Power supply 24 V DC for digital
80
VCC24V
outputs
81
VCC24V
Power supply 24 V DC of PCB
82
VCC24V
83
VCC24V
84
VCC24V
85
GND
86
GND
GND towards PCB 2U2
87
GND
88
GND
X103
Used for:
89
GND
90
GND
91
GND
Power supply of CAN: towards
92
VCC24V
LED/button PCB
93
GND
94
GND
95
GND
96
GND
97
Field Bus5
98
Field Bus6
99
Field Bus7
100
Field Bus8
X600
Used for:
21
Digital In 0 Pressure switch 1
22
COM 0
GND
X601
Used for:
23
Digital In 1 Pressure switch 2
24
COM 1
GND
X602
Used for:
Float switch of the start-up tank –
25
Digital In 2
Low level
26
COM 2
GND
X603
Used for:
27
Digital In 3 Main water tank – Low level
28
COM 3
GND
X604
Used for:
11
Digital In 4 Pressure switch "pump in demand"
12
Digital In 5 Motor protection switch pump
13
Digital In 6 Key switch level 2
14
Digital In 7 Float switch – Lack of glycol
15
COM 4-7
GND
X605
Used for:
WILO SE 01/2017
Power supply 24 V DC for digital
80
VCC24V
outputs
81
VCC24V
82
VCC24V
83
VCC24V
84
VCC24V
85
GND
GND of transformer of LED
86
GND
87
GND
88
GND
X103
Used for:
89
GND
90
GND
Power supply of CAN: towards
91
GND
LED/button PCB
Power supply of CAN: towards
92
VCC24V
LED/button PCB
93
GND
94
GND
95
GND
CAN shielding: towards
96
GND
LED/button PCB
97
Field Bus5
98
Field Bus6
99
Field Bus7
100
Field Bus8
X600
Used for:
21
Digital In 0 Signalling trip circuit malfunction
22
COM 0
GND
X601
Used for:
23
Digital In 1 Trip circuit operation malfunction
24
COM 1
GND
X602
Used for:
25
Digital In 2 Pump fuse malfunction
26
COM 2
GND
X603
Used for:
27
Digital In 3 Pump in operation
28
COM 3
GND
X604
Used for:
Monitoring availability of the
11
Digital In 4
connection voltage 400 V
12
Digital In 5 Free error message
13
Digital In 6
14
Digital In 7
15
COM 4-7
GND
X605
Used for:
