08 QUICK START

PUSH BUTTON SAFETY

PUSH SAFE
FIG-1
The safety button is located on the frame and is used to switch
A
between safe (PUSH SAFE) and fire (PUSH FIRE). When the marker is
NOT safe the button will protrude from the left side of the frame.
FIG-2 - PUSH SAFE
Push the safety button in from the left side of the frame to make
A
the M170R safe. The M170R trigger will be locked and the marker will
not fire.
Firing the M170R
When the safety button is set to PUSH SAFE the M170R will not fire.
IMPORTANT! If the safety button does not work, do not use the
1
marker. Either the button requires maintenance or the trigger has
been adjusted outside of its operating window and is blocking
the safety.
If you are not comfortable in performing either of these
operations then contact your nearest Eclipse Service Centre.
GTEK M170R
FIG-1
A
1
FIG-2
A
1
WARNING!
When the PUSH SAFE is enabled the M170R is still a live marker until the air
system has been fully removed.
Ensure that a barrel blocking device is attached when the marker is set to safe.
09 QUICK START
PUSH BUTTON SAFETY
PUSH FIRE
FIG-1
The safety button is located on the frame and is used to switch
A
between safe (PUSH SAFE) and fire (PUSH FIRE). When the marker is
NOT set to fire, the button will protrude from the right side of the frame.
FIG-2 - PUSH FIRE
Push the safety button in from the right side of the frame. The
A
M170R will be live and ready to fire.
Firing the M170R
When set to PUSH FIRE the M170R will fire when the trigger is pulled.
IMPORTANT! If the safety button does not work, do not use the
1
marker. Either the button requires maintenance or the trigger has
been adjusted outside of its operating window and is blocking the
safety.
If you are not comfortable in performing either of these operations
then contact your nearest Eclipse Service Centre.
WARNING
GTEK M170R
FIG-1
A
1
FIG-2
A
1
WARNING!
When PUSH FIRE is enabled the M170R is live and will fire with every pull of the
trigger, if an air system is fitted.
Ensure that the M170R is set to PUSH SAFE and a barrel blocking device is
attached until you are ready to use the marker.
