2.6.1.3 Expansion Address and Data Connector
The definition of P3, which has the address and data signals is shown below.
Pin #
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
Table 5: P3 Address/Data
Signal Pin #
A0 2
A2 4
A4 6
A6 8
A8 10
A10 12
A12 14
A14 16
GND 18
D0 20
D2 22
D4 24
D6 26
D8 28
D10 30
D12 32
D14 34
Spectrum Digital, Inc
Signal
A1
A3
A5
A7
A9
A11
A13
A15
GND
D1
D3
D5
D7
D9
D11
D13
D15
