption is applied to SNMP data. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 49: Trap
Click Add. The new host is added to the table. then click OK. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 50: Rmon
5). 2. Click on System, click on RMON and click on Settings. 3. Click the RMON Status drop-down list and select Enabled to enable RMON. Click Apply to save settings. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 51: Statistics
Click Add to add the entry to the table. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 52: History
• Owner: This parameter is used to identify the person who created an entry. It is primarily intended for switches that are managed by more than one person, and is an optional field. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 53: Alarms
• Owner: This parameter is used to identify the person who created an entry. It is primarily intended for switches that are managed by more than one person, and is an optional field. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 54: Events
Owner: This parameter is used to identify the person who created an entry. It is then click OK. primarily intended for switches that are managed by more than one person, and is an optional field. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 55 5. Select the Config you would like to save the settings to, then click Save Settings to Flash. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 56: Statistics
OutDiscards: Outbound Discards (Pkts), number of outbound discarded packets. • Apply: Click the Apply button to clear port specific Traffic information. • Refresh: Click the Refresh button to update table with newest traffic information. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 57: Error
Refresh: Click the Refresh button to update table with newest traffic Flash. information. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 58: Ieee 802.3Az Eee
3. Click the IEEE 802.3az EEE Status drop-down list and select Enabled to enable the power saving feature and click Apply to save the settings. 4. At the bottom of the left hand panel, click Save. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 59: Network
Link Status - This parameter indicates the status of the link between the port 10/Full -This parameter indicates the port is configured for 10Mbps and the end node connected to the port. The possible values are: operation in full-duplex mode. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 60 5. Select the Config you would like to save the settings to, click Save Settings to Flash, Enabled - This parameter indicates that the port is permitted to use then click OK. flow control. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 61: Spanning Tree
Maximum Age: The Maximum Age defines the amount of time a port will wait for STP/RSTP information. MSTP uses this parameter when interacting with STP/RSTP domains on the boundary ports. Its range is 6 - 40 seconds © Copyright 2023 TRENDnet. All Rights Reserved.
Page 62: Port
Writing a value of '0' assigns the automatically calculated default Path Cost value to the port. If the default Path Cost is being used, this object returns '0' when read. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 64: Mst
VID List (1 - 4094): Displays the VID List. Click Add to add into MST Table below. • Priority: Enter the new priority in the Priority field. The user may set a priority value between 0-61440. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 65: Instance
5. Select the Config you would like to save the settings to, then click Save Settings to Flash. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 66: Trunk
For each Trunk ID/Group, check the port numbers to add for each trunk group. Click the drop-down list and select one of the following options. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 67: Status
5. Select the Config you would like to save the settings to, then click Save Settings to Flash. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 68: Mirroring
Port section or you could click All to copy data received on all ports. To copy data transmitted on specific port, check the port number under the Egress Port section or you could click All to copy data transmitted on all ports. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 69: Loopback Detection
Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. In the Loopback Detection table, select one of the Loopback Detection Status choices from the pull down menu: © Copyright 2023 TRENDnet. All Rights Reserved.
Page 70: Static Unicast
You can also click Delete All to delete all the entries in the list. If the entries span multiple pages, you can navigate page number in the Page field and click Go or you can click First, Previous, Next, and Last Page to navigate the pages. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 71: Static Multicast
In the list, you can click Modify to modify an entry or click Delete or delete the entry. If the entries span multiple pages, you can navigate page number in the Page field and click Go or you can click First, Previous, Next, and Last Page to navigate the pages. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 73: Router Ports
Check the static router ports to add and click Apply to save the settings. Note: You can click on All to add all ports. Clicking Restore will restore the static router port settings to default. 4. At the bottom of the left hand panel, click Save. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 74: Mld Snooping
• Last Member Query Interval – Enter the interval between the last member queries. • Router Timeout – Enter the amount of time before the router times out. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 75: Router Port
802.1Q VLAN ID – Shows the VLAN ID. • Static Router Port – Check the box below the port number to set the statically set ports 4. At the bottom of the left hand panel, click Save. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 76: Multicast Vlan
5. Select the Config you would like to save the settings to, then click Save Settings to Flash. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 77: Multicast Vlan Access Settings
5. Select the Config you would like to save the settings to, then click Save Settings to Flash. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 78: Multicast Filtering
5. Select the Config you would like to save the settings to, send click Save Settings to Flash. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 79: Ingress Rate Limiting
Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 80: Vlan
VLAN ports to add to the new VLAN (Tagged or Untagged) and assign ports that are not members (Forbidden) of the new VLAN. Click Apply to save the new VLAN to the table. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 81: Port
Note: Modifying settings in the row marked All, will apply the settings to all ports. 4. At the bottom of the left hand panel, click Save. 5. Select the Config you would like to save the settings to, click Save Settings to Flash, then click OK. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 82: Dynamic
Note: The default mode is IVL. Flash. 4. At the bottom of the left hand panel, click Save. 5. Select the Config you would like to save the settings to, then click Save Settings to Flash. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 83: Private
Enable: Enable Private VLAN settings. Disable: Disable Private VLAN settings. • Press Apply for changes to take effect. • Set the Source Port to one of the following choices from the pull-down menu: All, 01 – 10 © Copyright 2023 TRENDnet. All Rights Reserved.
