4 Applications (application)
The switchgear SC Fire A2P controls a single electric pump in automatic sprinkler systems in accordance with
APSAD (T1-2).
The relevant fields of application are habitable buildings, offices, hospitals, hotels, administrative and
industrial buildings.
The pump is switched according to the pressure or level when it is used with the right signal sensors.
Compliance with this manual is also part of correct use.
Any use which does not meet this criteria is considered to be non-compliant.

5 Product information

5.1 Type key
Example:
W
CTRL
SC
F
1x
(2)
T4
(3)
(4)
ND
E
Table 1 – Type key
WILO SE 01/2017
W-CTRL-SC-F-1x(2)A-T4-(3)-(4)-ND-E
Brand:
W: Wilo
Multiple choice
Fixed Operation
Fixed Smart Control = control unit
Fixed F = application of protection against fire
Fixed Number of pumps
Maximum rated current of the motor [A]:
14.1A
20.4A
27.6A
33.7A
39.1A
Multiple choice
53.6A
65.8A
78.0A
95.0A
129.0A
Fixed T = three-phase ; 4 = 400 V
On state:
DOL: Direct online (direct starting)
Multiple choice
SD: Star Delta (start star-delta)
Type of installation of switchbox:
Multiple choice FM: Frame mounted (placed on a baseplate)
BM: Base mounted (mounted on feet)
Fixed Switchgear type "New Design"
Fixed Switchgear for electric pump
English
