OIL BURNER OPERATION

NOTICE: For reliable operation, set Air-Fuel mixture conservatively based on installation conditions. CO
draft readings should be taken through the over fire test port in front jacket opening at right of burner (see FIG. 6). A 1/4"
O.D. sample tube must extend at least eight (8) inches into front cover to obtain accurate readings. Smoke test and stack
temperature should be taken at flue outlet. A test port in the flue box is provided to measure draft loss and smoke.
NOTICE: For accurate efficiency calculations, measure flue gas temperature in flue box sample port.
Installation Conditions
Operational Range
Target for Normal Conditions
Active Area (Washer, Dryer, Shop)
Outside Oil Tank
* Although the Ascent Combi Boiler can operate without a trace of smoke above 14% CO
the nominal gain in efficiency may not offset the potential of increased maintenance costs.
Note 1: For combinations of above, use lowest CO
Note 2: CO
AFTER 15 MINUTES RUNNING, CHECK AND RECORD:
1. DRAFT AT BREECH/CHIMNEY
2. CO
3. STACK TEMPERATURE
SMOKE TEST
4.
Draft at the breech with a chimney should be -0.02" to -0.12" w.c. on the EK1T Ascent Combi.
If not, recheck chimney, chimney base and flue pipe for blockage or clean out door openings.
Draft over fire with a power vent (sidewall vent) should be negative.
If not, check power vent fan is turning, or vent blockage.
Ascent Oil – August 2019
/O must be checked with Silent Burner Cover in place.
2 2
............................................................................ .See table above
/O
2 2
.................................................................Verify 0 smoke at breech
CO Setting
2
8.0% to 14.0%*
11%
10 ½%
10%
level or highest O
2
(CONVENTIONAL VENTING ASCENT COMBI)
(POWER VENTED ASCENT PLUS COMBI)
(CONVENTIONAL VENTING ASCENT COMBI)
(POWER VENTED ASCENT PLUS COMBI)
26
O Setting
2
10% to 1.5%
6.5%
6.8%
7.1%
,
2
level.
2
..0.02"w.c. Minimum
.....Negative pressure
o o
........350
to 550 F
o o
...........150
to 300 F at breech
/O and
2 2