Page 84: Current
5. Select the Config you would like to save the settings to, click Save Settings to Flash, then click OK. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 85: Port Settings
Restricted VLAN Registration field. In other words, each port is set individually. Enable - The Restricted VLAN Registration is active for the port row selected. Disable - The Restricted VLAN Registration is de-active for the port row selected. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 86: Time Settings
Note: To ensure compatibility between network devices, you need to configure the same values for the GARP Join Timer, GARP Leave Timer, and GARP Leave All Timer on all participating GVRP devices in your network. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 87: Voice Vlan
If the IP phone(s) that you are installing cannot be configured with a VLAN ID, then the same, then no other IP phone MAC addresses need to be entered into the configuration. switch ports should be configured as Static tagged ports within the voice VLAN. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 88: Settings
VLAN IDs that have been defined. Aging Time - This parameter indicates the amount of time, in hours, after the last IP phone's OUI was received on a port, after which this © Copyright 2023 TRENDnet. All Rights Reserved.
Page 89: Oui
To delete a specific OUI that had already been entered in the table at the bottom of the page, click on Delete in the Action column of the table. The specific OUI will be deleted from the table. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 90: Lldp
• Enable: The LLDP feature is active. • Disable: The LLDP feature is inactive. LLDR-MED Parameter Settings: Fast Start Repeat Count: Enter the number of tries to start. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 91 System Name: This parameter lists the System Name of the switch. You can assign the system name. • System Description: This parameter lists the product name of the switch. You cannot change this parameter © Copyright 2023 TRENDnet. All Rights Reserved.
Page 92: Basic Tlvs Settings
5. Select the Config you would like to save the settings to, click Save Settings to Flash, then click OK. Dot1 TLVs Settings MED Port Settings Network > LLDP > Dot1 TLVs Settings Network > LLDP > MED Port Settings © Copyright 2023 TRENDnet. All Rights Reserved.
Page 93: Lldp Statistics Information
2. Click on Network, click on LLDP, and click on LLDP Local Port Information. 3. View the LLDP Local Port Information. Click Show Details to for additional info. Neighbor Network > LLDP > Neighbors © Copyright 2023 TRENDnet. All Rights Reserved.
Page 94: Mac Vlan
Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 95: Protocol Vlan Profile Interface
5. Select the Config you would like to save the settings to, click Save Settings to Flash, then click OK. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 96: Qos (Quality Of Service)
For each Priority who’s Queue ID you want to change, click on the CoS Table (1-7, Ignore) radio button that applies to your configuration. 4. Review the settings. Click Apply to save the settings. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 97: Port Priority
Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. 4. At the bottom of the left hand panel, click Save. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 98: Scheduling Algorithm
5. Select the Config you would like to save the settings to, then click Save Settings to Flash. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 99: Ipv6 Traffic Class
You can also click Delete All to delete all of the entries in the table. If the entries span multiple pages, you can navigate page number in the Page field and click Go or you can click First, Previous, Next, and Last Page to navigate the pages. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 100: Security
4. At the bottom of the left hand panel, click Save. 5. Select the Config you would like to save the settings to, then click Save Settings to Flash. 4. You may review the settings that was made in the table below © Copyright 2023 TRENDnet. All Rights Reserved.
