2.7 JTAG Interface.
The TMS320F240 Evaluation Module is supplied with a 14 pin header interface, P5.
This is the standard interface used by JTAG emulators to interface to Texas
Instruments DSPs. The pinout for the connector is shown below:
PD (+5V)
TCK-RET
TMS 1 2
TDI 3 4
5 6
TDO 7
8
9
10
11
TCK
12
EMU0 13
14
TRST-
GND Header Dimensions
Pin-to-Pin spacing, 0.100 in. (X,Y)
no pin (key)
Pin width, 0.025-in. square post
GND
GND
Pin length, 0.235-in. nominal
GND
EMU1
