18. ASE2000 Kit Contents

The ASE2000 is provided in kit form with all the necessary software, cables, adaptors, and
documentation to configure an operational test set. The actual kit contents will vary according to
ASE2000 model and are detailed in the following sections.

18.1. Model ASE2000-USB-M

• ASE2000 Software Installation CD-ROM. This CD contains both the ASE2000 Application
software installation files and the I/O driver files for the ASE dual-channel BCOM-USB device
and the SafeNet Pro/SuperPro Security Plug (dongle).
• ASE dual channel BCOM-USB device
• USB Cable – PC to BCOM-USB
• USB to ASE 2-Channel Modem Power Cable
• Two RS-233 Cables, each with a DB-9 Female connector on one end and a DB-25 Male
connector on the other end.
• ASE Bell-202 or CCITT V.23 dual-channel modem and two RJ-11 cables with fork-lug
connectors (optional only with the BCOM-USB models)
• DB-25 female-female gender changer
• DB-25 null modem adapter
• DB-9 to DB-25 adaptors
• RS-232 monitor-mode adapter cable
• ASE2000 documentation - ASE2000 Communication Test Set User Guide.

18.2. Model ASE2000-USB-RS

• ASE2000 Software Installation CD-ROM. This CD contains both the ASE2000 Application
software installation files and the I/O driver files for the ASE dual-channel BCOM-USB device
and the SafeNet Pro/SuperPro Security Plug (dongle).
• ASE dual channel BCOM-USB device
• USB Cable – PC to BCOM-USB
• Two RS-233 Cables, each with a DB-9 Female connector on one end and a DB-25 Male
connector on the other end.
• DB-25 female-female gender changer
• DB-25 null modem adapter
• DB-9 to DB-25 adaptors
• RS-232 monitor-mode adapter cable
• ASE2000 documentation - ASE2000 Communication Test Set User Guide.

18.3. Model ASE2000-COM

• ASE2000 Software Installation CD-ROM. This CD contains both the ASE2000 Application
software installation files and the I/O driver files for the ASE dual-channel BCOM-USB I/O card
and the SafeNet Pro/SuperPro Security Plug (dongle).
• SafeNet parallel port (LPT) or USB dongle for desktop or laptop PCs. The hardware dongle
included in this package enables the ASE2000 software.
• Two RS-233 Cables, each with a DB-9 Female connector on one end and a DB-25 Male
connector on the other end.