Page 101: Port Security Address Settings
Port Access Control - This parameter enables or disables Port Access Control. Select one of the following choices from the pulldown menu: This section contains information and configuration procedures for the Enable: The Port Access Control feature is activated. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 102: Dial-In User
In the Dynamic VLAN field, enter the VID of the VLAN which you will allow the user to access. If you enter 0, this field will be ignored. Click Add to add the entry to the table. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 103: Radius
Click Add to add the entry to the table. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 104: Tacacs
Possible field values are 1-255. The default value is 5. • Shared Secret – Enter the default authentication and encryption key for TACACS+ communication between the device and the TACACS+ server. Click Add to add the entry to the table. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 105: Destination Mac Filter
2. Click on Security and click on Destination MAC Filter. switch is rebooted or power cycled, the configuration changes will still be applied. 3. Enter the MAC Address to add to the destination filter table. Click Add. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 106: Denial Of Service
5. Select the Config you would like to save the settings to, click Save Settings to Flash, then click OK. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 107: Dhcp Snooping
Enable - Allows an Option 82 packet to be passed through the switch without being altered. Disable - Blocks an Option 82 packet from passing through the switch. • Verify MAC Address - Select one of the following choices from the pull-down menu: © Copyright 2023 TRENDnet. All Rights Reserved.
Page 108 Option 82 information into the DHCP packets. Disable: The Web Management Utility software does not insert the DHCP Option 82 information into the DHCP packets. 4. At the bottom of the left hand panel, click Save. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 109: Vlan
Page field and click Go or you can click First, Previous, Next, and Last Page to navigate the pages. 4. At the bottom of the left hand panel, click Save. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 110: Interfaces
5. Select the Config you would like to save the settings to, then click Save Settings to Flash. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 111: Dynamic Arp Inspection
Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 112: Arp Inspection Validation
VID List – Enter a VID. • Static ACL – Select Yes from the drop down menu to set a static ACL 4. At the bottom of the left hand panel, click Save. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 113: Arp Inspection Port Settings
5. Select the Config you would like to save the settings to, then click Save Settings to Flash. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 114: Arp Inspection Statistics
5. Select the Config you would like to save the settings to, then click Save Settings to Flash. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 115: Acl
Destination- Defines the access packet destination. Any- Indicates ACL action will be taken on packets to any destination. MAC Address – Indicates ACL action will be taken on packets to the specified MAC address. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 116: Access Profile List
5. Select the Config you would like to save the settings to, then click Save Settings to Flash. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 117: Acl Finder
Summary- Displays the ACL rule summary. • Status- Displays the ACL rule status. • Action- Includes the Delete button for removing ACL rules. 4.View the active poicies by clicking on the Access ID number. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 118 5. Select the Config you would like to save the settings to, then click Save Settings to Flash. Note: This step saves all configuration changes to the NV-RAM to ensure that if the switch is rebooted or power cycled, the configuration changes will still be applied. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 119: Tools
2. Click on Tools, click on Firmware Upgrade. TRENDnet may periodically release firmware upgrades that may add features or fix problems associated with your TRENDnet switch model and version. To check if there is 3. Select the Image you would like to upgrade.
Page 120: Firmware Upgrade Via Tftp Settings
Image File Name: Enter the firmware filename with extension. (.hex) • Retry Count: Defined the number of time to attempt to pull the firmware file from the TFTP server. 6. Click Apply to start the firmware upgrade. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 121: Config Backup Restore
TFTP server root directory. • TFTP Server IP: Enter the IP address of your TFTP server. 3. Next to Select File, depending on your web browser, click on Browse or Choose File. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 122: Diagnostics
Config File – Select the configuration. Startup-config refers to the configuration that was used to startup this switch. • Config File Name: Enter the configuration file name to restore. (Default: config.bin) 5. Wait for the switch to restore settings. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 123: Reboot
2. Click on Tools and click on Reboot. 3. Click the Reboot Type drop-down list and select Normal and click Apply to initiate a reboot. Wait for the switch complete the rebooting process. To reset your switch to factory defaults: © Copyright 2023 TRENDnet. All Rights Reserved.
Page 124: Ping
Number of Ping Requests - Specifies the number of ping requests you want the switch to perform. The switch factory default settings are below. Administrator User Name admin Administrator Password admin Switch IP Address 192.168.10.200 Switch Subnet Mask 255.255.255.0 © Copyright 2023 TRENDnet. All Rights Reserved.
Page 125: Using The Web Smart Switch Management Utility
Using the Web Smart Switch Management Utility The Web Smart Management Utility allows you to do the following: • You can easily discover all TRENDnet web smart switches on your network using the discover feature. • You can modify the IP address settings, change the admin password, and upgrade firmware for multiple switches.
