Cypress Semiconductor MB2146-302A Operation Manual

Mcu board for the f2mc*-8fx family mb95fv100d-102
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
2
F
MC-8FX Family
MCU Board for MB95FV100D-102
MB2146-302A,
Operation Manual
Doc. # 002-07488 Rev. *B
Cypress Semiconductor
198 Champion Court
San Jose, CA 95134-1709
Phone (USA): 800.858.1810
Phone (Intnl): +1.408.943.2600
www.cypress.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MB2146-302A and is the answer not in the manual?

Questions and answers

Related Manuals for Cypress Semiconductor MB2146-302A

Summary of Contents for Cypress Semiconductor MB2146-302A

  • Page 1 MC-8FX Family MCU Board for MB95FV100D-102 MB2146-302A, Operation Manual Doc. # 002-07488 Rev. *B Cypress Semiconductor 198 Champion Court San Jose, CA 95134-1709 Phone (USA): 800.858.1810 Phone (Intnl): +1.408.943.2600 www.cypress.com...
  • Page 2 RAM, and Traveo are trademarks or registered trademarks of Cypress in the United States and other countries. For a more complete list of Cypress trademarks, visit cypress.com. Other names and brands may be claimed as property of their respec- tive owners. F2MC-8FX Family, MCU BOARD for MB95FV100D-102 MB2146-302A, Operation Manual, Doc. # 002-07488 Rev. *B...
  • Page 3 F MC-8FX family of microcontrollers manufactured by Cypress. This manual is intended for engineers who use the MB2146-302A (referred to below as the MCU board) to develop applied products based on Cypress F MC-8FX family microcontrollers. The man- ual describes how to handle the MCU board and its functions as well as the setting procedures.
  • Page 4 Data Sheet of the MCU used ■ “MB2146-09 BGM Adapter Instruction Manual” ■ Related “Header Board Instruction Manuals” ■ ““S Workbench Operation Manual” OFTUNE ■ “S Workbench USER’S Manual” OFTUNE ■ F2MC-8FX Family, MCU BOARD for MB95FV100D-102 MB2146-302A, Operation Manual, Doc. # 002-07488 Rev. *B...
  • Page 5 Re-transporting the product may damage it to cause a fault. Keep Damage the packaging materials used for shipment of the product and use them when re- transporting it. F2MC-8FX Family, MCU BOARD for MB95FV100D-102 MB2146-302A, Operation Manual, Doc. # 002-07488 Rev. *B...

  • Page 6: Table Of Contents

    General specifications ....................21 Functional explanation....................21 Clock settings ......................23 Header board specifications ..................24 Connector socket specifications ................24 Pin assignment of header board I/F connector ............24 Revision History F2MC-8FX Family, MCU BOARD for MB95FV100D-102 MB2146-302A, Operation Manual, Doc. # 002-07488 Rev. *B...

  • Page 7: Product Outline

    MCU board, and BGM adapter (model number: MB2146-09) as shown in Figure 1-1. Figure 1-1. System configuration MCU board BGM adapter Header board F2MC-8FX Family, MCU BOARD for MB95FV100D-102 MB2146-302A, Operation Manual, Doc. # 002-07488 Rev. *B...

  • Page 8: Product Configuration

    Table 1-1. Product configuration Name Model number Description MCU board with built-in MB95FV100D- MB2146-302A MC-8FX MCU board* * Neither the oscillator nor the capacitor is bundled with the MB2146-302A. Therefore, prepare them separately. Table 1-2. Optional parts Name Model number Description MB2146-09...

  • Page 9: Appearance And Part Name

    (10) BGM adapter connector (11) Header board I/F connector A (12) Header board I/F connector B (13) Evaluation MCU (MB95FV100D-102) (14) Incorrect insertion prevention guard Note used during debugging. F2MC-8FX Family, MCU BOARD for MB95FV100D-102 MB2146-302A, Operation Manual, Doc. # 002-07488 Rev. *B...

