CHARACTERISTICS:
The HD67672 is a BACnet / Modbus Slave - Converter.
It has the following characteristics:
Up to 2000 BACnet objects;
Triple isolation between BACnet - Power Supply, BACnet - Modbus, Power Supply - Modbus.
Two-directional information between BACnet bus and Modbus bus;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8...24V AC or 12...35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].
CONFIGURATION:
You need Compositor SW67672 software on your PC in order to perform the following:
Define the parameter of BACnet line;
Define the parameter of Modbus line;
Define BACnet objects that contains the data sent by the Modbus Master;
Define BACnet objects that contains the data to send to the Modbus Master;
Update the device.
