2.6.1.2 Expansion Analog Connector
The definition of P2, which has the analog signals is shown below.
Pin #
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
2-12
Table 4: P2 Analog
Signal
VCCA, +5V Analog
ADCIN0/IOPA0
ADCIN2
ADCIN4
ADCIN6
ADCIN8/IOPA3
ADCIN10
ADCIN12
AGND
ADCIN14
VREFHI
AGND
DACOUT1
DACOUT3
RESERVED
RESERVED
AGND
TMS320F240 Evaluation Module Technical Reference
Pin # Signal
2 VCCA, +5V Analog
4 ADCIN1/IOPA1
6 ADCIN3
8 ADCIN5
10 ADCIN7
12 ADCIN9/IOPA2
14 ADCIN11
16 ADCIN13
18 AGND
20 ADCIN15
22 VREFLO
24 AGND
26 DACOUT2
28 DACOUT4
30 RESERVED
32 ADCSOC/IOPC0
34 AGND
