2.6.1.4 Expansion Control Connector
The definition of P4, which has the control signals is shown below.
Pin #
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
2-14
Table 6: P4 Control
Signal
VCC, +5 Volts
DS-
IS-
WE-
STRB-
READY
RS-
NMI-
GND
XINT2-/IO
RESERVED
RESERVED
RESERVED
RESERVED
RESERVED
CLKIN
GND
TMS320F240 Evaluation Module Technical Reference
Pin # Signal
2 VCC, +5 Volts
4 PS-
6 BR-
8 W/R-
10 R/W
12 RESERVED
14 TRGRESET-
16 XINT1-
18 GND
20 XINT3-/IO
22 RESERVED
24 RESERVED
26 RESERVED
28 RESERVED
30 RESERVED
32 CLKOUT/IOPC1
34 GND
