External connections of the electric cabinet
Digital inputs
Digital outputs
(contact NO)
Digital outputs
(contact NC)
Connection bus
Digital outputs
(contacts NO/NC)
WILO SE 01/2017
Function
Pressure switch no. 1
Pressure switch no. 2
Pressure switch "pump in
demand"
Motor protection switch
pump
Float switch level glycol
Float switch start-up tank
Float switch storage tank
Contact freely configurable
Malfunction start-up failed
Malfunction connection of
communication bus
Malfunction availability of
the connection voltage
RS485 Modbus or Bacnet
General malfunction
Pump in operation
Low level of start-up tank
Low water level
Lack of glycol
Contact freely configurable
Non-auto mode 1
Non-auto mode 2
Connection voltage
availability malfunction
Number of
wires per
Size of the shroud and
cable gland cross-section of
the wires
N07VK
PG7 2 x 1 mm²
PG7 2 x 1 mm²
PG7 2 x 1 mm²
PG7 2 x 1 mm²
PG7 2 x 1 mm²
PG7 2 x 1 mm²
PG7 2 x 1 mm²
PG7 2 x 1 mm²
Unused 2 x 1 mm²
Unused 2 x 1 mm²
Unused 2 x 1 mm²
Unused 2 x 1 mm²
Unused 2 x 1 mm²
Unused 2 x 1 mm²
Unused 2 x 1 mm²
Unused 2 x 1 mm²
Unused 2 x 1 mm²
Unused 2 x 1 mm²
Unused 2 x 1 mm²
Unused 2 x 1 mm²
Unused 2 x 1 mm²
English
Max
length
10 m
10 m
10 m
10 m
20 m
20 m
20 m
10 m
10 m
10 m
10 m
Electrical
switchgear
10 m
10 m
10 m
10 m
10 m
10 m
10 m
10 m
10 m
10 m
