(303IO) MODEL SM24100 SWIMMING MACHINE ENGLISH 7.5" X 10.3" PANTONE 295U 08/30/2018
Hydro Flow Swim Trainer™
Model SM24100
230-240V AC / 50Hz
For illustrative purposes only. Pool not included.
Don't forget to try these other fine Intex products: pools, pool
accessories, inflatable pools and in-home toys, airbeds and boats
available at fine retailers or visit our website.
Due to a policy of continuous product improvement, Intex
reserves the right to change specifications and appearance,
which may result in updates to the instruction manual without
notice.
Rechte vorbehalten. Printed in China/Imprimé en Chine/Impreso en China/Gedruckt in China.
®™ Trademarks used in some countries of the world under license from/®™ Marques utilisées dans certains pays sous
licence de/Marcas registradas utilizadas en algunos países del mundo bajo licencia de/Warenzeichen verwendet in einigen
Ländern der Welt in Lizenz von/Intex Marketing Ltd. to/à/a/an Intex Development Co. Ltd., G.P.O Box 28829, Hong
Kong & Intex Recreation Corp., P.O. Box 1440, Long Beach, CA 90801 • Distributed in the European Union by/Distribué
dans l'Union Européenne par/Distribuido en la unión Europea por/Vertrieb in der Europäischen Union durch/Intex Trading
B.V., Venneveld 9, 4705 RR Roosendaal – The Netherlands
www.intexcorp.com
IMPORTANT
SAFETY RULES
Please read, understand, and follow all
instructions carefully before installing
and using this product. Keep for future
reference.
©2018 Intex Marketing Ltd. - Intex Development Co. Ltd. - Intex Recreation
Corp.
All rights reserved/Tous droits réservés/Todos los derechos reservados/Alle
English
303A
303-*A*-R0-1908

Advertisement

Table of Contents
loading

Related Manuals for Intex Hydro Flow Swim Trainer SM24100

Summary of Contents for Intex Hydro Flow Swim Trainer SM24100

  • Page 1 Ländern der Welt in Lizenz von/Intex Marketing Ltd. to/à/a/an Intex Development Co. Ltd., G.P.O Box 28829, Hong Kong & Intex Recreation Corp., P.O. Box 1440, Long Beach, CA 90801 • Distributed in the European Union by/Distribué dans l’Union Européenne par/Distribuido en la unión Europea por/Vertrieb in der Europäischen Union durch/Intex Trading B.V., Venneveld 9, 4705 RR Roosendaal –...

  • Page 2: Table Of Contents

    (303IO) MODEL SM24100 SWIMMING MACHINE ENGLISH 7.5” X 10.3” PANTONE 295U 08/30/2018 English 303A TABLE OF CONTENTS Warnings..................3 Parts Reference................4-5 Product Specification..............6 Setup Instructions..............6-13 Operating Instructions............... 14-15 Maintenance................15 Internal Parts Replacements............. 16-17 Troubleshooting Guide.............. 18-19 Limited Warranty.................

  • Page 3: Warnings

    (303IO) MODEL SM24100 SWIMMING MACHINE ENGLISH 7.5” X 10.3” PANTONE 295U 08/30/2018 English 303A IMPORTANT SAFETY RULES Read, Understand and Follow All Instructions Carefully Before Installing and Using this Product. READ AND FOLLOW ALL INSTRUCTIONS WARNING • This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

  • Page 4: Parts Reference

    PARTS REFERENCE Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts. Intex Rectangular Frame Pool Mounting Bracket In Ground Pool Mounting Bracket Intex Round Frame Pool Mounting Bracket. NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale.

  • Page 5: Parts Reference

    (303IO) MODEL SM24100 SWIMMING MACHINE ENGLISH 7.5” X 10.3” PANTONE 295U 08/30/2018 English 303A PARTS REFERENCE (continued) Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts. Intex Rectangular Intex Round Frame Frame Pool Pool POOL REF. NO. DESCRIPTION QTY.