Page 126: Using The Utility
6. In the Completion window, click Finish. You can also launch the utility from the Start Menu programs. Start > Programs (or All Programs) > TRENDnet Management Utility > TRENDnet Management Utility.exe © Copyright 2023 TRENDnet. All Rights Reserved.
Page 127: Discovery List
Add Item: To add a device to the Monitor List manually, enter the IP Address of ⚫ Group Interval: the device that you want to monitor. ⚫ Delete Item: To delete the device in the Monitor List. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 128: Device Setting
“Set” to process the data change immediately. The default password of TRENDnet Web Smart Switches is “admin”. Access Web: Double click the device in the Monitor List or select a device in the Monitor List and press this “Web Access”...
Page 129: Main Menu Options
Choose 15 secs, 30 secs, 1 min, 2 min and 5 min to select the time of monitoring. ⚫ Group Interval: 120~1225 In the “Help TAB”, there is About function, it will show out the version of the Web Management Utility. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 130: Hardware Features And Specifications
Power Consumption 7.1 Watts (max.) 14.6 Watts (max.) 17.3 Watts (max.) 34.9 Watts (max.) 22.8 Watts (max.) Fan Quantity Fanless Noise Level N/A (fanless) MTBF 1,092,872 hours 835,519 hours 787,004 hours 400,158 hours © Copyright 2023 TRENDnet. All Rights Reserved.
Page 131 3.48 kg (7.67 lbs.) 2.09kg (4.61 lbs.) Certifications Warranty Lifetime In addition to the switch, the package contents include the following: Quick Installation Guide Package Contents Rack mount kit Power cord (1.8m/6 ft.) © Copyright 2023 TRENDnet. All Rights Reserved.
Page 132: Web Smart Switch Series Software & Technical Specifications
Web Smart Switch Series TRENDnet User’s Guide Web Smart Switch Series Software & Technical Specifications • • • IEEE 802.1X IEEE 802.3z IEEE 802.1d • • IEEE 802.1ab IEEE 802.3ab • IEEE 802.1p • • • IEEE 802.3 IEEE 802.3ad Standards IEEE 802.1Q...
Page 133 IPv4 / IPv6 static routing Layer 3 Features IPv6) • IP interfaces: Up to 6 • ARP table (up to 128 entries) Compatibility Optional Software Utility: Windows® 10, 8.1, 8, 7, Vista, XP, Windows® 2003/2008 Server © Copyright 2023 TRENDnet. All Rights Reserved.
Page 134: Quick Installation Guidetroubleshooting
Then click Use the following IP address, and make sure to assign your network adapter an IP address in the subnet of 192.168.10.x. Click OK Note: If you are experiencing difficulties, please contact your computer or operating system manufacturer for assistance. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 135: Appendix
2. In the Network Preference window, next to "Show:", select Network Status. You'll see Note: If you are experiencing difficulties, please contact your computer or operating your network status and your IP address settings displayed. system manufacturer for assistance. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 136 C:\Users>ping 192.168.10.100 Pinging 192.168.10.100 with 32 bytes of data: Reply from 192.168.10.100: bytes=32 time<1ms TTL=64 Reply from 192.168.10.100: bytes=32 time<1ms TTL=64 Reply from 192.168.10.100: bytes=32 time<1ms TTL=64 Reply from 192.168.10.100: bytes=32 time<1ms TTL=64 © Copyright 2023 TRENDnet. All Rights Reserved.
Page 137 Low Voltage Directive 2014/35/EU CE Mark Warning This is a Class A product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. © Copyright 2023 TRENDnet. All Rights Reserved.
Page 138 An RMA number is required in order to initiate warranty service support the event that the RMA unit needs to be replaced, TRENDnet may replace it with a for all TRENDnet products. Products that are sent to TRENDnet for RMA service must refurbished product of the same or comparable model.
Page 139 OF SUCH DAMAGES, AND LIMITS ITS LIABILITY TO REPAIR, REPLACEMENT, OR REFUND evidence of the original purchaser's date of purchase. Replacement products may be OF THE PURCHASE PRICE PAID, AT TRENDNET'S OPTION. THIS DISCLAIMER OF LIABILITY refurbished or contain refurbished materials. If TRENDnet, by its sole determination, is...

This manual is also suitable for:

Teg-082ws Teg-204ws Teg-284ws Teg-524ws Teg-30284

TRENDnet Web Smart Switch Series User Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TRENDnet Web Smart Switch Series

Summary of Contents for TRENDnet Web Smart Switch Series

This manual is also suitable for:

Table of Contents
