Setra Systems 231RS Operating Instructions Manual page 5

High Pressure
Remote Sensor
Valve A
1
High
Model 231RS (Conduit version, P/N: 231GRSX3MXXX) - Outline drawing
1.98
(50.3)
Side view
Model 231RS
Valve A = High side valve
Valve B = Low side valve
Valves not included.
1
Pipe
R 0.1
(2.5)
0.35
(8)
1/2" Conduit
Opening
4.0
(39.6)
(10.2)
Low Pressure
Remote Sensor
Figure 1
6.0
(152.4)
5.56
(141.2)
Front view
1.56
(30.99)
5.16
(131.1)
Bottom view
Figure 2
5
Pipe
2.0
(50.8)
2x
0.864
(21.95)
0.95
(24.1)
1.220
1.240
(31.50)
Valve B
1
Low
