REPLACEMENT PARTS

Obtain replacement parts from your local Energy Kinetics dealer.
Contact Energy Kinetics at 800-323-2066 or www.energykinetics.com
for help locating your nearest authorized dealer.
W
V
U
C
N
F
G
EK1T
ITEM
PART NO.
A 10-0828 Combustion Chamber (Stainless)
B1 10-0825 Energy Converter (Ascent)
B2 10-0825-P Energy Converter (Ascent Plus)
C 10-0831 Front Liner Board
D 10-0832 Rear Liner Board (PacMan)
Front Insulation Board 2"
F 10-0829
G 10-0826-F Front Cover
H 10-0826-L Left Jacket
J 10-0826-R Right Jacket
Top Jacket –Ascent (one piece)
K1 10-0826-T
Top Jacket –Ascent Plus (three pcs)
K2 10-0826-TP
COMMON ITEMS AVAILABLE BUT NOT SHOWN
PART NO. DESCRIPTION
Air Vent, 1/2" with ¾" bushing
10-0434H
10-0178 Puff Switch
10-0599 Ascent Hydrostat w/Sensor w/o Well
Hydrostat Well, ½" NPT
10-0597
10-0568F TACO 007e ECM Circulator
10-0705 Amulet Carlin EZ1
Ascent Oil – August 2019
H
A
S
T
DESCRIPTION
K
D
B1
P
R
EK1T
ITEM
PART NO.
L 10-0830
M 10-0826-B
N 10-0833
P 10-0726
R 10-0827-RL
S 10-0827-LL
T 10-0827-FP
U 10-0295
V 10-0296
W 10-1064
PART NO. DESCRIPTION
10-0465 Primary Control w/Oil Valve On-Delay
10-0420 T&P Gauge
10-0933 Cartridge for Smart Filter
10-0132 Flexible Oil Line
10-0904 Filter Bracket w/Mounting Hardware
10-0447 #18 Plate Heat Exchanger
32
M
L
E
J
DESCRIPTION
Rear Insulation Board 2"
Rear Cover
Front Board Clip (ea)
Door Hinge Assembly (ea.)
Base Right Leg
Base Left-Leg
Base Front/Rear Panel (ea)
Power Vent Assembly (Ascent Plus)
Vent Adaptor (Ascent Plus)
Vent Adaptor to PPS (Ascent Plus)
B2