  • Page 10: Checking The Delivered Product

    Before using the MCU board, confirm that the following components are included in the box: MCU board: 1 ■ Operation manual (English version, this manual) : 1 ■ Operation manual (Japanese version) : 1 ■ F2MC-8FX Family, MCU BOARD for MB95FV100D-102 MB2146-302A, Operation Manual, Doc. # 002-07488 Rev. *B...

  • Page 11: Connections

    *: Be sure to connect the BGM adapter correctly to the BGM adapter connector (CN3) on the MCU board. I can damage the MCU board if it is accidentally connected to the LVD2 detection voltage selector jumper plug (S2). F2MC-8FX Family, MCU BOARD for MB95FV100D-102 MB2146-302A, Operation Manual, Doc. # 002-07488 Rev. *B...

  • Page 12: Note On Connection

    BGM adapter connector on the MCU board. b. Remove the header board from the MCU board. Remove it with uniform force without applying force to only one point. F2MC-8FX Family, MCU BOARD for MB95FV100D-102 MB2146-302A, Operation Manual, Doc. # 002-07488 Rev. *B...

  • Page 13: How To Setup

    “Setting of the LVD2 detection voltage selector jumper plug (S2)”. Figure 4-1. The switch and jumper plug on a MCU board GND VCC PRODUCT SELECT 1 2 3 4 1 2 3 4 ADAPTER F2MC-8FX Family, MCU BOARD for MB95FV100D-102 MB2146-302A, Operation Manual, Doc. # 002-07488 Rev. *B...

  • Page 14: How To Oscillator Mounting On A Mcu Board

    F MC-8FX (MB95FV100D and MB2146-09). 2. Do not perform a chip erase when using the software development support environment for the MC-8FX (MB95FV100D and MB2146-09). F2MC-8FX Family, MCU BOARD for MB95FV100D-102 MB2146-302A, Operation Manual, Doc. # 002-07488 Rev. *B...

  • Page 15: Setting Of The Switch And Jumper Plug

    Set this switch depending on the number of Product selector pins on the target MCU to be used (See “Set- switch ting of the product selector switch (SW3)”). F2MC-8FX Family, MCU BOARD for MB95FV100D-102 MB2146-302A, Operation Manual, Doc. # 002-07488 Rev. *B...
  • Page 16 (S1)”). LVD2 detection volt- Set the LVD2 detection voltage (See “Setting age selector jumper of the LVD2 detection voltage selector jumper LVD0 plug plug (S2)”). F2MC-8FX Family, MCU BOARD for MB95FV100D-102 MB2146-302A, Operation Manual, Doc. # 002-07488 Rev. *B...

  • Page 17: Setting Of The Clock Input Selector Switch (Sw2)

    Table 4-3. Setting of the sub clock supply source Settings of the clock input selector switch Sub clock supply source SW2-3 SW2-4 Clock area User system F2MC-8FX Family, MCU BOARD for MB95FV100D-102 MB2146-302A, Operation Manual, Doc. # 002-07488 Rev. *B...

  • Page 18: Setting Of The Product Selector Switch (Sw3)

    100-pin package, LCD function integrated type 80-pin package, LCD function integrated type 64-pin package, LCD function integrated type 48-pin, 52-pin package, LCD function integrated type Setting Prohibited F2MC-8FX Family, MCU BOARD for MB95FV100D-102 MB2146-302A, Operation Manual, Doc. # 002-07488 Rev. *B...

  • Page 19: Setting Of The Sub Clock Selector Jumper Plug (S1)

    * Oscillation is not guaranteed when the crystal oscillator is mounted on the user system. Figure 4-5. The example of sub clock selection Example 1 Example 2 F2MC-8FX Family, MCU BOARD for MB95FV100D-102 MB2146-302A, Operation Manual, Doc. # 002-07488 Rev. *B...

