SETUP INSTRUCTIONS (continued)
Connecting the swim-trainer unit to the
transformer (see fi gures 9.1 to 9.2).
1. Be sure the transformer (2) switch is OFF,
connect the transformer cable to a
grounded electrical outlet.
Ensure the voltage and electrical rating
indicated on the transformer corresponds
to the local mains voltage before you
connect the unit.
2. Transformer must be fi xed to a solid,
level ground or base with the transformer
anchor screws (27). Hole size:
Ø 8.5mm x 30mm (Ø 11/32" x 1.2").
Connect the swim-trainer unit power cable
plug into the transformer power receptacle.
Be sure the plug collar is securely tightened
(see fi gure 9.1 to 9.2).
3. Position the transformer 2m or more away
from the pool, so as to prevent children from
climbing on it and accessing the pool.
4. Test the GFCI or RCD before use:
a) Press the "RESET" button. The indicator
on the GFCI/RCD should be "ON".
b) Press the "TEST" button. The indicator
on the GFCI/RCD should be "OFF".
c) Press the "RESET" button again to
start using the product.
d) Do not use the product if the test failed. Contact a qualifi ed electrician to inspect the
electrical outlet socket.
5. Turn the transformer switch ON.
NOTE: To reactivate the swim-trainer unit after the emergency stop lanyard is pulled,
replace the emergency stop lanyard back into the swim-trainer unit, unplugged and
re-plugged the power cable from the transformer.
SAVE THESE INSTRUCTIONS
(303IO) MODEL SM24100 SWIMMING MACHINE ENGLISH 7.5" X 10.3" PANTONE 295U 08/30/2018
Power
receptacle
English
ON/OFF Switch
27
Page 13
303A
9.1
Fuse Box
9.2