  • Page 6: Product Specification

    Model: Transformer input: 230-240V AC / 50Hz Voltage: Transformer output: +12VDC, 35A 880 W Max Power: In ground pool or Intex above ground metal frame pools Suitable for: Pool water temperature range: 25ºC - 35ºC Speed Setting* 0.66 0.77 0.83 0.94...
  • Page 7 303A SETUP INSTRUCTIONS (continued) Pool Mounting Bracket Assembly A: For Intex Rectangular Frame Pools 1. Mounting Bracket Assembly (see fi gures 1.1 to 1.2): NOTE: Center the swim-trainer unit on the short-end side of the pool. 2. Installing the mounting bracket assembly onto a rectangular frame pool wall (see fi...
  • Page 8 (303IO) MODEL SM24100 SWIMMING MACHINE ENGLISH 7.5” X 10.3” PANTONE 295U 08/30/2018 English 303A SETUP INSTRUCTIONS (continued) • Lock the bracket poles and mounting bracket assembly onto the U-shaped side support with the bracket pole fi xer (7) and screws (8), (see fi gure 2.2.). NOTE: Make sure all the screws are securely tightened and the mounting bracket top surface is level.
  • Page 9 (303IO) MODEL SM24100 SWIMMING MACHINE ENGLISH 7.5” X 10.3” PANTONE 295U 08/30/2018 English 303A SETUP INSTRUCTIONS (continued) B: For Intex Round Frame Pools 1. Mounting Bracket Assembly (see figures 4.1 to 4.5): • Identify the frame pool pipe shape. For “ ” shape pipe see fi gure 4.2 to 4.5.
  • Page 10 (303IO) MODEL SM24100 SWIMMING MACHINE ENGLISH 7.5” X 10.3” PANTONE 295U 08/30/2018 English 303A SETUP INSTRUCTIONS (continued) 2. Installing the mounting bracket assembly onto a round frame pool wall (see figures 5.1 to 5.3): • Attach the mounting bracket assembly onto the frame pool vertical legs with the horizontal pipe lugs (10), screws (8), and depending on the shape of the vertical leg pipe include A/B/C gap fi...
  • Page 11 (303IO) MODEL SM24100 SWIMMING MACHINE ENGLISH 7.5” X 10.3” PANTONE 295U 08/30/2018 English 303A SETUP INSTRUCTIONS (continued) • Adjust the nut on the swimming machine until the support plate is against the pool wall and the swim-trainer unit is perfectly Ajustable nut horizontal (see figure 5.5).
  • Page 12 (303IO) MODEL SM24100 SWIMMING MACHINE ENGLISH 7.5” X 10.3” PANTONE 295U 08/30/2018 English 303A SETUP INSTRUCTIONS (continued) 2. Swim-Trainer Unit Assembly (see fi gures 6.4 to 6.5). • Be sure the swim-trainer unit “support bracket” is closed before installing the swim-trainer unit onto the mounting bracket assembly (see fi...
  • Page 13 (303IO) MODEL SM24100 SWIMMING MACHINE ENGLISH 7.5” X 10.3” PANTONE 295U 08/30/2018 English 303A SETUP INSTRUCTIONS (continued) Connecting the swim-trainer unit to the ON/OFF Switch transformer (see fi gures 9.1 to 9.2). 1. Be sure the transformer (2) switch is OFF, Power receptacle connect the transformer cable to a...

  • Page 14: Operating Instructions

    (303IO) MODEL SM24100 SWIMMING MACHINE ENGLISH 7.5” X 10.3” PANTONE 295U 08/30/2018 English 303A OPERATION INSTRUCTIONS Display Panel Function Antenna Zone #1 Function Zone #1 Function Zone #2 Function A: On/Off Button B: Speed Increase Button C: Speed Decrease Button D: Speed Setting Display A: On/Off Button: Once the swim-trainer unit is connected to the transformer and the transformer turned ON, use this button to active the system.

  • Page 15: Maintenance

    F or when the appliance will not be used for a long period of time. IMPORTANT: Close the support bracket before disassembling and removing the swim-trainer unit from the mounting bracket assembly (Only for Intex Rectangular Frame Pools). 1. Turn off the transformer and unplug the power cable from the electrical outlet.

  • Page 16: Internal Parts Replacements

    (303IO) MODEL SM24100 SWIMMING MACHINE ENGLISH 7.5” X 10.3” PANTONE 295U 08/30/2018 English 303A INTERNAL PARTS REPLACEMENTS Tools required: one Philip screwdriver, one flat screwdriver and one small adjustable wrench. A: Propeller disassembly Page 16 SAVE THESE INSTRUCTIONS...
  • Page 17 (303IO) MODEL SM24100 SWIMMING MACHINE ENGLISH 7.5” X 10.3” PANTONE 295U 08/30/2018 English 303A INTERNAL PARTS REPLACEMENTS (continued) B: Swim-trainer unit bracket and circuitry box unit disassembly Page 17 SAVE THESE INSTRUCTIONS...

  • Page 18: Troubleshooting Guide

    (303IO) MODEL SM24100 SWIMMING MACHINE ENGLISH 7.5” X 10.3” PANTONE 295U 08/30/2018 English 303A TROUBLESHOOTING GUIDE LED PANEL PROBLEM SOLUTION CODE The maximum operating time It's normal. Turn off and unplug the unit. ● ● (90 minutes) has fi nished under the Then plug the RCD/GFCI back and same set mode.

  • Page 19: Troubleshooting Guide

    ● ● Emergency stop lanyard is put wrong plugged fi rmly into the cell ● place. housing receptacle. Contact Intex Service Center. ● Put the emergency stop lanyard ● on correct place. See “Setup Instructions”. Abnormal display / Display panel cord is loose.

  • Page 20: Limited Warranty

    Other than this warranty, and other legal rights in your country, no further warranties are implied. To the extent possibly in your country, in no event shall Intex be liable to you or any third party for direct or consequential damages arising out of the use of your Hydro Flow Swim Trainer™, or Intex or its agents’...
