INTEX
Operating Instructions
READ, UNDERSTAND AND FOLLOW ALL INSTRUCTIONS CAREFULLY BEFORE INSTALLING
AND USING THIS PRODUCT.
Made in China
© 2006 ®™ Intex Recreation Corp.
(102) ENGLISH SALTWATER SYSTEM MODEL8220/8230 SIZE: 7.5" X 10.5" 10/11/2006
®
OWNER'S MANUAL
Krystal Clean Poolwater™ System
Model 8220
Model 8230
220W, IPX5

TABLE OF CONTENTS

5-9
10
11
12
13
13
14-15
IMPORTANT SAFETY RULE
Intex Trading Ltd.
C/O Intex (HongKong) Ltd.
SAVE THESE INSTRUCTIONS
Page 1
220 - 230 V~, 50 Hz
230 - 240 V~, 50 Hz
2
3
Stationary Mounting Option
4
Intex Service Center Locations
Intex Trading B.V.
P. O. Box nr. 1075-4700 BB Roosendaal
102
16-17
18
18-19
19
20
21-22
22
23
23
102**-R0-0710

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Krystal Clean Poolwater 8220 and is the answer not in the manual?

Questions and answers

Related Manuals for Intex Krystal Clean Poolwater 8220

Summary of Contents for Intex Krystal Clean Poolwater 8220

  • Page 1: Table Of Contents

    Pool Maintenance and Chemical Definitions 20 Intex Pools Operating Time Table Trouble Shooting Guide 21-22 Non Intex Pools Salt Table General Aquatic Safety Non Intex Pools Operating Time Table Limited Warranty Operating Instructions 14-15 Intex Service Center Locations IMPORTANT SAFETY RULE READ, UNDERSTAND AND FOLLOW ALL INSTRUCTIONS CAREFULLY BEFORE INSTALLING AND USING THIS PRODUCT.

  • Page 2: Warning

    (102) ENGLISH SALTWATER SYSTEM MODEL8220/8230 SIZE: 7.5” X 10.5” 10/11/2006 IMPORTANT SAFETY RULE Read, Understand and Follow All Instructions Carefully Before Installing and Using this Product. This Electronic Saltwater System is intended to be used only for the purposes described in this manual.

  • Page 3: Parts Reference

    (102) ENGLISH SALTWATER SYSTEM MODEL8220/8230 SIZE: 7.5” X 10.5” 10/11/2006 PARTS REFERENCE Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts. ELECTROLYTIC CELL HOUSING CELL LINE CORD FLOW SENSOR RECEPTACLE LINE CORD 05CG-03...

  • Page 4: Product Information And Specifications

    (102) ENGLISH SALTWATER SYSTEM MODEL8220/8230 SIZE: 7.5” X 10.5” 10/11/2006 Product Information and Specifications How the Chlorine is Generated Common salt (sodium chloride) is made up of two elements, sodium and chloride. During the installation of your Saltwater System, a measured quantity of salt is dissolved in the pool water to make it slightly salty. This pool water is passed through the Saltwater System's electrolytic cell to produce chlorine which is dissolved instantly in the water.

  • Page 5: Set Up Instructions

    (102) ENGLISH SALTWATER SYSTEM MODEL8220/8230 SIZE: 7.5” X 10.5” 10/11/2006 Set Up Instructions IMPORTANT: The Saltwater System must be installed as the last piece of pool equipment in the water return line to the pool as displayed in Drawing #1. This location extends the life of the titanium plates. 1.
  • Page 6 (102) ENGLISH SALTWATER SYSTEM MODEL8220/8230 SIZE: 7.5” X 10.5” 10/11/2006 Set Up Instructions (cont.) 1. If your above-ground-pool is filled up with water, unscrew the strainer grids from the strainer connectors and insert the black hat-like plugs into the strainer connectors before saltwater pool system installation.
  • Page 7 (102) ENGLISH SALTWATER SYSTEM MODEL8220/8230 SIZE: 7.5” X 10.5” 10/11/2006 Set Up Instructions (cont.) For connection to filter pumps with 1-1/2” (38mm) hose size: (Do not use adapter A or B, 05CG-11 or 05CG-12) Drawing #2 PLUNGER VALVE WATER TO POOL SWIMMING POOL WATER FROM...
  • Page 8 (102) ENGLISH SALTWATER SYSTEM MODEL8220/8230 SIZE: 7.5” X 10.5” 10/11/2006 Set Up Instructions (cont.) For connection to other filter pump (with different type of thread or no thread): Saltwater System can also adapt to other filter pumps for those with different thread or without thread on the connection.
  • Page 9 (102) ENGLISH SALTWATER SYSTEM MODEL8220/8230 SIZE: 7.5” X 10.5” 10/11/2006 Set Up Instructions (cont.) Connect to 1-1/4” (32mm) hose: • 05CG-11 1-1/4”(32mm) HOSE SALTWATER SYSTEM 1. Connect the adaptor A (05CG-11) to the electrolytic cell (05CG-01) outlet. Tighten securely. 2. Connect the water return (to the pool) hose to the adaptor A (05CG-11) on the saltwater pool system with a hose clamp (F26).