  • Page 20: Setting Of The Lvd2 Detection Voltage Selector Jumper Plug (S2)

    Table 4-6. Setting of the LVD2 detection voltage selector jumper plug Jumper plug position LVD2 setting value LVD0 Å{4.17V LVD1 Å{3.74V LVD2 Å{3.3V LVD3 Å{2.9V LVD4 Å{2.6V F2MC-8FX Family, MCU BOARD for MB95FV100D-102 MB2146-302A, Operation Manual, Doc. # 002-07488 Rev. *B...

  • Page 21: Product Specifications

    The crystal oscillator mounted socket on the MCU board is used to supply clock signals Clock mounting to the main clock (X0/X1) and sub clock (X0A/X1A) pins on the evaluation MCU from the socket MCU board. F2MC-8FX Family, MCU BOARD for MB95FV100D-102 MB2146-302A, Operation Manual, Doc. # 002-07488 Rev. *B...
  • Page 22 Vcc,GND,BRSTX, SEL4 connector BSIN,BSOUT, BDBMX,BEXCK LVDIN SEL0 LVR0 Product SEL1 LVR1 selector SEL2 LVR2 switch SEL3 LVR3 LVR4 LVD2 detection voltage setting jumper plug Other pins F2MC-8FX Family, MCU BOARD for MB95FV100D-102 MB2146-302A, Operation Manual, Doc. # 002-07488 Rev. *B...

  • Page 23: Clock Settings

    Figure 5-2. Clock selector circuit Clock input selector switch Crystal oscillator mounting socket (main clock) (M1) Crystal oscillator (R1) mounting socket Sub clock selector (sub clock) jumper plug F2MC-8FX Family, MCU BOARD for MB95FV100D-102 MB2146-302A, Operation Manual, Doc. # 002-07488 Rev. *B...

  • Page 24: Header Board Specifications

    Mounts the sub clock crystal oscillator. Pin assignment of header board I/F connector Table 5-5 Table 5-6 lists the pin assignments of the header board interface connectors on the MCU board F2MC-8FX Family, MCU BOARD for MB95FV100D-102 MB2146-302A, Operation Manual, Doc. # 002-07488 Rev. *B...
  • Page 25 PADDR0 PAC- LVCC * TIVE LVDIN PLOCK Cpin PWRITE Vcc51 * PADDR1  LVDENX2 GND * PADDR2  LVR4 GND * PADDR3 TESTO PADDR4 LVDOUT PADDR5 F2MC-8FX Family, MCU BOARD for MB95FV100D-102 MB2146-302A, Operation Manual, Doc. # 002-07488 Rev. *B...
  • Page 26 MCU Pin line MCU Pin line MCU Pin line Number Number name Number Number name Number Number name LVR2 PADDR7 PRDA- BGOENX LVR1 PADDR6 PRDA- LVR0 ROMS0 F2MC-8FX Family, MCU BOARD for MB95FV100D-102 MB2146-302A, Operation Manual, Doc. # 002-07488 Rev. *B...
  • Page 27 PE5A P03B PWDA- PE7A P02B PWDA- PE3B P00B PWDA- PE6A PRDA- Vss * PWDA-  PE2B GND * PWDA-  PE7B GND * PWDA- PE1B P01B F2MC-8FX Family, MCU BOARD for MB95FV100D-102 MB2146-302A, Operation Manual, Doc. # 002-07488 Rev. *B...
  • Page 28 Connect the Vcc51, Vcc53 and Vcc54 pins to Vcc. Disconnect the LVCC pin from Vcc. Connect the Vss pin to GND. Disconnect the LVSS pin from GND. : 3.3V power supply pins : GND power supply pins F2MC-8FX Family, MCU BOARD for MB95FV100D-102 MB2146-302A, Operation Manual, Doc. # 002-07488 Rev. *B...

  • Page 29: Revision History

    Issue Date Description of Change Change  03/13/2007 HUAL Initial release 5299269 06/13/2016 HUAL Migrated to Cypress format 5774833 06/15/2017 NIBK Updated Cypress Logo and Copyright. F2MC-8FX Family, MCU BOARD for MB95FV100D-102 MB2146-302A, Operation Manual, Doc. # 002-07488 Rev. *B...
