Summary of Contents for Infinite Peripherals Infinea Tab Lite
- Page 1 USER MANUAL Infinea Tab Lite ® For iPhone 6/6s Plus/7Plus/8 Plus ®...
- Page 2 6 Plus iPhone 6s Plus iPhone 7 Plus iPhone 8 Plus Trademarks Infinite Peripherals, Mobilize Your Enterprise, Linea Pro, Infinea, Infinea Tab, and Infinea Omni are trademarks of Infinite Peripherals, Inc. All other trademarks are the property of their respective owners.
-
Page 3: Table Of Contents
USER MANUAL- INFINEA TAB LITE Table of Contents Overview TUrn on the Infinea Tab Lite Technical Data Magnetic Stripe Reader Box Contents Read NFC Cards Getting Started Troubleshooting Product Description Servicing the Infinea Tab Lite Attach iOS Device to Otterbox uniVERSE case... -
Page 4: Overview
Overview The Infinea Tab Lite is a compact, enterprise-grade mobile payment device featuring a magnetic card reader and NFC contactless card reader. The Lightning™ cable connects the Infinea Tab Lite to you iOS device. In addition, the Otterbox uniVERSE case is designed for plus-size iOS devices... - Page 5 USER MANUAL- INFINEA TAB LITE Connectivity Battery Capacity Near-Field Communication (NFC) Rechargeable Li-ion Battery 3.7V/500mAh, charging from Lighning ISO/IEC 14443 Type A/MIFARE port or charging station MIFARE MINI Power Supply MIFARE CLASSIC-1K, MIFARE CLASSIC-4K 5V through Lightning™ Connector 5V through single charger...
-
Page 6: Box Contents
Infinea Tab Lite (1) Getting Started The Infinea Tab Lite allows you to transact credit card payments via the magnetic stripe reader and NFC contactless card reader, and pass that data onto compatible iOS applications. The following helps you get the Infinea Tab Lite ready for use:... -
Page 7: Product Description
USER MANUAL- INFINEA TAB LITE Product Description Contactless Reader On/Off Button Indicators for Contactless transactions/LEDs for device status Charging Contacts Magnetic Card Reader Lightning Receptacle Port Battery Charging Indicator Lightning™ Connector Attach iOS Device to Otterbox uniVERSE Case Insert your iOS device into the Otterbox uniVERSE case. -
Page 8: Battery Charging
Lightning cable plugged into the Lightning port. Use only the approved 5 volt, 2.1 amp DC adapters to charge the iOS device and Infinea Tab Lite together. Failure to do so may result in problems charging the unit and/or potential damage to the Infinea Tab Lite and/or iOS device. -
Page 9: Operational Modes
When enabled and the Lightning cable is plugged in, the iOS device is with a Windows computer or an Apple MacOS. When syncing is required, enable the Pass-Through Sync setting in the SDK. When this setting is disabled and the cable is plugged in, the Infinea Tab Lite only charges. -
Page 10: Turn On The Infinea Tab Lite
USER MANUAL- INFINEA TAB LITE Turn on the Infinea Tab Lite Press the On button on the side of the unit. Hold the button until you see the first three LEDs illuminated, and then release the button. Magnetic Stripe Reader... -
Page 11: Troubleshooting
USER MANUAL- INFINEA TAB LITE Troubleshooting If you experience problems with your Infinea Tab Lite, which are not addressed in the Troubleshooting section, contact https://ipcmobile.com/support General Issues Issue Possible Cause Infinea Tab Lite does not • Battery is too low or fully discharged connect to the iOS device •... -
Page 12: Servicing The Infinea Tab Lite
USER MANUAL- INFINEA TAB LITE Servicing the Infinea Tab Lite The Infinea Tab Lite is designed with an internal, Lithium-ion rechargeable battery. If the Infinea Tab Lite battery is not charging properly, or the unit is not https://ipcmobile.com/support powering on, contact your Infinite Peripherals representative or Encrypted functionality with special key protection features is included. -
Page 13: Symbols
USER MANUAL- INFINEA TAB LITE Symbols Symbol Description Refer to the instructions before using this product Manufacturer Manufacture Date Caution Serial Number Part Number Waste Electrical and Electric Equipment Complies with part 15 of the FCC rules Operation is subject to the following two conditions:...