  • Page 10: Salt & Pool Water Volumes

    (102) ENGLISH SALTWATER SYSTEM MODEL8220/8230 SIZE: 7.5” X 10.5” 10/11/2006 Salt & Pool Water Volumes Use only Sodium Chloride Salts Use only sodium chloride (NaCl) salt that is at least 99.8% pure. It is also acceptable to use water conditioning salt pellets (the compressed forms of evaporated salt), but it will take longer time for them to dissolve.

  • Page 11: Intex Pools Salt Table

    Startup Pool Size and 80% for Easy Set & Oval Pool) (CODE “91”) (Lbs) (Gals) (Lbs) (Kgs) (Kgs) (Liters) INTEX ABOVE GROUND POOLS (AGP’s) 15' x 36" 3282 12422 15' x 42" 3861 14614 15' x 48" 4440 16806 CIRCULAR 16' x 42"...

  • Page 12: Intex Pools Operating Time Table

    (102) ENGLISH SALTWATER SYSTEM MODEL8220/8230 SIZE: 7.5” X 10.5” 10/11/2006 Intex Pools Operating Time Table This table shows the operating time required for normal use of the Saltwater System with AGP’s. Operating Time (hours) Water Capacity at different ambient/air Calculated at 90% for Frame Pool...

  • Page 13: Non Intex Pools Salt Table

    Water Capacity (Liters) x Water Capacity (Gals) x Water Capacity (Liters) x 0.025 0.003 0.0067 0.0008 Non Intex Pools Operating Time Table Operating Time (hours) Water Capacity at different ambient/air temperatures 20 - 28 °C 29 - 36 °C 37 - 42 °C...
  • Page 14 (102) ENGLISH SALTWATER SYSTEM MODEL8220/8230 SIZE: 7.5” X 10.5” 10/11/2006 Operating Instructions After the salt is dissolved, but before starting the Saltwater System be sure that: The entire filtering and chlorinating system is connected to a grounding type receptacle protected •...
  • Page 15 (102) ENGLISH SALTWATER SYSTEM MODEL8220/8230 SIZE: 7.5” X 10.5” 10/11/2006 Operating Instructions (cont.) 7. The green LED light on the control panel will disappear when the cycle has ended. The system will go into a “Stand-By Mode” with the LED flashing “93”. The system automatically goes into a “Power Saving Mode”...

  • Page 16: Alarm Codes & Led Code Chart

    2. Low salt level. • Add salt. See “Salt & Pool Water Volumes”. Level 3. Possible electrolytic cell • Contact Intex Service Center. Replace the cell failure. if needed. 1. High salt level. • Partially drain the pool and refill with fresh water.
  • Page 17 (102) ENGLISH SALTWATER SYSTEM MODEL8220/8230 SIZE: 7.5” X 10.5” 10/11/2006 LED Code Chart LED Reading Definitions Stand-By Mode (Start-up) Zero Operating Hours Minimum Operating Hour (1 hour remaining) Operating Hours (2 hours remaining) Operating Hours (3 hours remaining) Operating Hours (4 hours remaining) Operating Hours (5 hours remaining) Operating Hours (6 hours remaining) Operating Hours (7 hours remaining)

  • Page 18: Maintenance

    (102) ENGLISH SALTWATER SYSTEM MODEL8220/8230 SIZE: 7.5” X 10.5” 10/11/2006 Maintenance IMPORTANT: Unplug power cord before cleaning and close plunger valves or insert black hat-like plugs in strainer opening to prevent water spillage. Plug in the power cord and open plunger valves or remove plugs when maintenance tasks are completed.

  • Page 19: Long Term Storage

    (102) ENGLISH SALTWATER SYSTEM MODEL8220/8230 SIZE: 7.5” X 10.5” 10/11/2006 Maintenance (cont.) 05CG-08 05CG-06 05CG-09 3. Disconnect screen fitting (05CG-09) from the flow sensor conduit (05CG-06). See “Parts Reference”. 4. Check for debris which has passed through the filter and been trapped on the debris screen (05CG-08).

  • Page 20: Intex 3-Way Test Strips

    (102) ENGLISH SALTWATER SYSTEM MODEL8220/8230 SIZE: 7.5” X 10.5” 10/11/2006 INTEX ® 3-Way Test Strips (packed with the Saltwater System) 3-Way Test Strips can test the “Free Chlorine”, “pH”, and “Total Alkalinity” levels at the same time. Directions and Use: 1.

  • Page 21: Trouble Shooting Guide

    • Check to see if cell cord is loose or not connected properly. Ensure the cell cord is plugged firmly into the cell housing receptacle. Contact Intex Service Center for • replacement. Contact Intex Service Center for • replacement.

  • Page 22: General Aquatic Safety

    See “Maintenance”. • Add salt. See “Salt & Pool Water Volumes”. 2. Low salt level. • Contact Intex Service Center. Replace the cell 3. Possible electrolytic cell failure. if needed. • Partially drain the pool and refill with fresh CODE 92 1.

  • Page 23: Limited Warranty

    Limited Warranty is invalid. If a manufacturing defect is found within this one (1) year period, please contact the appropriate Intex Service Center listed in this manual. The Service Center will determine the validity of the claim.
