"ACTIVE"
When the pressure in the unit falls below the threshold set on the pressure switches, the pressure switch(es)
becomes active. The LED flashes green (for pressure switch 1) or yellow (for pressure switch 2).
After the elapsed follow-up time (menu 1.2.5.1), the LED remains turned on permanently.
If key switch 1 or 2 is in the "Auto" position, the pump starts automatically.
When the pressure rises and exceeds the threshold set, the pressure switch passes to the passive state. It is
possible to turn off the LED by pressing the acknowledgement button (Fig. 2, pos. 11).
The acknowledgement is only accessible if the user has previously connected to level 2.

7 Installation and electrical connection

Installation and electrical connection must be carried out in accordance with local regulations and
only by qualified personnel!
WARNING! Risk of personal injury!
Comply with applicable accident prevention regulations.
Warning! Risk of electric shock!
Danger from electrical current must be eliminated.
Local directives or general directives [e.g. IEC] and instructions from local energy
supply companies must be adhered to.
7.1 Installation
Install the switchgear/unit in a dry location.
Protect the place of installation from direct exposure to sunlight.
7.2 Electrical connection
DANGER! Risk of death!
In case of non-compliant electrical connection, there is a danger of death by electrocution.
• Have the electrical connection established by an electrician approved by the local energy
supply company only and in accordance with local regulations.
• Observe the installation and operating instructions for the pumps and accessories.
• Disconnect the power supply before any work!
Warning! Risk of electric shock!
There is a potentially fatal voltage on the supply side, even when the main switch is turned
off.
